GA-Z270X-Gaming 5
User's Manual
Rev. 1001
12ME-Z27GME5-1001R
For more product details, please visit GIGABYTE's website.
To reduce the impacts on global warming, the packaging materials of this product
are recyclable and reusable. GIGABYTE works with you to protect the environment.
