1. CONFIGURATION

NO
1
2
3
4 NUMERIC KEY BUTTON
5
6
7
8 HOUSEHOLE CALL BUTTON
9 NAME SEARCH BUTTON
※ Proximity sensor
- OLED screen turns on automatically when a person approaches within a certain distance (1m).
※ Precautions for using proximity sensor
- If the outdoor temperature is below -20 ℃, the proximity sensor may not operate.
4
NAME
SPEAKER
PROXIMITY SENSOR
RF CARD READER
PROGRAM BUTTON
CAMERA
LED
NO
10 ELECTRONIC KEY BUTTON
11 GUARD CALL
12 CALL BUTTON
13
14 LAN PORT
15 DOOR OPEN
16 DC 14V
NAME
MIC
