WH1-HF
High Flow Series Whole
House 10 Micron Sediment
Filter Package
Package Contents:
one (1) heavy-duty Pentek Big Blue 20" filter housing (1" NPT) w/ pressure relief button
•
one (1) mounting bracket and related screws
•
one (1) Hydronix SDC-45-2010 multi-gradient sediment filter cartridge
•
one (1) spanner wrench
•
This high capacity whole house filter package is designed specifically to remove sediments down
to a level of 10 microns thereby improving water clarity, taste, and odor, and protecting your
home's plumbing system (including other water treatment equipment) from damage and pre-
mature clogging due to sediment build-up. This package features Hydronix's unique SDC Series
multi-gradient sediment filter. This filter uses the entire depth of its media by trapping the largest
sediment particles on the outside of the filter, then gradually stepping down the size of particles it
will reject as the water moves closer to the core of the filter. The outer layer is rated at 75
microns. The subsequent layers are rated at 50 microns, 25 microns, and finally 10 microns. The
result is longer filter life, greater dirt-holding capacity, higher flow rates, and remarkably low
pressure drop. The 100% pure polypropylene media is highly resistant to bacteria, making this an
excellent choice for both well water and municipal water treatment applications.
Housing Material:
Housing O-Ring Material:
Housing Pressure Drop:
Filter Pressure Drop:
Maximum Recommended Flow Rate:
Recommended Operating Temp. Range:
Maximum Recommended Pressure:
Note: We recommend that this product be installed by a professional plumber. If you
install this product yourself, please ensure that your installation meets all local building
and plumbing codes. The following instructions are meant only as a general guide and
should not be considered a substitution for your local plumbing and / or building codes.
Specifications
Polypropylene
Buna-N
1 PSI at 15 Gallons Per Minute (0.1 bar at 57 LPM)
1 PSI at 20 Gallons Per Minute (0.1 bar at 76 LPM)
20 Gallons Per Minute (76 LPM)
40-100˚F (4.4 to 37˚C)
90 PSI (6.2 bar)
