- Page 1 Installation and User's Manual for Self Contained Prodigy Cubers Models CU1526, CU2026 and CU3030 E Series...
-
Page 2: Table Of Contents
CU1526, CU2026, CU3030 User Manual Introduction The design of this cuber is the result of years of This installation and user manual is divided into experience and testing. Standard features include three main sections: Installation, which provides a removable bin for service. the trade person with the information needed to set up and install this product;... -
Page 3: Installation: Product Specifications
CU1526, CU2026, CU3030 User Manual Installation: Product Specifications In most cases, CU3030 air cooled models installed without legs or casters will experience reduced ice making capacity. Location Limitations: Environmental Limitations The product is designed to be installed indoors, in a controlled environment. Air cooled models discharge very warm air into the room. -
Page 4: Model Number Description
• and performance. CU2026SA-1E • C= cuber Scotsman assumes no liability of responsibility of • U=under the counter type any kind for products manufactured by Scotsman • 20= nominal ice capacity in 10s of pounds that have been altered in any way, including the •... -
Page 5: Water
Testing has shown that using a filter that floor, see that kit's instructions. If placing on the does not remove chlorine, such as the Scotsman floor without using that kit, position field supplied Aqua Patrol, will greatly improve this situation,... -
Page 6: Cu1526 And Cu2026 Cabinet Layout
CU1526, CU2026, CU3030 User Manual CU1526 and CU2026 Cabinet Layout March 2017 Page 5... -
Page 7: Cu3030 Cabinet Layout
CU3030 Cabinet Layout March 2017 Page 6... -
Page 8: Ice Storage Bin Removal
CU1526, CU2026, CU3030 User Manual Ice Storage Bin Removal The ice storage bin is removable to allow access to 9. Remove two bolts from the bottom of the bin, the refrigeration system for service. one on the left and one on the right. 1. -
Page 9: Plumbing Requirements
CU1526, CU2026, CU3030 User Manual Plumbing Requirements Connect to cold, potable water. A hand actuated 2. Connect drain tubing to drain fittings. valve within site of the machine is required. Air cooled models have a single 3/8” male flare inlet 3. -
Page 10: Electrical
CU1526, CU2026, CU3030 User Manual Electrical The machine is supplied with a power cord. 208-230 volt, 60 Hz cords have NEMA 6-20P plugs. This is a cord-connected unit, and must be on a separate power supply. Check the dataplate for the voltage, ampacity and maximum fuse size and per the dataplate use fuses or HACR circuit breakers. -
Page 11: Initial Start Up
CU1526, CU2026, CU3030 User Manual Initial Start Up The display shows an H. The hot gas valve opens, 1. Remove left front louver. Check machine for any packing or wires rubbing moving parts. the air cooled fan motor(s) shut off and the harvest Note location of control board at the left. -
Page 12: Adjustments
CU1526, CU2026, CU3030 User Manual Adjustments Bridge Thickness - For the Service Tech Only 1/8-3/16" 1. Remove left louver, locate controller on and off bridge switches. 2. Push and hold Off till the machine stops. 3. Remove curtain. 4. Use a hex wrench and rotate the bridge thickness adjustment screw in 1/8 turn increments CW to increase bridge thickness. -
Page 13: Use And Operation
Contact an switch light on all the time, as a curtain switch light authorized Scotsman service agent and have the is ON when a curtain is either open or not present. machine cleaned, de-scaled and sanitized. -
Page 14: Control Switches
CU1526, CU2026, CU3030 User Manual Control Switches The controller (located inside the cabinet) has on and off switches: The cuber drops ice in large sections. That ice will To switch the machine OFF, push and release the break up into random parts as it falls into the bin, Off button. -
Page 15: Cleaning, Sanitation And Maintenance
11. Mix a cleaning solution of 1 oz of ice machine scale remover to 12 ounces of water. 6. Pour 8 ounces of Scotsman Clear 1 ice machine scale remover into the reservoir. 12. Locate curtain, push in on edge of curtain by pivot pin to release it. - Page 16 CU1526, CU2026, CU3030 User Manual 23. Push and release the On button to resume ice making. 24. Return the top panel and front louvered panel to their normal position and secure with the original fasteners. Inspect Orifice Holes Air cooled condenser filter used on the CU1526 and CU2026 only Inspect Water Distributor 1.
-
Page 17: What To Do Before Calling For Service
CU1526, CU2026, CU3030 User Manual What to do before calling for service Reasons the machine might shut itself off: To Manually Reset the machine. • Lack of water. • Push and release the On/Off button. • Freeze cycle takes too long. •... - Page 18 SCOTSMAN ICE SYSTEMS 101 Corporate Woods Parkway Vernon Hills, IL 60061 1-800-726-8762 www.scotsman-ice.com 17-3645-01 Rev.D Last Revised: July 02 2018...
