- Page 1 OWNER’S MANUAL & INSTALLATION GUIDE APPLICABLE MODELS: CP-CS-5810XTR2 Series PLEASE READ THIS MANUAL CAREFULLY BEFORE ATTEMPTING INSTALLATION. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY AFFECT THE PERFORMANCE OF YOUR SYSTEM, VOID YOUR WARRANTY, AND RESULT IN PROPERTY DAMAGE.
- Page 2 They also protect your skin and hair from the damaging effects of chlorine. The brain of your ClearPlus™ system is the Fleck 5810XTR2 control valve. It is manufactured by one of the world’s premier water treatment companies. The Fleck 5810 control valve is well respected for its reliability, serviceability, simple operation, and value.
-
Page 3: Table Of Contents
Table of Contents: GENERAL WARNINGS ……………………………………………………………………………………………...….. …….. OPERATING CONDITIONS …………………………………………………………………………………………….…... INSTALLATION ………………………………………………………………………………………………………….…..…..….. Step 1 – Pre-Installation Inspection ……………………………………………………………..……… Step 2 – Selecting an Installation Location ………………………………………………..…..Step 3 – Prepare Treatment Tank ………………………………………………………………..……… Step 4 – Turn off the Water & Electric Water Heaters ………………………………….… Step 5 –... -
Page 4: General Warnings
GENERAL WARNINGS Do not allow children or pets to play on or around the water filter. Do not install or store this filter system where it will be exposed to freezing temperatures. Do not tamper with controls. Do not repair, replace, or attempt to service any part of the system unless specifically instructed to in this manual and you have the understanding, tools, and skills necessary to carry out the procedure. -
Page 5: Operating Conditions
Range 5.0*** to 9.0 * While the ClearPlus™ Carbon system is built to withstand pressures exceeding 90 PSI, if your water pressure is greater than 70 PSI, we recommend that you have a certified plumber install a pressure reducing valve ahead of the ClearPlus™ system. -
Page 6: Installation
ClearPlus™ Carbon Ultimate Series Flow Rates & Backwash Requirements: Optimal Maximum Backwash Flow Rate Backwash Flow Rate Service Flow Service Flow at 40F Water Temp at 70F Water Temp Model Rate* (GPM) Rate* (GPM) (GPM) (GPM) CP-CS-5810XTR2-8-44 CP-CS-5810XTR2-9-48 CP-CS-5810XTR2-10-54 11.8 CP-CS-5810XTR2-12-52 13.8... -
Page 7: Step 1 - Pre-Installation Inspection
Step 1. – Pre-Installation Inspection Inspect all of the components that you received with your unit. You should have received the following: 1. Fleck 5810 XTR2 Control Valve 2. Media Tank 3. Upper Screen 4. Bypass Assembly w/ Bypass Valve and 1”... - Page 8 IF YOU HAVE OTHER WATER TREATMENT EQUIPMENT, YOU SHOULD DISCUSS THE ORDER OF YOUR TREATMENT EQUIPMENT WITH YOUR DEALER PRIOR TO INSTALLATION. Select a location for installation of your water filter that is within close proximity to the main incoming water line of the home. The location should have a firm, level surface with enough space for the unit itself and sufficient space surrounding the unit to facilitate maintenance.
-
Page 9: Step 3 - Prepare Treatment Tank
Step 3. – Prepare Treatment Tank Two types of media are supplied with your ClearPlus™ Carbon system: gravel which forms the base layer (underbedding) in your treatment tank, and activated carbon. Place the tank in the location where it will sit when the installation is complete. Note that the black base of your tank is not permanently attached to the rest of the tank. - Page 10 longer than the tank height works well as a leveling tool if you need it. Ensure that the riser tube remains centered in the opening at the top of the tank. Once this is complete, add the carbon media in the same manner. Use all of the media provided.
-
Page 11: Step 4 - Turn Off The Water & Electric Water Heaters
DO NOT INITIATE A REGENERTION OF THIS SYSTEM FOR A MINIMUM OF 2 HOURS AFTER ADDING THE WATER TO ALLOW ADEQUATE PRE-SOAKING. BACKWASHING BEFORE THE MEDIA IS SATURATED MAY CAUSE A LOSS OF MEDIA AND POTENTIAL DAMAGE TO THE CONTROL VALVE. Attach the upper screen to the underside of the control valve. -
Page 12: Step 5 - Prepare And Install Inlet And Outlet Plumbing Connection
Turn off the household main water shutoff valve. Open several plumbing fixtures inside the home as well as the outside faucets to drain as much water out of the plumbing system as possible. Following completion of the entire installation, restore the water flow by turning on the household main water valve and allow all air to be purged from the plumbing system before turning the power back on to your water heater. - Page 13 TEFLON® TAPE IS THE ONLY SEALANT TO BE USED ON THE 1” NPT CONNECTOR YOKES AND DRAIN FITTINGS. The system’s control valve is connected to your incoming and outgoing water lines by way of a bypass assembly with 1”NPT threaded fittings. This assembly is composed of the bypass valve and two 1”NPT connector yokes.
-
Page 14: Step 6 - Drain Line Installation
LOCAL CODES. THE DRAIN LINE SHOULD NOT BE EXPOSED TO FREEZING TEMPERATURES. During the backwash cycle, your ClearPlus™ Carbon filter will send captured contaminants out the drain port. This port needs to be connected to a suitable household drain, ideally within 20 feet of your media tank. - Page 15 Locate the drain port on the back of your control valve. The drain line flow control assembly (DLFC) is pre-attached to the control valve. For backwash flow rates of 7 GPM or less, the DLFC will be a black plastic elbow housing with 3/4 inch male NPT threads. This housing contains a flow control washer that limits the backwash flow rate.
-
Page 16: Step 7 - Control Valve Set-Up
Using an appropriate fitting, connect the drain line flow control to your drain line tubing/pipe. The DLFC can be removed from the control valve to facilitate easier plumbing if desired. To remove the drain line flow control, pull on the retaining clip to remove it and then grasp the drain line flow control and pull outward. - Page 17 The following is the primary “Home Screen” or Main Menu: Items displayed in blue or grey can be touched to edit or obtain more information. Items displayed in black are for information purposes only and cannot be selected. In the top left corner of the screen, you will find the current day of the week and time. In the top right corner, there is an indicator that will tell you when the next “regeneration”...
- Page 18 Diagnostics: Select this icon to enter the Diagnostics Mode - see Diagnostics Mode below for more details. Settings: Select this icon to edit the time of day that the flush cycle will occur. Other programming functions can be accessed using this icon, however, it is strongly recommended that you do not change any settings without first discussing with your dealer.
-
Page 19: Step 8 - Initial Start-Up And Leak Testing
To cancel your changes and return to the home screen, press the “X” icon at any time. Your ClearPlus™ system has been pre-programmed to backwash every 5 days or 2,000 gallons (whichever occurs first) and to perform the backwash process at 12:30am in the morning when it is very unlikely that water will be required in the building. - Page 20 When the system returns to service mode, slowly open a nearby cold water tap (after the ClearPlus™ system) and let the water run for 5 to 10 minutes until the system is purged of all air that may have resulted from the installation, and the water is running clear. Repeat for other faucets in the building starting at the highest elevation and working down to the lowest point until all air is purged.
-
Page 21: Backwash
Congratulations! Your system is now ready to provide treated water to your home! BACKWASH The backwash process is automatically engaged and controlled by your Fleck 5810XTR2 valve. Your system was pre-programmed at the factory. In most cases, your system will be programmed to backwash every 5 days, or 2,000 gallons (whichever occurs first) at 12:30am. -
Page 22: Changing Time Of Day
Skip through backwash steps: There may be times that it may be desirable to skip through backwash steps without allowing them to fully complete. This would be most typical during servicing. When a cycle engages, always wait until the motor has stopped before skipping to the next cycle. You can hear the valve motor while it is repositioning the valve at the beginning of each cycle. -
Page 23: Changing Basic Settings
Touch the grey box associated with the year. 2 blue arrows will appear. Touch the blue arrow on the left to decrease the year. Touch the blue arrow on the right to increase in the year. Adjust the year by touching the arrows until it is correct. Similarly, touch the grey boxes associated with the month and day and use the arrows to adjust the month and day settings until they are correct. -
Page 24: Diagnostics
To adjust the time of day that the flush cycles will occur, touch “regen. time” and two blue arrows will appear. Touch the arrow on the left to adjust to an earlier time, and the arrow on the right to adjust to a later time. When you are satisfied that all of the settings are correct, press the CHECKMARK ICON in the bottom right corner of the screen. - Page 25 left arrow on the top left of the screen. You can return to the home screen at any time by pressing the HOME ICON on the bottom right corner of the screen. The first screen displays the following diagnostic information: Flow Rate: This is the current flow rate of water through the system in gallons per minute.
-
Page 26: Master Settings Mode
MASTER SETTINGS MODE THE MASTER PROGRAMMING MODE IS DESIGNED FOR PROFESSIONAL USE ONLY. UNLESS DIRECTED BY A WATER TREATMENT PROFESSIONAL FAMILIAR WITH THE SYSTEM, IT IS STRONGLY RECOMMENDED THAT YOU DO NOT MODIFY ANY OF THE MASTER PROGRAMMING MODE SETTINGS To enter the Master Settings Mode, select the SETTINGS ICON from the home screen, then select the SETTINGS ICON again. -
Page 27: Operation During A Power Failure
RELAY Parameter Setting auxiliary 1 auxiliary 2 Aux. 1 Cycle Based treatment rapid rinse backwash draw tank refill pause Aux. 2 Cycle Based treatment rapid rinse backwash draw tank refill pause METER Parameter Setting meter type 1.25” turbine generic plumbing leak detect OPERATION DURING A POWER FAILURE The 5810XTR2 valve/controller includes integral power backup. -
Page 28: Maintenance & Troubleshooting
If power fails while the unit is in backwash, the control will save the current valve position before it shuts down. When power is restored, the control will resume the backwash cycle from the point where power failed. Note that if power fails during a backwash cycle, the valve will remain in its current position until power is restored. -
Page 29: Warranty Information
WARRANTY INFORMATION ClearPlus™ Carbon systems are backed by a comprehensive warranty program. The Fleck 5810XTR2 control valve and related bypass assembly and media tank are manufactured by Pentair LLC and are subject to Pentair LLC’s Limited Warranty. See Pentair’s Limited Warranty for details. - Page 30 HomePlus Products Inc. Toll free: 1-866-376-2690 Subject to the limitations noted below, all other components of the ClearPlus™ system are warranted by HomePlus Products Inc. to be free of defects in material and workmanship for a period of 1 year except as noted**.
- Page 31 This warranty does not apply to the following situations: misuse; normal wear and tear; neglect; unauthorized repair or damage caused through installation, adaptation, or modification; use in an improper manner or manner inconsistent with the manufacturer's installation, operating, and maintenance instructions; misapplication; wear or deterioration due to environmental conditions;...
- Page 32 MANUFACTURED BY: HomePlus Products Inc. 5-1490 Pearson Place Kamloops, BC V1S 1J9 Canada Phone: 250-374-2690 Fax: 250-374-2692 www.homeplusproducts.com...
