Summary of Contents for CDA SL100SS
- Page 1 SL100SS Seven function electric oven Use and maintenance...
-
Page 2: Table Of Contents
Contents Important information First use of the oven Oven functions and operation Using the grill ECO heating Practical tips Cleaning and maintenance Changing the oven light bulb Installation Mains electrical connection Technical assistance Specifications Product fiche Product information IMPORTANT: Please read the user instructions carefully before using the appliance for the first time and before installing it. -
Page 3: Important Information
Any other use could be dangerous and may lead to premature failure of the appliance. The CDA Group Ltd. cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserves the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance. - Page 4 Appliance information Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model Serial Number...
-
Page 5: First Use Of The Oven
First use of the oven In order to remove oil residues accumulated during the manufacturing process and dust accumulated during storage and transport, we recommend a preliminary cleaning before first use. This is to protect your health and provide optimum quality in cooking. Preliminary heating 1. -
Page 6: Oven Functions And Operation
Oven functions and operation The ovens operations are controlled by the function selector knob on the right side of the control panel and the temperature selector knob on the left side. Please note: Only when the temperature has been selected will the oven begin to heat up. - Page 7 Oven functions and operation Oven is off Eco heating This is an optimised heating function designed to save energy. When using this function the oven light is intentionally left off. Fan oven This function uses the circular heating element with a temperature between 50°C and 250°C.
-
Page 8: Using The Grill
Using the grill Important! When using any grill function the oven door should be kept closed. When the grill is in use accessible parts can become hot; it is advisable to keep children away from the oven. In order to switch on the grill you need to: •... -
Page 9: Eco Heating
ECO heating ECO heating is an optimised heating function designed to save energy when preparing food. You cannot reduce the cooking time by setting a higher temperature; preheating the oven is not recommended. Do not change the temperature setting and do not open the oven door during cooking. -
Page 10: Practical Tips
Practical tips The times given in the table below apply to a dish that is placed in to a cold oven. For a preheated oventhe times should be reduced by 5 - 10 minutes. The figures given below are approximate and can be altered based on your own experience and cooking preferences. -
Page 11: Cleaning And Maintenance
Cleaning and maintenance Keeping your oven clean and well maintained helps to prolong it's fault-free lifespan. It is important that, before any cleaning or maintenance is performed, you switch off the oven at the mains supply. Do not start any cleaning or maintenance until the oven has been allowed to cool completely. - Page 12 Cleaning and maintenance Abrasive cleaning agents or scouring pads/cloths should not be used on the cavity surface. IMPORTANT: • Steam cleaners must not be used when cleaning this appliance • Once care and maintenance is complete, ensure that all parts are correctly replaced before using the oven Removing the appliance door In order to allow easier access into the oven cavity for cleaning, it is...
- Page 13 Cleaning and maintenance Replacing the appliance door • Hold the door to the appliance in the closed position and manoeuvre the hinges so that the part of the hinge, highlighted by the star in fig. 2, inserts into the hinge slot in the cavity frame •...
- Page 14 Cleaning and maintenance Important: Do not disassemble the door without it having been removed from the oven. Weight differences could cause the door to snap shut, causing damage to the oven and/or the user Removing the inner door glass With the door removed, the inner glass can also be taken out for cleaning purposes.
- Page 15 Cleaning and maintenance • The middle pane of glass can also be removed but it is important that this pane is reinserted facing the same way that it was when removed • There are a number of rubber guides attached to the inner pane and these must be returned to their original positions when reassembling the door.
- Page 16 Cleaning and maintenance Important: Always remember to allow the oven to cool sufficiently, if it has been in use, before carrying out any maintenance. To remove the shelf supports • Take a firm hold of the shelf support in the middle. Place your thumb against the oven wall and lever the support out of the support holes...
-
Page 17: Changing The Oven Light Bulb
Changing the oven light bulbs Important: Before any maintenance is started involving electrical parts, the appliance must be disconnected from the power supply. If the oven has been in use, let the oven cavity and the heating elements cool down before attempting any maintenance. Never use screwdrivers or other utensils to remove the light cover. -
Page 18: Installation
Installation Important! If installing this oven below a hob, ensure that the required air gap between the two appliances is observed. This gap is usually detailed in the hob’s manual. The installation of this appliance must be carried out by a suitably qualified person. - Page 19 Installation The walls of the kitchen units must be able to withstand temperatures of 75˚C above ambient (typically this is between 90˚C and 100˚C). When correctly installed ensure that there is a gap of 4mm minimum between the sides of the oven and adjacent furniture doors. How to install your oven You will need the housing area in fig.
-
Page 20: Mains Electrical Connection
Mains electrical connection Warning! This appliance must be earthed. This appliance must be connected by a competent person, using fixed wiring DOUBLE POLE SWITCHED FUSED SPUR OUTLET via a double pole switched fused spur outlet, protected by a 13A fuse. FUSE We recommend that the appliance is connected by a qualified... - Page 21 Mains electrical connection Please note: • The mains cable must only be replaced by a qualified electrician or service engineer and must be of equivalent or better rating (i.e. 3 x 1.5 mm ² , HO5VV-F) • This appliance is intended to be connected to the mains supply with a cable of cross sectional area 1.5 mm ²...
-
Page 22: Technical Assistance
Technical assistance In the event of your appliance requiring technical assistance and/or spare parts, please contact CDA Customer Care. CDA Customer Care Phone: 01949 862 012 Email: customer.care@cda.eu In this case it is necessary to state all the appliance data on the rating plate, such as model, serial number etc. -
Page 23: Specifications
Specifications Model SL100SS Oven Dimensions 595 x 595 x 575 mm (HxWxD) Rated voltage 230 V ~ 50 Hz Total rated input 2800 W This product meets the requirements of European standards EN 60335 -1; EN60335-2-6. The data on the energy labels of electric ovens is given according to standard EN60350-1 / IEC60350-1. -
Page 24: Product Fiche
Commision Delegated Regulation (EU) NO 65/2014 supplementing Directive of the European Parliament and of the Council 2010/30/EU with regard to energy labelling of household ovens and range hoods. Supplier name Model identifier SL100SS 12246.3eEdDQX Energy efficiency index (EEI cavity) 95,4 Energy efficiency class... -
Page 25: Product Information
Product information given in accordance with Commission Regulation (EU) No 66/2014 supplementing Directive of the European Parliament and Council Directive 2009/125/EC with regard to eco-design requirements for household ovens, hobs and range hoods. Model identifier SL100SS 12246.3eEdDQX Oven type (electricity or gas) Electric Appliance weight [kg]... - Page 26 Notes 26 | Instruction Manual...
- Page 27 Notes Instruction Manual | 27...
- Page 28 The CDA Group Harby Road Langar Nottinghamshire NG13 9HY Sales Department Phone: 01949 862010 Email: sales@cda.eu CDA Customer Care Phone: 01949 862012 Email: customer.care@cda.eu ©2020 CDA Group Ltd...
