FM/AM Cassette Receiver
ALPINE ELECTRONICS, INC.
Tokyo office: 1-1-8 Nishi Gotanda,
Shinagawa-ku,
Tokyo 141-8501, Japan
Tel.: (03) 3494-1101
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
Suite 203, 7300 Warden Ave. Markham,
Ontario L3R 9Z6, Canada
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
Melyi Printing Factory, Dalian, China
No. 28 Chang Qing Street, Xl Gang District, Dalian, China
TDM-7582
• OWNER'S MANUAL
Please read before using this equipment.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
6-8 Fiveways Boulevarde Keysborough,
Victoria 3173, Australia
Tel.: (03) 9769-0000
ALPINE ELECTRONICS GmbH
Kreuzerkamp 7-11 40878 Ratingen, Germany
Tel.: 02102-45 50
ALPINE ITALIA S.p.A.
Via C. Colombo 8, 20090 Trezzano Sul Naviglio
MI, Italy
Tel.: 02-48 47 81
R R
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue De La Belle Etoile, Z.I. Paris Nord Il
B.P. 50016 F-95945, Roissy, Charles De Gaulle
Cedex, France
Tel.: 01-48 63 89 89
ALPINE ELECTRONICS OF U.K., LTD.
13 Tanners Drive, Blakelands, Milton Keynes
MK14 5BU, U.K.
Tel.: 01908-61 15 56
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal De Gamarra 36, Pabellón 32
01013 Vitoria (Alava)-Apdo. 133, Spain
Tel.: 34-45-283588
Designed by ALPINE Japan
Printed in China (Y)
68P01434K83-O
EN
FR
ES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TDM-7582 and is the answer not in the manual?

Questions and answers

Related Manuals for Alpine TDM-7582

Summary of Contents for Alpine TDM-7582

  • Page 1 Veuillez lire avant d'utiliser cet appareil. • MANUAL DE OPERACIÓN Léalo antes de utilizar este equipo. ALPINE ELECTRONICS, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ELECTRONICS FRANCE S.A.R.L. Tokyo office: 1-1-8 Nishi Gotanda, 6-8 Fiveways Boulevarde Keysborough, (RCS PONTOISE B 338 101 280)
  • Page 2 The CHA-S634 model can be connected to the M-Bus model Head Unit using the optional M-Bus/Ai-NET compatible cable. (KCA-130B) Changeurs de CD Alpine : vous avez le choix! Plus de sélections musicales, plus de souplesse, plus de confort. Le modèle CHA-S634 est un changeur 6 disques ultra performant équipé des nouvelles fonctions M DAC, CD-R/RW PLAY BACK, MP3 PLAY BACK et CD TEXT.

  • Page 3: Table Of Contents

    ENGLISH Contents CD Changer Operation Operating Instructions Controlling CD Changer (Optional) ....10 Switching between Track No. and Elapsed WARNING Time Displays ..........10 WARNING ..........2 Music Sensor (M.S.) Skip ........ 10 CAUTION ........... 2 Fast Forward and Backward ......10 PRECAUTIONS .........

  • Page 4: Warning

    Doing so may result in an accident, fire or electric shock. Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or KEEP SMALL OBJECTS SUCH AS BATTERIES OUT the nearest Alpine Service Center for repairing.
  • Page 5 Return it to your Alpine dealer or the nearest Alpine Service Station for servicing. Installation Location Make sure the TDM-7582 will not be installed in a location subjected to: • Direct sun and heat • High humidity and water •...

  • Page 6: Basic Operation

    Basic Operation MODE/LOUD CLOCK POWER A.S.U. HOUR ZERO Detaching the Front Panel Initial System Start-Up Press the POWER button to turn off the power. Immediately after installing or applying power to the unit, it should be initialized. To do this, first, Press the (Release) button until the front remove the detachable front panel.

  • Page 7: Turning Power On And Off

    Press the K or L button until the desired sound Press and hold the A.S.U. (Automatic Setup) button for at least 3 seconds to activate the is obtained in each mode. A.S.U. mode. NOTE "ASU" blinks in the display. The BASS and TREBLE settings for each source (FM, The unit automatically performs the following AM, TAPE, and CD) are automatically memorized.

  • Page 8: Radio Operation

    Radio Operation BAND/D.A.P. SOURCE g DN f UP Preset buttons (1 through 6) TUNE/A.ME Manual Tuning Press the g DN or f UP button to automatically seek for a station downward or upward respectively. Press the SOURCE button until radio frequency The unit will stop on the next station it finds.

  • Page 9: Automatic Memory Of Station Presets

    Automatic Memory of Station Tuning to Preset Stations Presets Press the SOURCE button until the radio frequency appears in the display. Press the SOURCE button until the radio frequency appears in the display. Press the BAND button repeatedly until the desired band is displayed.

  • Page 10: Cassette Player Operation

    Cassette Player Operation REPEAT PROG g DN f UP B.SKIP P.S.DN P.S.UP Inserting/Ejecting Cassette Normal Play Insert a cassette tape into the slot with the open Insert a cassette tape into the slot with the open side facing right. side facing to the right. The player automatically starts tape playback and the display shows "TAPE"...

  • Page 11: Fast Forward And Rewind

    Fast Forward and Rewind Program Sensor (P.S.) Press the g DN or f UP button during Press the P.S. DN button once during tape play tape play to fast rewind or forward the tape to return to the beginning of the current selection respectively.

  • Page 12: Cd Changer Operation

    Controlling CD Changer (Optional) Music Sensor (M.S.) Skip Momentarily press the g DN button once to The CD controls on the TDM-7582 will function return to the beginning of the current track. only when a CD Changer (M-Bus) is connected.

  • Page 13: M.i.x. (Random) Play

    M.I.X. (Random) Play Press and hold the M.I.X. button in CD play for at least 2 seconds to turn on the M.I.X. mode. When this mode is turned on, the tracks on the currently playing disc will be played back in a random sequence.

  • Page 14: Information

    • Single CD adaptor is not used. • No antenna or open connection in cable. - Attach a single CD adaptor (recommended by Alpine) - Make sure the antenna is properly connected; replace to the single disc and insert into the CD magazine.

  • Page 15: Specifications

    E - 01 Capture Ratio 2.0 dB • Malfunction in the CD Changer. AM TUNER SECTION - Consult your Alpine dealer. Press the magazine eject Tuning Range 530 – 1,710 kHz button and pull out the magazine. Usable Sensitivity 22.5 µV Check the indication.

  • Page 16: Installation And Connections

    When connecting the DO NOT USE BOLTS OR NUTS IN THE BRAKE OR TDM-7582 to the fuse box, make sure the fuse for the STEERING SYSTEMS TO MAKE GROUND intended circuit of the TDM-7582 has the appropriate amperage.

  • Page 17: Installation

    Mounting sleeve (Included) Dashboard Lock Pin Slide the TDM-7582 into the dashboard. When the unit is in place, make sure the locking pins are fully TDM-7582 seated in the down position. This can be done by pressing firmly in on the unit while pushing the Remove the Detachable Front Panel (refer to page locking pin down with a small screwdriver.

  • Page 18: Connections

    POWER ANT To power antenna REMOTE TURN-ON Blue/White To amplifier or equalizer IGNITION Ignition Key BATTERY Yellow Black Battery TDM-7582 DIN Connector PIN Configuration. Power Supply Ground lgnition Data Ground SIG GND Grey SPEAKER RIGHT Gray/ FRONT Black Front right Violet/ "...
  • Page 19 RED is right and WHITE is left. + DIN Extension Cable NOTE For some installations, an L-type DIN connector would simplify installation. Use the Alpine 4910 Adapter (Sold Separately) if your changer did not include an L- type DIN. , RCA Extension Cable (Sold Separately)

  • Page 21: Limited Warranty

    LIMITED WARRANTY ALPINE ELECTRONICS OF AMERICA, INC. AND ALPINE OF CANADA INC. ("Alpine"), are dedicated to quality craftsmanship and are pleased to offer this Warranty. We suggest that you read it thoroughly. Should you have any questions, please contact your Dealer or Alpine at one of the telephone numbers listed below.
