King Industrial KRF-J30 Instruction Manual
King Industrial KRF-J30 Instruction Manual

King Industrial KRF-J30 Instruction Manual

Industrial t-square rip fence systems

Advertisement

Quick Links

INDUSTRIAL T-SQUARE
RIP FENCE SYSTEMS
MODEL: KRF-J30 (30" Max Rip)
MODEL: KRF-J52 (52" Max Rip)
INSTRUCTION MANUAL
COPYRIGHT © 2010 ALL RIGHTS RESERVED BY KING CANADA TOOLS INC.

Advertisement

loading
Need help?

Need help?

Do you have a question about the KRF-J30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for King Industrial KRF-J30

  • Page 1 INDUSTRIAL T-SQUARE RIP FENCE SYSTEMS MODEL: KRF-J30 (30” Max Rip) MODEL: KRF-J52 (52” Max Rip) INSTRUCTION MANUAL COPYRIGHT © 2010 ALL RIGHTS RESERVED BY KING CANADA TOOLS INC.
  • Page 2: Warranty Information

    WARRANTY INFORMATION 2-YEAR KING CANADA TOOLS LIMITED WARRANTY OFFERS A 2-YEAR LIMITED WARRANTY FOR THIS RIP FENCE SYSTEM FOR INDUSTRIAL USE. PROOF OF PURCHASE Please keep your dated proof of purchase for warranty and servicing purposes. REPLACEMENT PARTS Replacement parts for this product are available at our authorized King Canada service centers across Canada. LIMITED TOOL WARRANTY King Canada makes every effort to ensure that this product meets high quality and durability standards.
  • Page 3: General Safety Instructions For Power Tools

    GENERAL SAFETY INSTRUCTIONS FOR POWER TOOLS 1. KNOW YOUR TOOL 12. ALWAYS WEAR SAFETY GLASSES. Read and understand the owners manual and labels affixed to Always wear safety glasses (ANSI Z87.1). Everyday eyeglasses the tool. Learn its application and limitations as well as its only have impact resistant lenses, thet are NOT safety glasses.
  • Page 4: Assembly And Adjustments

    ASSEMBLY AND ADJUSTMENTS INSTALLING FRONT RAIL AND TUBE ASSEMBLY Place and align the mounting holes of the front rail and tube assembly (A) Fig.1 with the holes in the front lip of the table (C) and extension wings (D & E). Install the front rail and tube assembly to the table and extension wings using 4 countersunk head bolts, 8 washers, 4 spring washers and 4 hex.
  • Page 5 ASSEMBLY, ADJUSTMENTS & PARTS DIAGRAM INSTALLING MEASURING TAPE ON GUIDE TUBE Caution! Only proceed with the following step once the rip fence system has been adjusted and that the fence is set perfectly parallel with the saw blade. See “Adjusting Rip Fence” section on the previous page for instructions. Slide the fence against the saw blade.
