- Page 1 SL500SS Thirteen function pyrolitic oven Use and maintenance...
-
Page 2: Table Of Contents
Contents Important information First use of the oven Setting the time Minute minder Semi automatic cooking Automatic cooking Settings Oven functions and operation Using the grill ECO heating Practical tips Pyroltic cleaning Cleaning and maintenance Changing the oven light bulbs Installation Mains electrical connection Technical assistance... -
Page 3: Important Information
Any other use could be dangerous and may lead to premature failure of the appliance. The CDA Group Ltd. cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserves the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance. - Page 4 Appliance information Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes. Appliance Model Serial Number...
-
Page 5: First Use Of The Oven
First use of the oven In order to remove oil residues accumulated during the manufacturing process and dust accumulated during storage and transport, we recommend a preliminary cleaning before first use. This is to protect your health and provide optimum quality in cooking. IMPORTANT! Remove the protective foil from the telescopic runners before using the oven. -
Page 6: Setting The Time
Setting the time When first connected to the power supply, the digital display will flash 0.00 . The oven will not operate until the time is set. • Simultaneously touch until you see the dot below the symbol flashing • Touch within 7 seconds to set the current time. -
Page 7: Semi Automatic Cooking
Semi-automatic cooking This function allows for a cooking time to be set. When the set time elapses the oven will switch the set function off and an acoustic signal will sound to alert the user. The cooking time available ranges from between 1 minute and 10 hours. -
Page 8: Automatic Cooking
Automatic cooking This function allows for a duration and an end time to be set for cooking. For example, if you set the cooking duration to 1 hour, and the end time to 15:00, then the oven will activate the function at 14:00. To switch on automatic cooking repeatedly until the display shows dur (duration) and the •... -
Page 9: Settings
Cancel settings Timer and function settings can be cancelled at any time regardless of the status of the operation. Simultaneously touch to cancel. In order to cancel the minute minder function, first hold down then simultaneously touch to cancel. Changing the beep tone •... -
Page 10: Oven Functions And Operation
Oven functions and operation The ovens operations are controlled by the function selector knob on the right side of the control panel and the temperature selector knob on the left side. Please note: Only when the temperature has been selected will the oven begin to heat up. - Page 11 Oven functions and operation Oven is off Light The oven light will be turned on. Half grill This function radiates heat from the grill element. This fully temperature variable grill can be set between 50°C and 250°C maximum. Full grill In this setting both the grill and top element are engaged.
- Page 12 Warming oven This function radiates heat from the bottom element, baking cakes from underneath until done. Fan cooking with lower heat With this setting the convection fan and bottom heater are on, which increases the temperature at the bottom of the cooked dish.
-
Page 13: Using The Grill
Using the grill Important! When using any grill function the oven door should be kept closed. When the grill is in use accessible parts can become hot, it is advisable to keep children away from the oven. In order to switch on the grill you need to: •... -
Page 14: Eco Heating
ECO heating ECO heating is an optimised heating function designed to save energy when preparing food. You cannot reduce the cooking time by setting a higher temperature; preheating the oven is not recommended. Do not change the temperature setting and do not open the oven door during cooking. -
Page 15: Practical Tips
Practical tips The times given in the table below apply to a dish that is placed in to a cold oven. For a preheated oven the times should be reduced by 5 - 10 minutes. The figures given below are approximate and can be altered based on your own experience and cooking preferences. -
Page 16: Pyroltic Cleaning
Pyrolytic cleaning This function heats the oven to approximately 480°C which will burn off or loosen any stubborn grease, stains or dirt inside the oven, leaving behind an ash that simply has to be wiped up or swept from the interior afterwards. The cleaning process •... - Page 17 Pyrolytic cleaning Cancelling the process Pyrolytic cleaning is an automatic process that should not be interrupted. If you need to stop the process turn the function selector knob to 0. Depending on the time you interrupt the process, the oven may still be hot and must first cool down to 160°C before the door will unlock.
-
Page 18: Cleaning And Maintenance
Cleaning and maintenance Keeping your oven clean and well maintained helps to prolong it's fault-free lifespan. It is important that, before any cleaning or maintenance is performed, you switch off the oven at the mains supply. Do not start any cleaning or maintenance until the oven has been allowed to cool completely. - Page 19 Cleaning and maintenance Abrasive cleaning agents or scouring pads/cloths should not be used on the cavity surface. IMPORTANT: • Steam cleaners must not be used when cleaning this appliance • Once care and maintenance is complete, ensure that all parts are correctly replaced before using the oven Removing the appliance door In order to allow easier access into the oven cavity for cleaning, it is...
- Page 20 Cleaning and maintenance Replacing the appliance door • Hold the door to the appliance in the closed position and manoeuvre the hinges so that the part of the hinge, highlighted by the star in fig. 2, inserts into the hinge slot in the cavity frame •...
- Page 21 Cleaning and maintenance Important: Do not disassemble the door without it having been removed from the oven. Weight differences could cause the door to snap shut, causing damage to the oven and/or the user Removing the inner door glass With the door removed, the inner glass can also be taken out for cleaning purposes.
- Page 22 Cleaning and maintenance • The middle pane of glass can also be removed but it is important that this pane is reinserted facing the same way that it was when removed • There are a number of rubber guides attached to the inner pane and these must be returned to their original positions when reassembling the door.
- Page 23 Cleaning and maintenance Important: Always remember to allow the oven to cool sufficiently, if it has been in use, before carrying out any maintenance. To remove the shelf supports • Take a firm hold of the shelf support in the middle. Place your thumb against the oven wall and lever the support out of the support holes...
-
Page 24: Changing The Oven Light Bulbs
Changing the oven light bulbs Important: Before any maintenance is started involving electrical parts, the appliance must be disconnected from the power supply. If the oven has been in use, let the oven cavity and the heating elements cool down before attempting any maintenance. Never use screwdrivers or other utensils to remove the light cover. -
Page 25: Installation
Installation Important! If installing this oven below a hob, ensure that the required air gap between the two appliances is observed. This gap is usually detailed in the hob’s manual. The installation of this appliance must be carried out by a suitably qualified person. - Page 26 Installation The walls of the kitchen units must be able to withstand temperatures of 75˚C above ambient (typically this is between 90˚C and 100˚C). When correctly installed ensure that there is a gap of 4mm minimum between the sides of the oven and adjacent furniture doors. How to install your oven You will need the housing area in fig.
-
Page 27: Mains Electrical Connection
Mains electrical connection Warning! This appliance must be earthed. This appliance must be connected by a competent person, using fixed wiring via a double pole switched fused spur outlet, protected by a 13A fuse. DOUBLE POLE SWITCHED FUSED SPUR OUTLET We recommend that the appliance is connected by a qualified FUSE... - Page 28 Mains electrical connection Please note: • The mains cable must only be replaced by a qualified electrician or service engineer and must be of equivalent or better rating (i.e. 3 x 1.5 mm ² , HO5VV-F) • This appliance is intended to be connected to the mains supply with a cable of cross sectional area 1.5 mm ²...
-
Page 29: Technical Assistance
Technical assistance In the event of your appliance requiring technical assistance and/or spare parts, please contact CDA Customer Care. For more information about the warranty of your product, including terms and conditions, please visit www.cda.eu/warranty CDA Customer Care Phone: 01949 862 012 Email: customer.care@cda.eu... -
Page 30: Specifications
Specifications Model SL500SS 12247.3eETsPrDJVX Oven Dimensions 595 x 595 x 575 mm (HxWxD) Rated voltage 230 V ~ 50 Hz Total rated input 2800 W This product meets the requirements of European standards EN 60335 -1; EN60335-2-6. The data on the energy labels of electric ovens is given according to standard EN60350-1 / IEC60350-1. -
Page 31: Product Fiche
Commision Delegated Regulation (EU) NO 65/2014 supplementing Directive of the European Parliament and of the Council 2010/30/EU with regard to energy labelling of household ovens and range hoods. Supplier name Model identifier SL500SS 12247.3eETsPrDJVX Energy efficiency index (EEI cavity) 95.4 Energy efficiency class... -
Page 32: Product Information
Product information given in accordance with Commission Regulation (EU) No 66/2014 supplementing Directive of the European Parliament and Council Directive 2009/125/EC with regard to eco-design requirements for household ovens, hobs and range hoods. Model identifier SL500SS 12247.3eETsPrDJVX Oven type (electricity or gas) Electric Appliance weight [kg] 48.1... - Page 33 Notes Instruction Manual | 33...
- Page 34 Notes 34 | Instruction Manual...
- Page 35 Notes Instruction Manual | 35...
- Page 36 The CDA Group Harby Road Langar Nottinghamshire NG13 9HY Sales Department Phone: 01949 862010 Email: sales@cda.eu Customer Care Department Phone: 01949 862012 Email: customer.care@cda.eu ©2020 CDA Group Ltd IO-CBI-1657 v1 / 8508534...
