Power Dynamics ISPT5W Instruction Manual page 18

TECHNICAL SPECIFICATION / TECHNISCHE SPECIFICATIE / TECHNISCHE
DATEN / ESPECIFICACIONES TÉCNICAS / SPÉCIFICATIONS TECHNIQUES /
Ref. nr. :
Power max.
Power rms
Tappings
Frequency response
Woofer
Tweeter
SPL @ 1W/1m
SPL max
Dimensions
Weight
The specifications are typical. The actual values can slightly change from one unit to the other. Specifications can
be changed without prior notice.
SPECYFIKACJA TECHNICZNA
ISPT5W ISPT5B
952.961 952.963
120W @ 8 Ohm
35W @ 8 Ohm
4, 8, 16, 30W @ 100V / 8 Ohm
50Hz - 20kHz
5.25" Polypropylene
1/2" Mylar dome
89dB
110dB
160 x 163 x 239mm
2.2kg
18
ISPT6W ISPT6B
952.976 952.977
150W
45W
40Hz - 20kHz
6.5" Polypropylene
1" PEI dome
91dB
112dB
195 x 196 x 287mm
3.1kg
