ClearPlus WH2-HF Manual

WH2-HF
High Flow Series Premium Multi-Stage
Whole House Filter System w/ 5 Micron Carbon Block

Package Contents:

two (2) heavy-duty Pentek Big Blue 20" filter housing (1" NPT) w/ pressure relief buttons
•
one (1) mounting bracket and related lag bolts and washers
•
one (1) Hydronix SDC-45-2010 multi-gradient sediment filter
•
one (1) Pentek EP-20BB 5 micron carbon block filter
•
one (1) 1" housing coupler used to join the 2 filter housings
•
one (1) spanner wrench & one (1) roll of Teflon tape
•
The WH2-HF high-flow series whole house filter package features dual stage filtration for a wide range of
common contaminants that affect the clarity, taste, and odor of residential water.
for customers seeking higher than average water flow rates and less pressure drop. This system features
Hydronix's unique multi-depth poly sediment filter. This filter uses the entire depth of its media by trapping
the largest sediment particles on the outside of the filter, then gradually stepping down the size of particles it
will reject as the water moves closer to the core of the filter, finally ending at 10 microns. The result is longer
filter life and higher flow rates (less pressure drop). The polypropylene media is highly resistant to bacteria,
making this an excellent choice for well water treatment applications.
This filter is followed by Pentek's EP Series 5 micron carbon block filter which features greater chlorine
removal and dirt-holding capacity than competitor's filters of a similar size. The high porosity-design helps
prevent the cartridge from clogging before its absorption capacity is exhausted, maximizing the utilization of
the activated carbon media. The carbon block filter has excellent chlorine reduction characteristics and is
also commonly used to remove chlorine disinfection by-products (THM's), and a wide range of organic and
volatile organic compounds (VOC's) that affect water clarity, taste, and odor. Minimum chlorine reduction of
90% at over a filter life of 40,000 gallons at a flow rate of 4 GPM (151,400 L @ 15.1 LPM). This system is
also a popular choice for well water owners requiring filtration down to a level of 5 microns for a whole house
UV sterilizer, especially where elevated levels of organic contaminants are present (organic contaminants can
absorb UV light).
Housing Material:
Housing O-Ring Material:
Housing Pressure Drop:
SDF-45-2010 Filter Pressure Drop:
Pentek EP-20BB Filter Pressure Drop:
Maximum Recommended Flow Rate:
Recommended Operating Temp. Range:
Maximum Recommended Pressure:
Specifications
Polypropylene
Buna-N
1 PSI at 15 Gallons Per Minute (0.1 bar at 57 LPM)
1 PSI at 20 Gallons Per Minute (0.1 bar at 76 LPM)
2.5 PSI @ 4 Gallons Per Minute (0.17 bar @ 15.1 LPM)
6 Gallons Per Minute (23 LPM)
40-100˚F (4.4 to 37˚C)
90 PSI (6.2 bar)
It is designed specifically
