Biostar m7vik motherboard: user guide
Hide thumbs Also See for M7VIK:

Advertisement

Quick Links

M
7
V
I
K
M
7
V
I
K
M
7
V
I
K
FCC Statement and Copyright
This equipment has been tested and found to comply with the limits of a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. There is no guarantee that interference will not occur in a
particular installation.
The vendor makes no representations or warranties with respect to the
contents here of and specially disclaims any implied warranties of
merchantability or fitness for any purpose. Further the vendor reserves the
right to revise this publication and to make changes to the contents here of
without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole is not allowed without
first obtaining the vendor's approval in writing.
The content of this user's is subject to be changed without notice and we
will not be responsible for any mistakes found in this user's manual. All the
brand and product names are trademarks of their respective companies.
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M7VIK and is the answer not in the manual?

Questions and answers

Summary of Contents for Biostar M7VIK

  • Page 1 FCC Statement and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    ENGLISH... 1 M7VIK Features... 1 Package contents ... 2 Layout of M7VIK ... 2 CPU Installation ... 3 DDR DIMM Modules: DIMM1-2-3 ... 4 Jumpers, Headers, Connectors & Slots ... 6 ESPAÑOL ...11 Características del M7VIK... 11 Contenido del Paquete... 12 Disposición del M7VIK ...
  • Page 3: English

    English M7VIK Features Use VIA KT400 / VT8235 Chipset, Winbond W83697HF. Contains on board I/O facilities, which include two serial ports, a parallel port, a PS/2 mouse port, a PS/2 keyboard port, audio ports, USB ports, a game port. Supports Single Socket-A for an AMD Athlon/ Duron Family processor, running at 200/266/333 MHz Front Side Bus frequency.
  • Page 4: Package Contents

    Flash Memory Writer for BIOS update X 1 USB Cable X 2 (Optional) Rear I/O Panel for ATX Case X 1 (Optional) IEEE1394 Cable X1 (Optional) Serial ATA Cable X1 (Optional) Layout of M7VIK JKBV1 JUSBV1 Socket A JCOM1 JPRNT1...
  • Page 5: Cpu Installation

    CPU Installation Pull the lever sideways away from the socket then raise the lever up to 90-degree angle. Locate Pin A in the socket and lock for the white dot or cut edge in the CPU. Match Pin A with the white dot/cut edge then insert the CPU.
  • Page 6: Ddr Dimm Modules: Dimm1-2-3

    DDR DIMM Modules: DIMM1-2-3 DRAM Access Time: 2.5V Unbuffered/ Registered DDR 1600/ 2100/ 2700/ 3200 Type required. DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin) Only support 4 bank for DDR PC3200 (2pcs Double-Side or 3 pcs Single-Side). DIMM Socket Location DIMM 1...
  • Page 7: How To Install A Dimm Module

    How to install a DIMM Module 1. The DIMM socket has a “ Plastic Safety Tab”, and the DIMM memory module has an “Asymmetrical notch”, DIMM memory module can only fit into the slot in one direction. 2. Push the tabs out. Insert the DIMM memory modules into the socket at a 90-degree angle, then push down vertically so that it will...
  • Page 8: Jumpers, Headers, Connectors & Slots

    The first hard drive should always be connected to IDE1. Serial ATA Connector: (JSATA1/ JSATA2) (Optional) The motherboard has a PCI to SATA Controller with 2 channels STAT interface, it satisfies the SATA 1.0 spec and can transfer data with 1.5GHz speed.
  • Page 9 Peripheral Component Interconnect Slots: PCI1-5 This motherboard is equipped with 5 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards, which has, supplanted the older ISA bus standard in most ports. This PCI slot is designated as 32 bits.
  • Page 10 5V/ 5VSB Selection for USB/KB: JUSBV1/2/3/ JKBV1 JUSBV1/2/3 JKBV1 Front 1394 Header: J1394A1/J1394B1/J1394C1 Pin1,2 ==> A+/A- Pin1,2 ==> +5V Pin3,4 ==> Dato(-) Pin3,4 ==> Ground Pin5,6 ==> B+/ B- Pin5,6 ==> Dato(+) Pin7,8 ==> +12V Pin7,8 ==> Tierra J1394A1/B1/C1 Pin9 Pin9 JUSB3/4 Pin10 ==>...
  • Page 11 CPU Clock Selection: JCLK1 Pin 1-2, 5-6 ==> 100 Mhz Pin 2-3, 5-6 ==> 133 Mhz JCLK1 Pin 2-3, 4-5 ==> 166Mhz Audio Subsystem: JAUDIO1/ JCDIN1 JAUDIO1 JAUDIO1 (Front Audio Header) (Front Audio Header) (CD-ROM Audio-In Header) (CD-ROM Audio-In Header) Clear CMOS Jumper: JCMOS1 Pin 1-2 on ==>...
  • Page 12: Back Panel Connectors

    Back Panel Connectors JKBMS1 JPRNT1 PS/2 JGAME1 Mouse Parallel Game Port JUSB1 Speaker Line In Mic PS/2 COM1 COM1 COM1 COM1 COM2 Keyboard JCOM1 JCOM2...
  • Page 13: Español

    Español Características del M7VIK Usa Chipsets VIA KT400 / VT8235, Winbond W83697HF. Contiene facilidades I/O integrados en la placa madre en el que incluye dos puertos en serie, un puerto paralelo, un puertos de ratón PS/2, un puerto de teclado PS/2, puertos de audio, puertos USB y un puerto de juego.
  • Page 14: Contenido Del Paquete

    Flash Memory Writer para actualización del BIOS X 1 Cable USB X 2 (Opcional) Panel Trasero I/O para Caja ATX X 1 (Opcional) Cable IEEE1394 X1 (Opcional) Cable Serial ATA X1 (Opcional) Disposición del M7VIK JKBV1 JUSBV1 Socket A JCOM1...
  • Page 15: Instalación De La Cpu

    Instalación de la CPU Tire de la palanca del lado del zócalo, luego levante la palanca hasta un ángulo de 90 grados. Sitúe el contacto A del zócalo y busque el punto blanco o corte el borde en la CPU. Empareje el contacto A con el punto blanco/ corte del borde, luego inserte la CPU.
  • Page 16: Módulos Ddr Dimm: Dimm1-2-3

    Módulos DDR DIMM: DIMM1-2-3 DRAM Tiempo de Acceso: 2.5V Unbuffered/ Registered DDR 1600/ 2100/ 2700/ 3200 Tipo requerido. DRAM Tipo: 64MB/ 128MB/ 256MB/ 512MB/ 1GB Módulo DIMM (184 contactos) Solamente soporta 4 bancos para DDR 3200 (2 DDR de Doble Cara o 3 DDR de una cara. Localización del Módulo DIMM...
  • Page 17 Cómo instalar un Módulo DIMM 1. El zócalo DIMM tiene una lengüeta plástica de seguridad y el módulo de memoria DIMM tiene una muesca asimétrica, así el módulo de memoria DIMM puede caber solamente en la ranura de una sóla dirección. 2.
  • Page 18: Puentes, Cabezales, Conectores Y Ranuras

    Puentes, Cabezales, Conectores y Ranuras Conectores del Disco Duro: IDE1/ IDE2 La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo PIO 0~4, Bus Master, y funcionalidad Ultra DMA / 33/ 66/ 100. Tiene dos conectores HDD IDE1 (primario) y IDE2 (secundario). El conector IDE puede conectar a un master y un drive esclavo, así...
  • Page 19 Ranura de Interconexión del Componente Periférico: PCI1-5 Ésta placa madre está equipada con 5 ranuras estándar PCI. PCI es la sigla para Interconexión del Componente Periférico, y es un bus estándar para tarjetas de expansión en el que suplanta a la antigua bus estándar ISA, en su mayoría de las partes.
  • Page 20 5V/ 5VSB Selección para USB/KB: JUSBV1/2/3/ JKBV1 JUSBV1/2/3 JKBV1 Cabezal Frontal 1394: J1394A1/J1394B1/J1394C1 Contacto1,2 ==> A+/A- Pin1,2 ==> +5V Contacto3,4 ==> Tierra Pin3,4 ==> Dato(-) Contacto5,6 ==> B+/ B- Pin5,6 ==> Dato(+) Contacto7,8 ==> +12V Pin7,8 ==> Tierra J1394A1/B1/C1 Pin9 Contacto9 JUSB3/4 Pin10 ==>...
  • Page 21 Selección del Reloj del CPU: JCLK1 Contacto 1-2, 5-6 ==> 100 Mhz Contacto 2-3, 5-6 ==> 133 Mhz JCLK1 Contacto 2-3, 4-5 ==> 166Mhz Subsistema de Audio: JAUDIO1/ JCDIN1 JAUDIO1 (Cabezal Frontal de Audio) Puente de Borrar CMOS: JCMOS1 Contacto 1-2 on ==> Operacion Normal (default) Contacto 2-3 on ==>...
  • Page 22 Conectores del Panel Trasero JKBMS1 JPRNT1 Raton PS/2 Paralelo JUSB1 Teclado COM1 PS/2 JCOM1 JGAME1 Puerto de Juego Salida del Entrada Entrada COM2 Altavoz de Linea del MIC JCOM2...
  • Page 23: Warpspeeder

    WarpSpeeder Introduction [ WarpSpeeder™ ], a new powerful control utility, features three user-friendly functions including Overclock Manager, Overvoltage Manager, and Hardware Monitor. With the Overclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU performance with just one click. The Overvoltage Manager, on the other hand, helps to power up CPU core voltage and Memory voltage.
  • Page 24: System Requirement

    System Requirement OS Support: Windows 98 SE, Windows Me, Windows 2000, Windows XP DirectX: DirectX 8.1 or above. (The Windows XP operating system includes DirectX 8.1. If you use Windows XP, you do not need to install DirectX 8.1.) Installation Execute the setup execution file, and then the following dialog will pop up.
  • Page 25 When you see the following dialog in setup procedure, it means setup is completed. If the “Launch the WarpSpeeder Tray Utility” checkbox is checked, the Tray Icon utility and [ WarpSpeeder™ ] utility will be automatically and immediately launched after you click “Finish”...
  • Page 26: Usage

    Usage The following figures are just only for reference, the screen printed in this user manual will change according to your motherboard on hand. [ WarpSpeeder™ ] includes 1 tray icon and 5 panels: 1. Tray Icon: Whenever the Tray Icon utility is launched, it will display a little tray icon on the right side of Windows Taskbar.
  • Page 27 2. Main Panel If you click the tray icon, [ WarpSpeeder™ ] utility will be invoked. Please refer do the following figure; the utility’s first window you will see is Main Panel. Main Panel contains features as follows: a. Display the CPU Speed, CPU external clock, Memory clock, AGP clock, and PCI clock information.
  • Page 28 3. Voltage Panel Click the Voltage button in Main Panel, the button will be highlighted and the Voltage Panel will slide out to up as the following figure. In this panel, you can decide to increase CPU core voltage and Memory voltage or not.
  • Page 29 4. Overclock Panel Click the Overclock button in Main Panel, the button will be highlighted and the Overclock Panel will slide out to left as the following figure. Overclock Panel contains the these features: a. “–3MHz button”, “-1MHz button”, “+1MHz button”, and “+3MHz button”: provide user the ability to do real-time overclock adjustment.
  • Page 30 “Verify button”: User can click this button and [ WarpSpeeder™ ] will proceed a testing for current frequency. If the testing is ok, then the current frequency will be saved into system registry. If the testing fail, system will do a fail-safe rebooting. After reboot, the [ WarpSpeeder™ ] utility will restore to the hardware default setting or load the verified best and stable frequency according to the Recovery Dialog’s setting.
  • Page 31 5. Hardware Monitor Panel Click the Hardware Monitor button in Main Panel, the button will be highlighted and the Hardware Monitor panel will slide out to left as the following figure. In this panel, you can get the real-time status information of your system. The information will be refreshed every 1 second.
  • Page 33 Note: Because the overclock, overvoltage, and hardware monitor features controlled several separate chipset, [ WarpSpeeder™ ] divide these features to separate panels. If one chipset is not on board, the correlative button in Main panel will be disabled, but will not interfere other panels’ functions. This property can make [ WarpSpeeder™...
  • Page 34: Trouble Shooting

    Trouble Shooting PROBABLE No power to the system at all Power light don’t illuminate, fan inside power supply does not turn on. Indicator light on keyboard does not turn on PROBABLE System inoperative. Keyboard lights are on, power indicator lights are lit, hard drive is spinning.
  • Page 35: Solución De Problemas

    Solución de Problemas CAUSA PROBABLE No hay corriente en el sistema. La luz de corriente no ilumina, ventilador dentro de la fuente de alimentación apagada. Indicador de luz del teclado apagado. CAUSA PROBABLE Sistema inoperativo. Luz del teclado encendido, luz de indicador de corriente iluminado, disco rígido está...
  • Page 36 09/5/2002...
