SAFETY INFORMATION GENERAL SAFETY RULES READ ALL INSTRUCTIONS CAREFULLY W A R N I N G This symbol indicates important safety instructions. If these instructions are not followed, it could endanger the personal safety and/or property of the operator and others. Read and understand all instructions in this manual before attempting to operate the mower.
Page 4
– Store indoors, and do not expose to rain or water, avoid direct sunshine. – When servicing, use only identical replacement parts. – Only to be used with Greenworks GMAX 40V Batteries. See instruction manual for additional battery packs. • Carefully read all instructions on the mower and in the manual before attempting to assemble and operate the mower.
Page 5
SAFETY INFORMATION • Mow only in daylight or in good artificial light. Do not rush a mowing job. • Stop the blade when crossing gravel driveways, walkways, or roads. • If the mower starts to vibrate excessively, stop the motor and check for the cause immediately. Vibration is generally a sign the mower is not functioning properly.
Page 6
C A U T I O N Use only greenworks approved replacement batteries, other batteries may cause injury or damage to the mower. Only to be used with Greenworks GMAX 40V Batteries. BATTERY SAFETY RULES • Battery tools do not have to be plugged into an electrical outlet; therefore, they are always in operating condition.
Page 7
SAFETY INFORMATION • Always remove battery pack from your tool when you are assembling parts, making adjustments, cleaning, or when not in use. Removing battery pack will prevent accidental starting that could cause serious personal injury. • Always remove battery pack before storing the device. When battery becomes fully charged, unplug the charger from the power supply and remove the battery pack from the charger.
Page 8
SAFETY INFORMATION W A R N I N G When transporting or servicing unit, always remove the battery. W A R N I N G ( P R O P O S I T I O N 6 5 ) Some dust created by power sanding, sawing, grinding, drilling and other construction activities contains chemicals known to the state of California to cause cancer, birth defects or other reproductive harm.
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second)
Page 10
SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, which, if not DANGER avoided, will result in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, WARNING could result in death or serious injury.
KNOW YOUR LAWN MOWER Read this operator's manual and safety rules before operating your lawn mower. Compare the illustration in Figure 1 to your lawn mower in order to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. Bail lever Upper handle Safety lock-out button...
ASSEMBLY INSTRUCTIONS PART NAME FIGURE PART NO. Lawn Mower Mulching Plug Side Discharge Chute Grass Catcher Bag Handle Knob Handle Bolt 21” 40V Brushless Mower MO40L02 Owner’s Manual Owner’s Manual TOLL-FREE HELPLINE: 1-888-90WORKS (888.909.6757) www.GreenWorksTools.com Read all safety rules and instructions carefully before operating this tool .
Page 13
ASSEMBLY INSTRUCTIONS UNPACKING • Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included. • Inspect the product carefully to make sure no breakage or damage occurred during shipping. •...
Page 14
ASSEMBLY INSTRUCTIONS UNFOLDING AND ADJUSTING LOWER HANDLE (See Figure 2) W A R N I N G Folding or unfolding the handle improperly can damage the cables, causing an unsafe operating condition. • Do not damage the cables when folding or unfolding the handle. •...
Page 15
ASSEMBLY INSTRUCTIONS INSTALLING THE UPPER HANDLE (See Figure 3) • Align the mounting holes on the upper handle (1) and the lower handle (2). Insert the carriage bolts (3) and use the knobs (4) to tighten them. Repeat the operation on the other side. (1) Upper handle (4) Knob (3) Bolt...
Page 16
ASSEMBLY INSTRUCTIONS INSTALLING THE GRASS CATCHER BAG (See Figure 4) • Lift the rear discharge door (1). • Lift the grass catcher by its handle (2) and place under the rear discharge door so that the hooks (3) on the grass catcher (4) are seated on the door rod (5). •...
Page 17
ASSEMBLY INSTRUCTIONS INSTALLING / REMOVING THE MULCHING PLUG (See Figure 5) • To remove the mulching plug, lift the rear discharge door (1). • Grasp the handle (2) of the mulching plug. Using this handle, lift and pull the mulch plug out. •...
Page 18
ASSEMBLY INSTRUCTIONS INSTALLING SIDE DISCHARGE CHUTE (See Figure 6) • Lift the side discharge cover (1). • Align the grooves (2) on the side discharge chute (3) with the pins (4) on the underside of the discharge cover. • Lower the discharge chute until the hooks on the mower deck are secured in the openings of the discharge chute.
Page 19
ASSEMBLY INSTRUCTIONS TO INSTALL THE BATTERY PACK (See Figure 7) • Lift and hold up the battery door (1). • Align the battery (2) with the mower’s battery port. • Make sure the battery release button snaps in place and that battery is fully seated and secure in the mower before beginning operation.
OPERATING YOUR LAWN MOWER STARTING/STOPPING THE MOWER (See Figure 8) To start the motor: • Open the battery door. • Install the battery. Insert the safety key. • Press and hold the safety lock-out button (1). • Pull the bail lever (2) upward to the handle to start the mower and release the button. To stop the motor: Release the bail lever.
Page 21
OPERATING YOUR LAWN MOWER CUTTING HEIGHT ADJUSTMENT (See Figure 9) When shipped, the wheels on the mower are set at the lowest cutting position. Before using the mower for the first time, raise the cutting position to the height best suited for your lawn. The average lawn should be between 1 1/2"...
Page 22
OPERATING YOUR LAWN MOWER SLOPE GAUGE (See Figure 10) W A R N I N G Slopes are a major factor related to accidents involving slips and falls, which can result in severe injury. Operating the mower on a slope requires extra caution. If you feel uneasy on a slope, do not mow it.
Page 23
OPERATING YOUR LAWN MOWER MOWING TIPS NOTE: A sharp blade will greatly enhance the performance of the mower, especially when cutting high grass. Be sure to check the blade and to sharpen it at least once per year, as described in the Maintenance section. •...
Page 24
OPERATING YOUR LAWN MOWER EMPTYING THE GRASS CATCHER BAG (See Figure 11) • Stop mower, allow blades to completely stop, and remove the battery. • Lift the rear discharge cover. • Lift the grass catcher bag by its handle to remove from mower. •...
ALWAYS remove the battery when servicing or transporting the mower. Use only a GREENWORKS replacement blade (Item#: 333041179). • REMOVE BATTERY. • While wearing leather padded gloves, wedge a block of wood between the blade and the mower deck in order to prevent the blade from turning when the bolt (1) is being removed.
Page 26
MAINTENANCE CLEANING THE MOWER W A R N I N G In order to reduce the risk of electric shock, do not expose the mower to water. The underside of the mower deck should be cleaned after each use, because grass clippings, leaves, dirt, and other debris will accumulate, which will cause rust and corrosion.
Page 27
MAINTENANCE VERTICAL STORAGE FUNCTION (See Figure 14) • Remove the battery from the mower. • Remove the grass catcher bag. • Rotate the handle knobs to the unlocked position. • Lower the handle assembly and rotate the handle knobs to the locked position. •...
Page 28
MAINTENANCE • When servicing the mower, use only identical replacement parts that are available from the manufacturer. In order to obtain replacement parts, call the toll-free helpline, at 1-888-909- 6757. The use of parts that do not meet the original equipment specifications may lead to improper performance, and may compromise safety.
ENVIRONMENTALLY SAFE BATTERY DISPOSAL The following toxic and corrosive materials are in the batteries used in this Lawn Mower: Lithium- Ion, a toxic material. W A R N I N G All toxic materials must be disposed of in a specified manner to prevent contamination of the environment.
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION The battery is not charged. Charge the battery. Replace the switch (call the tollfree helpline, The switch is defective. at 1-888-909-6757. Grass jammed between the Remove battery; check under deck for jams. deck and blade. The mower does Check the connection between the battery The battery is not fully inserted...
4 year consumer warranty against defects in materials, parts or workmanship. GREENWORKS™, at its own discretion will repair or replace any and all parts found to be defective, through normal use, free of charge to the customer. This warranty is valid only for...
PARTS LIST ITEM NO. PART NO. DESCRIPTION 311161571 Motor assembly 333021527 341191179-1 341241179C Side discharge chute 341331179U Bumper cover 32205836 Screw 341061179C Bumper main body 311201546 Side discharge cover assembly 333041179 21” Blade 322011179AC Bolt 3220951D Screw 333011179 21” Deck 32202390 Bolt 32204113D...
Page 34
PARTS LIST ITEM NO. PART NO. DESCRIPTION 3290506 Clip washer 332021179 Rear cover axle 332111179 Torsinal spring (rear cover) 33401222 Torsinal spring 3290135 Cotter pin 311011179 Rear wheel axle 342011179 Rear shield 3220505D Screw 332041179 Press board (rear shield) 341271179A 10”...
Page 35
Greenworks Tools PO Box 1238 Mooresville, NC 28115 TOLL-FREE HELPLINE: 1-888-909-6757 Rev: 00 (04-24-2017) Printed in China on 100% Recycled Paper...
Page 36
Podadora inalámbrica de 21 pulg. de 40 V MO40L01 Manual del Propietario LÍNEA DE AYUDA GRATUITA: 1-888-90WORKS (888.909.6757) www.GreenWorksTools.com Antes de hacer funcionar esta herramienta, lea cuidadosamente todas las reglas de seguridad y las instrucciones.
ÍNDICE Índice ........................... 2 Especificaciones del producto ..................... 2 Información sobre seguridad ....................3 Símbolos ..........................9 Conozca su podadora ......................11 Ensamblado ........................12 Funcionamiento ......................... 20 Mantenimiento ........................25 Eliminación de la batería que no daña el medio ambiente ..........29 Corrección de problemas ....................
INFORMACIÓN DE SEGURIDAD FUNCIONAMIENTO GENERAL GUARDAR ESTAS INSTRUCCIONES A D V E R T E N C I A Este símbolo indica instrucciones importantes de seguridad. Si no se siguen estas instrucciones, la seguridad o propiedad personal del operador y otras personas podrían verse en peligro. Lea y comprenda todas las instrucciones en este manual antes de intentar usar la podadora.
Page 39
– Use sólo piezas de recambio idénticas al realizar operaciones de mantenimiento o reparaciones. – Solo debe usarse con la bacteria Greenworks GMAX 40V. Ver el manual de instrucciones para otras baterías. • Lea atentamente todas las instrucciones en la podadora y este manual antes de intentar ensamblar y usar la podadora.
Page 40
INFORMACIÓN DE SEGURIDAD • Asegúrese de estar bien equilibrado. • Tire la podadora lentamente hacia usted. • No use la podadora en tareas que no sean para las que fue diseñada. No fuerce la podadora. • No haga funcionar el cortacésped bajo los efectos de alcohol o cualquier sustancia. •...
Page 41
P R E C A U C I Ó N Utilice baterías de repuesto aprobadas únicamente. Otras bateríaspueden ocasionar daños a la podadora. Úsese con baterías GREENWORKS GMAX 40V. NORMAS DE SEGURIDAD DE LA BATERÍA • No se necesita conectar a una toma de corriente las herramientas de baterías; por lo tanto, siempre están en condiciones de funcionamiento.
Page 42
INFORMACIÓN DE SEGURIDAD • No coloque herramientas de baterías ni las baterías mismas cerca del fuego o del calor. De esta manera se reduce el riesgo de explosiones y de lesiones. • No aplaste, deje caer o dañe la batería. Nunca utilice una batería o cargador que se ha caído, aplastado, recibido un golpe contundente o ha sido dañado(a) de alguna manera.
Page 43
INFORMACIÓN DE SEGURIDAD NORMAS DE SEGURIDAD PARA EL CARGADOR • Cargue la batería en lugares secos exentos de la influencia del clima. No exponga la podadora ni el cargador a la lluvia. No realice la carga en lugares húmedos. Use el cargador de la batería en temperaturas de entre 6°...
SÍMBOLO Algunos de los siguientes símbolos pueden ser usados en este producto. Obsérvelos y aprenda su signifi cado. Una correcta interpretación de estos símbolos le permitirá utilizar el producto mejor y de una forma más segura. SÍMBOLO DENOMINACIÓN/EXPLICACIÓN Voltios Voltaje Amperios Corriente Hertz...
Page 45
SÍMBOLO Las siguientes palabras de senalizacion y sus significados tienen el objeto de explicar los niveles de riesgo relaciondos con este producto. SÍMBOLO SEÑAL SIGNIFICADO Indica una situación peligrosa inminente, la cual, si no se evita, PELIGRO: causará la muerte o lesiones serias. CIIndica una situación peligrosa posible, la cual, si no se evita, ADVERTENCIA: podría causar la muerte o lesiones serias.
CONOZCA SU PODADORA Lea el manual del operador y las normas de seguridad antes de manejar la podadora. Compare la ilustración en Fig. 1 con la podadora para familiarizarse con la ubicación de los diferentes controles y ajustes. Guarde este manual para referencia futura. Libere la palanca Manija superior Botón de bloqueo...
INSTRUCCIONES DE ENSAMBLADO NOMBRE DE LAS PIEZAS FIGURA PARTE NO. Podadora Clavija para compuesto orgánico Conducto de descarga lateral Bolsa colectora de césped Perilla de la empuñadura Perno del asa 21” 40V Brushless Mower MO40L02 Manual Owner’s Manual TOLL-FREE HELPLINE: 1-888-90WORKS (888.909.6757) www.GreenWorksTools.com Read all safety rules and instructions carefully before operating this tool .
Page 48
INSTRUCCIONES DE ENSAMBLADO DESEMPAQUETADO • Extraiga cuidadosamente de la caja la herramienta y los accesorios. Asegúrese de que estén presentes todos los artículos enumerados en la lista de empaquetado. • Inspeccione cuidadosamente la herramienta para asegurarse de que no haya sufrido ninguna rotura o daño durante el transporte.
Page 49
INSTRUCCIONES DE ENSAMBLADO DESPLEGAR Y AJUSTAR EL MANGO INFERIOR (Consulte la figura 2) A D V E R T E N C I A Plegar y desplegar el mango incorrectamente puede dañar los cables y dar lugar a unas condiciones de funcionamiento inseguras. •...
Page 50
INSTRUCCIONES DE ENSAMBLADO INSTALACIÓN DEL MANGO SUPERIOR (Consulte la figura 3) • Alinee los agujeros para montar de la manija superior (1) y la manija inferior (2). Introduzca el perno (3) de cabeza de hongo y utilice las perillas (4) para apretarlos. Repita la operación por el otro lado.
Page 51
INSTRUCCIONES DE ENSAMBLADO COLOCACIÓN DEL COLECTOR DE CÉSPED (Consulte la figura 4) • Levante la puerta de descarga posterior (1). • Levante el colector de césped sujetándolo por el mango (2) y colóquelo debajo de la puerta trasera de descarga para que los ganchos (3) del colector de césped (4) queden asentados en la barra de la puerta (5).
Page 52
INSTRUCCIONES DE ENSAMBLADO INSTALACIÓN O RETIRO DE LA CLAVIJA PARA COMPUESTO ORGÁNICO (Consulte la figura 5) • Para quitar el tapón de la función para cubrimiento con hojarasca , levante la puerta de descarga posterior (1). • Sujete el mango (2) del adaptador para triturado. Usando este mango, eleve y tire el adaptador de triturado.
Page 53
INSTRUCCIONES DE ENSAMBLADO INSTALACIÓN DEL DEFLECTOR DE DESCARGA LATERAL (Consulte la figura 6) • Levante la puerta de descarga lateral (1). • Alinee las ranuras (2) del deflector (3) con los pasadores (4) de la parte inferior de la puerta. •...
Page 54
INSTRUCCIONES DE ENSAMBLADO PARA INSTALAR LA BATERÍA(Consulte la figura 7) • Levante y sostenga la tapa de la batería (1). • Alinee la batería (2) con el puerto de la batería de la podadora. • Asegúrese de que el botón de liberación de la batería trabe en su lugar y que la batería esté completamente asentada y asegurada en la podadora antes de empezar la operación.
INSTRUCCIONES DE USO ENCENDIDO /APAGADO DE LA PODADORA (Consulte la figura 8) Para arrancar la podadora: • Levante la tapa de la batería. • Instale la batería. Inserte la llave de seguridad. • Presione y mantenga presionado el botón de bloqueo para seguridad (1). •...
Page 56
INSTRUCCIONES DE USO AJUSTE DE LA ALTURA DE CORTE (Consulte la figura 9) Al enviarse el aparato, las ruedas en el cortacésped se ajustan a una posición de corte bajo. Antes de usar el cortacésped por primera vez, ajuste la posición del corte a la altura más adecuada para su cortacésped.
Page 57
INSTRUCCIONES DE USO MANEJO EN PENDIENTES (Consulte la figura 10) A D V E R T E N C I A Las pendientes son una de las causas principales de accidentes por resbalones y caídas accidentales que pueden provocar lesiones severas. El funcionamiento de la podadora en pendientes requiere tomar precauciones extraordinarias.
Page 58
INSTRUCCIONES DE USO CONSEJOS DE PODA NOTA: el rendimiento de la podadora será mucho mayor con una cuchilla filosa, especialmente si de corta césped alto.Asegúrese de revisar la cuchilla y afilarla al menos una vez al año, según se describe en la sección Mantenimiento.
Page 59
INSTRUCCIONES DE USO VACIADO DE LA BOLSA PARA ENSA CAR LA HIER BA (Consulte la figura 11) • Detenga la podadora de césped, deje que las hojas se detengan por completo y retire la batería. • Levante la cubierta de descarga trasera. •...
óxido y corrosión. Utilice solo una cuchilla de sustitución GREENWORKS (artículo n.º 333041179). • RETIRE LA BATERÍA.
Page 61
MANTENIMIENTO LIMPIEZA DE LA PODADORA A D V E R T E N C I A Para reducir el riesgo de descarga eléctrica, no exponga la podadora al agua. Se debe limpiar el lado inferior de la plataforma de la podadora después de cada uso, ya que se acumulan recortes de césped, hojas, suciedad y otros desechos, y producen óxido y corrosión.
Page 62
MANTENIMIENTO FUNCIÓN DE ALMACENAMIENTO VERTICAL (Consulte la figura 14) • Retire la batería del cortacésped. • Retire la bolsa de colector de césped. • Gire las perillas del mango a la posición de desbloqueo. • Baje el conjunto del mango y gire las manillas del mango a la posición de bloqueo. •...
Page 63
MANTENIMIENTO • Cuando repare la podadora, utilice únicamente piezas de repuestos disponibles del fabricante. Para obtener piezas de repuesto, llame a la línea de ayuda gratuita al 1-888-909- 6757. Si se utilizan piezas que no cumplen con las especificaciones del equipo original,es posible que el rendimiento sea inadecuado y se vea comprometida la seguridad.
ELIMINACIÓN DE BATERÍAS SIN DAÑO PARA EL AMBIENTE Los siguientes materiales tóxicos y corrosivos están en las baterías usadas en esta cortadora de césped: Litio-ión, un material tóxico. A D V E R T E N C I A Todos los materiales tóxicos deben ser desechados de forma específica para evitar contaminar el medio ambiente.
SOLUCIÓN DE PROBLEMAS PROBLEMA CAUSA POSIBLE SOLUCIÓN La batería no tiene carga. Cargue la batería. Reemplace el interruptor de control.(Llame a El interruptor de control está la línea telefónica gratis para ayuda 1-888- dañado. 909-6757. Quite beteria.Verifique bajo plataforma para Pasto pegado al lado de la asegurar que césped no sea atascado luego hoja.
GARANTÍA LIMITADA Por este medio y por un período de cuatro años GREENWORKS™ garantiza este producto contra defectos en materiales, piezas o mano de obra al comprador original que cuente con una prueba de compra. GREENWORKS™, a su sola discreción reparará o reemplazará, sin costo alguno para el cliente, cualquier pieza defectuosa, siempre y cuando se haya hecho uso normal de ella.
LISTA DE PIEZAS NO.D’ARTICLE NO. DE PIECE DESCRIPTION QTÉ 311161571 Conjunto del motor de 40 V 333021527 Bloc 341191179-1 Lámina 341241179C Conducto de descarga lateral 341331179U Conjunto de la cubierta de descarga lateral 32205836 Cubierta decorativa 341061179C Parachoques 311201546 Tornillo 333041179 Conjunto de la rueda de 8”...
Page 69
LISTA DE PIEZAS NO.D’ARTICLE NO. DE PIECE DESCRIPTION QTÉ 3290506 Conjunto de la bolsa del receptor de hierba 332021179 Conjunto de la rueda de 10” 332111179 Conjunto de la palanca de ajuste de la altura 33401222 Eje de la rueda trasera 3290135 mango superior 311011179...
Page 70
Greenworks Tools PO Box 1238 Mooresville, NC 28115 LÍNEA DE AYUDA GRATUITA: 1-888-909-6757 Rev: 00 (04-24-2017) Impreso en China en papel reciclado de 100%...
