GA-IMBLAP3450
User's Manual
Rev. 1001
For more product details, please visit GIGABYTE's website.
To reduce the impacts on global warming, the packaging materials of this product
are recyclable and reusable. GIGABYTE works with you to protect the environment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GA-IMBLAP3450 and is the answer not in the manual?

Questions and answers

Related Manuals for GIGA-BYTE TECHNOLOGY GA-IMBLAP3450

Summary of Contents for GIGA-BYTE TECHNOLOGY GA-IMBLAP3450

  • Page 1 GA-IMBLAP3450 User's Manual Rev. 1001 For more product details, please visit GIGABYTE's website. To reduce the impacts on global warming, the packaging materials of this product are recyclable and reusable. GIGABYTE works with you to protect the environment.
  • Page 2 Jun. 15, 2018 Jun. 15, 2018 Copyright © 2018 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved. The trademarks mentioned in this manual are legally registered to their respective owners. Disclaimer Information in this manual is protected by copyright laws and is the property of GIGABYTE.

  • Page 3: Table Of Contents

    Table of Contents GA-IMBLAP3450 Motherboard Layout ................4 Chapter 1 Hardware Installation ..................5 Installation Precautions ..................5 1-2 Product Specifications ..................6 Installing the Memory ..................8 Installing an Expansion Card ................8 Back Panel Connectors ..................8 Internal Connectors ..................10 Chapter 2 BIOS Setup ....................22...

  • Page 4: Ga-Imblap3450 Motherboard Layout

    GA-IMBLAP3450 Motherboard Layout SYS_FAN DC_PWR ATX_12V LVDS RUSB30_1 Intel Apollo Lake SoC N3450 ® RUSB30_2 SATA_PWR SATA3 SMBUS FPD_PWR MON_SW FUSB20_1 LCD_VCC CPU_FAN FUSB20_2 BL_SW HDMI SODIMM_1 Realtek GbE LAN ® LAN2 SODIMM_2 SPEAKER Realtek GbE LAN ® LAN1 ®...

  • Page 5: Chapter 1 Hardware Installation

    Chapter 1 Hardware Installation Installation Precautions The motherboard contains numerous delicate electronic circuits and components which can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user's manual and follow these procedures: • Prior to installation, make sure the chassis is suitable for the motherboard. •...

  • Page 6: 1-2 Product Specifications

    1-2 Product Specifications Built in with an Intel Quad-Core Celeron N3450 SoC (2.2 GHz) Š ® ® * Do not disassemble the onboard SoC and the heatsinks by yourself to avoid damage to these components. 2 MB Cache Š Memory 2 x DDR3L SO-DIMM socket supporting up to 16 GB of system memory Š...
  • Page 7 Internal 1 x digital microphone header (DMIC_CON) Š Connectors 1 x speaker header (SPKR) Š 1 x buzzer header (SPEAKER) Š 1 x chassis intrusion jumper Š 1 x LPT/GPIO header (LPT_GPIO) Š 1 x LPT configuration jumper (LPT_SEL) Š 1 x GPIO power selection jumper (GPIO_PWRSEL) Š...

  • Page 8: Installing The Memory

    Installing the Memory Read the following guidelines before you begin to install the memory: • Make sure that the motherboard supports the memory. It is recommended that memory of the same capacity, brand, speed, and chips be used. (Go to GIGABYTE's website for the latest supported memory speeds and memory modules.) •...
  • Page 9 HDMI Port The HDMI port is HDCP compliant and supports Dolby TrueHD and DTS HD Master Audio formats. It also supports up to 192KHz/24bit 8-channel LPCM audio output. You can use this port to connect your HDMI-supported monitor. The maximum supported resolution is 3840x2160@30 Hz, but the actual resolutions supported are dependent on the monitor being used.

  • Page 10: Internal Connectors

    Internal Connectors 33 12 ATX_12V CPU_FAN FPD_PWR SYS_FAN DMIC_CON SATA3_0/1 F_AUDIO SATA_PWR SPKR SPEAKER BAT_CON FUSB20_1/FUSB20_2 F_PANEL COMA/COMB/COME/COMF VGA_CONN COMC/COMD LPT_GPIO COMA/B/C/D/E/F_PW LPT_SEL GPIO_PWRSEL CLR_CMOS GPIO_SET SMBUS LVDS BL_SW LCD_VCC BIOS_SET MON_SW Read the following guidelines before connecting external devices: •...
  • Page 11 1) ATX_12V (2x2 12V Power Connector) This connector can be used to input power when the DC power jack on the rear panel is not connected. However, if the DC power jack is connected, this connector can only be used to output power. When used to input power: When used to output power: Pin No.
  • Page 12 5) SATA_PWR (SATA Power Connector) This connector provides power to installed SATA devices. Pin No. Definition +12V 6) BAT (Battery) The battery provides power to keep the values (such as BIOS configurations, date, and time information) in the CMOS when the computer is turned off. Replace the battery when the battery voltage drops to a low level, or the CMOS values may not be accurate or may be lost.
  • Page 13 8) F_PANEL (Front Panel Header) Connect the power switch, reset switch, and system status indicator on the chassis to this header according to the pin assignments below. Note the positive and negative pins before connecting the cables. RES+ Reset Switch Power Switch RES- PLED-...
  • Page 14 10) LPT_GPIO (LPT/GPIO Header) Use this header to connect a LPT or GPIO device. Refer to the descriptions of the LPT_SEL and GPIO_ PWRSEL jumpers below for further configuration. LPT: Pin No. Definition Pin No. Definition Pin No. Definition 26 25 STB- ACK- AFD- BUSY ERR- INIT- SLCT...
  • Page 15 13) G PIO_SET (GPIO Status Configuration Jumper) Use this jumper to set the GPIO status of the LPT_GPIO header to HIGH or LOW. 1-2 Close: Set to HIGH level (3V) (Default) 2-3 Close: Set to LOW level. 14) LVDS (LVDS Header) LVDS stands for Low-voltage differential signaling, which uses high-speed analog circuit techniques to provide multigigabit data transfers on copper interconnects and is a generic interface standard for high- speed data transmission.
  • Page 16 16) LCD_VCC (LVDS Drive Voltage Jumper) This jumper can be used to provide different screen voltage settings. 1-2 Close: Set to 3V. (Default setting) 2-3 Close: Set to 5V. 17) MON_SW (Flat Panel Display Switch Header) This header allows you to connect an on/off switch for the display. Pin No.
  • Page 17 19) FPD_PWR (Flat Panel Display Power Select Jumper) The power select jumper can be used to select the working voltage of the flat panel display. Make use your flat panel display supports DC In power. If not, use a DC In power adapter that meets the voltage requirements of your flat panel display.
  • Page 18 22) SPKR (Speaker Header) This header connects to the L/R Audio output of the motherboard and supports 3W stereo speaker (4 Ohm) in an AIO chassis. Pin No. Definition Speaker OUT R- Speaker OUT R+ Speaker OUT L- Speaker OUT L+ 23) SPEAKER (Buzzer Header) Connects to the buzzer on the chassis front panel.
  • Page 19 25) COMA/COMB/COME/COMF (Serial Port Headers) Each COM header can provide one serial port via an optional COM port cable. For purchasing the optional COM port cable, please contact the local dealer. RS232 device: Pin No. Definition NDCD- NDSR- NSIN NRTS- NSOUT NCTS- NDTR-...
  • Page 20 28) CI (Chassis Intrusion Header) This motherboard provides a chassis detection feature that detects if the chassis cover has been removed. This function requires a chassis with chassis intrusion detection design. Pin No. Definition Signal 29) CLR_CMOS (Clear CMOS Jumper) Use this jumper to clear the BIOS configuration and reset the CMOS values to factory defaults. To clear the CMOS values, use a metal object like a screwdriver to touch the two pins for a few seconds.
  • Page 21 32) M.2 (M.2 Socket 3 Connector) The M.2 connector supports M.2 SATA SSDs or M.2 PCIe SSDs. Follow the steps below to correctly install an M.2 SSD in the M.2 connector. Step 1: Locate the proper mounting hole for the M.2 SSD to be installed and then install the mounting clip first. Step 2: Slide the M.2 SSD into the connector at an angle. Step 3: Press the M.2 SSD down and then secure it by pressing the clip pin into the mounting hole.

  • Page 22: Chapter 2 Bios Setup

    Chapter 2 BIOS Setup BIOS (Basic Input and Output System) records hardware parameters of the system in the CMOS on the motherboard. Its major functions include conducting the Power-On Self-Test (POST) during system startup, saving system parameters and loading operating system, etc. BIOS includes a BIOS Setup program that allows the user to modify basic system configuration settings or to activate certain system features.

  • Page 23: Main

    Main Once you enter the BIOS Setup program, the Main Menu (as shown below) appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. Main Menu Help The on-screen description of a highlighted setup option is displayed on the bottom line of the Main Menu. Submenu Help While in a submenu, press <F1>...

  • Page 24: Advanced

    Advanced Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc. Advanced Security Boot Save & Exit Main OnBoard LAN Controller [Enabled] OnBoard LAN Controller#2 [Enabled] Soft-Off by PWR-BTTN [Instant-off] Primary Display [IGD] PCIE VGA Workaround [Disabled] [Disabled] LVDS Panel Resolution [1024x768 8-bit] ` Realtek PCIe GBE Family Controller (MAC:1C:1B:0D:6D:B0:71)
  • Page 25 ` Realtek PCIe GBE Family Controller This sub-menu provides information on LAN configuration and related configuration options. ` Trusted Computing Enables or disables Trusted Platform Module (TPM). ` IT8686 Super IO Configuration This section provides information on the super I/O chip and allows you to configure the parallel port. ` Hardware Monitor & CPU Temperature/System Temperature Displays current CPU/system temperature. & System Fan Speed Displays current system fan speeds. &...
  • Page 26 & C-States Enables or disables support for C-States. (Default: Enabled) & Enhanced C-states Allows you to determine whether to let the CPU enter C states. When enabled, the CPU core frequency will be reduced during system halt state to decrease power consumption. This item is configurable only when C-States is enabled. (Default: Enabled) & Active Processor Cores Allows you to select the number of CPU cores to enable.
  • Page 27 & Storage Allows you to select whether to enable the UEFI or legacy option ROM for the storage device controller. Do not launch Disables option ROM. Enables UEFI option ROM only. (Default) UEFI Enables legacy option ROM only. Legacy This item is configurable only when CSM Support is set to Enabled. &...

  • Page 28: Security

    Security Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc. Advanced Security Boot Save & Exit Main Password Description If ONLY the Administrator's password is set, then this only limits access to Setup and is only asked for when entering Setup. If ONLY the User's password is set, then this is a power on password and must be entered to boot or enter Setup.
  • Page 29 & Attempt Secure Boot Enables or disables the secure boot function. Secure Boot requires all the applications that are running during the booting process to be pre-signed with valid digital certificates. This way, the system knows all the files being loaded before Windows 8 loads and gets to the login screen have not been tampered with. (Default: Disabled) & Secure Boot Mode Allows you to configure the secure boot mode. (Default: Customized) ` Key Management This section provides you with configuration options for secure boot key management. - 29 -...

  • Page 30: Boot

    Boot Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc. Main Advanced Security Boot Save & Exit Boot Configuration Setup Prompt Timeout Bootup NumLock State [On] Full Screen LOGO Show [Enabled] Boot Option Priorities Fast Boot [Disable] New Boot Option Policy [Default] gf: Select Screen hi: Select Item...
  • Page 31 & VGA Support Allows you to select which type of operating system to boot. Enables legacy option ROM only. Auto EFI Driver Enables EFI option ROM. (Default) This item is configurable only when Fast Boot is set to Enabled. & USB Support All USB devices are disabled before the OS boot process completes. Disabled Full Initial All USB devices are functional in the operating system and during the POST.

  • Page 32: Save & Exit

    Save & Exit Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc. Main Advanced Security Boot Save & Exit Save Options Save Changes and Exit Discard Changes and Exit Save Changes Discard Changes Default Options Restore Defaults Save as User Defaults Restore User Defaults gf: Select Screen Boot Override...

  • Page 33: Chapter 3 Appendix

    Chapter 3 Appendix Drivers Installation • Before installing the drivers, first install the operating system. • After installing the operating system, insert the motherboard driver disk into your optical drive. Click on the message "Tap to choose what happens with this disc" on the top-right corner of the screen and select "Run Run.exe."...

  • Page 34: Regulatory Statements

    Regulatory Statements Regulatory Notices This document must not be copied without our written permission, and the contents there of must not be imparted to a third party nor be used for any unauthorized purpose. Contravention will be prosecuted. We believe that the information contained herein was accurate in all respects at the time of printing.
  • Page 35 FCC Notice (U.S.A. Only) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 36: Contact Us

    Contact Us GIGA-BYTE TECHNOLOGY CO., LTD. Address: No.6, Baoqiang Rd., Xindian Dist., New Taipei City 231, Taiwan TEL: +886-2-8912-4000, FAX: +886-2-8912-4005 Tech. and Non-Tech. Support (Sales/Marketing) : https://esupport.gigabyte.com WEB address (English): https://www.gigabyte.com WEB address (Chinese): https://www.gigabyte.tw GIGABYTE eSupport • To submit a technical or non-technical (Sales/Marketing) question, please link to: https://esupport.gigabyte.com...
