Page 1 EVOLUTION OF POWER AMPLIFIERS M1600.2 / M3200.2 M1000.4 / M1400.4 / M2000.4 M1500.1D / M2500.1D / M4000.1D...
Page 2: Table Of Contents
Autotek is proud to introduce the finest high end car audio products available and would like to thank you for your continued support. The Mean Machine Series products have been designed to a very high level of performance, with features unavailable in any other products.
Page 3: General Installation Procedure
GENERAL INSTALLATION PROCEDURE System Design The success of any car stereo system relies on several factors, such as the system design, execution of the installation, and system setup. Please remember that any system is only as good as its weakest link. Please remember that higher power systems are not necessarily useful purely for high sound pressure levels, but also to establish a headroom capability, to reproduce musical peaks cleanly without distortion.
Page 4: Amplifier Feature Descriptions
LINE OUTPUT: The line output passes through signal from the line inputs which allows you to daisy chain multiple amplifiers from one signal. - All Autotek amplifiers feature a comprehensive diagnostic system, with speaker lead short circuit, and amplifier DC faults indicated by the red “PROTECT” LED.
Page 5: M1600.2 / M3200.2 2 Channel Amplifier Applications
N/A for full range operation. FULL RANGE STEREO LINE INPUT MONO This application illustrates the basic mono bridging method for all Autotek amplifiers. Interconnect cable checklist: A MONO signal source is required, such as would be available from the mono sub bass output of an active crossover, whether stand alone, or built into a head unit or equalizer.
Page 6: M1000.4 / M1400.4 / M2000.4 4-Channel Amplifier Applications
Here we show how to use the 4 channel amplifiers as a 3 channel unit by taking advantage of the mono bridging capability of all Autotek amplifiers. The following example shows how to create a 3 channel system by mono bridging channel pair 3 / 4.
Page 7 M1000.4 / M1400.4 / M2000.4 4-CHANNEL AMPLIFIER APPLICATIONS Front/Rear high pass, using a 2 channel amplifier for mono sub bass The combination of a 2 and a 4 channel amplifier, utilizing their built in crossovers, makes it a snap to put together a full system with front and rear highs, with mono sub bass.
Page 8: M1500.1D / M2500.1D / M4000.1D / 1-Channel Amplifier Applications
M1500.1D / M2500.1D / M4000.1D MONO AMPLIFIER APPLICATION Basic application These sub bass amplifiers can be used in any of the bi-amplification systems described in this manual, replacing the 2 channel amplifiers as per the illustrations. Interconnect cable checklist: Connect the inputs to a suitable source, e.g. a head unit with good quality RCA cables. Connect the LINE OUT to the inputs of the system highs amplifier.
Page 10: Setting Up Systems After Installation For Best Performance
SETTING UP SYSTEMS AFTER INSTALLATION FOR BEST PERFORMANCE M1600.2 / M3200.2 / M1000.4 / M1400.4 / M2000.4 General: At this point you are ready to get more specific on the settings for your amplifier. High Pass: -When in Hi Pass operation, this setting acts as a low frequency cut off for your system reproduction. The point that you set it at cuts off any frequencies from reproduction beyond this point.
Page 11: Troubleshooting And Diagnostics
The key to finding the problem in a misbehaving sound system is to isolate parts of that system in a logical fashion to track down the fault. Description of the PROTECT system built into all Autotek amplifiers The diagnostic system will shut down the amplifier, until reset by turning the head unit off, and back on. This state of affairs will be indicated by the front panel PROTECT LED lighting up under the following conditions: 1 - A sort circuit on the loudspeaker leads.
Page 12: Product Warranty
Maxxsonics Limited Warranty As the manufacturer of Maxxsonics, Autotek, Crunch, MB Quart and Hifonics car audio products Maxxsonics USA Inc. Warrants to the original consumer purchaser the amplifier to be free from defects in material and workmanship for one (1) Year from date of purchase.
Page 13 MX-1 Premium High To Low Level Converter * Converts High Level OEM speaker wires to Ultra Clean RCA Low Level Outputs * High Level Inputs: Accepts all types of High level Inputs including floating ground and high voltages up to 30 volts. * Audio Signal Sense / Hardwire Turn-On: Audio sense detects music signals from the OEM wires and activates the MX-1.
Page 14 SLAVE MASTER MODE INPUT LEVEL Accessories 35Hz 250Hz LOW PASS RED - CLIP OUTPUT FILTER GREEN - 9V LEVEL 24 dB/OCT MAXX-LINK MLX-100 0.2V +10 dB PHASE BOOST PARAMETRIC BASS EQ -6dB BYPASS -20dB NORMAL LEVEL 15Hz 35Hz TEST TONE SUBSONIC 65Hz FILTER...
Page 16 PART: A0910...
