Velocity 5.5" Touch Panel
AT-VTP-550
The Atlona AT-VSP-550-BL and AT-VTP-550-WH are 5.5" touch panels in black and white,
respectively, for the Atlona Velocity™ Control System. They feature contemporary, refined styling
for modern presentation environments with 720x1280 native resolution, and a capacitive glass
surface that supports multi-touch and gesture interactions. These touch panels conveniently
install into a wall or furniture via a US or Euro one-gang opening. The VTP-550-BL and VTP-550-
WH feature Power over Ethernet (PoE), enabling a single network connection for data and power.
Setting up the touch panels is effortless as the AV control GUI is automatically uploaded from the
Velocity Control Gateway processor during system configuration.
Package Contents
1 x AT-VTP-550
1 x Metal mounting plate
Operating Notes
•
The Velocity 5" Touch Panel (AT-VTP-550) must be on the same network as the Velocity
Gateway (AT-VGW-HW) or it will be unable to sync for control.
•
The AT-VTP-550 is PoE capable, to power the unit, simply plug it into a 802.3at compatible
network switch. If the network switch is not PoE capable, a PoE injector
can be used.
IMPORTANT: Velocity Gateway (AT-VGW-HW) must be set up before the AT-VTP-550 is
fully functional.
4 x Mounting screws
1 x Installation Guide
1
Installation Guide
(purchased separately)
AT-VTP-550
Advertisement
Table of Contents
Related Manuals for Atlona Velocity AT-VSP-550-BL
Summary of Contents for Atlona Velocity AT-VSP-550-BL
- Page 1 Velocity 5.5” Touch Panel AT-VTP-550 The Atlona AT-VSP-550-BL and AT-VTP-550-WH are 5.5” touch panels in black and white, respectively, for the Atlona Velocity™ Control System. They feature contemporary, refined styling for modern presentation environments with 720x1280 native resolution, and a capacitive glass surface that supports multi-touch and gesture interactions.
-
Page 2: Mounting Instructions
Installation Guide AT-VTP-550 Mounting Instructions The AT-VTP-550 can be mounted to a 1 gang back plate. Select the type of 1 gang back box to use and install into a wall. NOTE: Install using the region’s safety guidelines for electrical boxes. Thread the Ethernet cable through the 1 gang box. -
Page 3: Installation And Setup
Installation Guide AT-VTP-550 Installation and Set Up NOTE: Installation of the Velocity Touch Panel can only be done after the VGW-250 has been set up. View the AT-VGW-HW Installation Guide and Velocity Manual for instructions. Connect the Ethernet cable into the back of the unit. If the Ethernet cable is connected to a non PoE switch, use a PoE injector using 802.3at (purchased separately). - Page 4 Installation Guide AT-VTP-550 Scanning for Gateways Scanning for Gateways Velocity Device Setup Velocity Device Setup 10.0.0.234 Set Static IP Device Alias Velocity Touch Panel 550 IP Address 10.0.0.123 0.0.0.0 Subnet Mask 255.255.255.0 Alt. URL 0.0.0.0 Default Gateway 10.0.0.1 SCAN FOR GATEWAYS DNS Server 75.75.75.75 BACK...
-
Page 5: Advanced Settings
Installation Guide AT-VTP-550 Velocity Device Setup Device Alias Velocity Touch Panel 550 10.0.0.234 10.0.0.234 SCAN FOR GATEWAYS BACK SAVE & CONTINUE Depending on the room options there may be multiple buttons on the home page. Select the any icon to open the room’s control page. NOTE: The room must be completely set up to receive the control interface. -
Page 6: Firmware Updating
Installation Guide AT-VTP-550 ADVANCED SETTINGS ADVANCED SETTINGS Set Configuration PIN Gateway Settings Gateway Settings (Note: Once a pin is set, it will be required to edit settings going 0.0.0.0 0.0.0.0 forward) (Enter a blank pin to remove) Alternate URL 0.0.0.0 Alternate URL 0.0.0.0 Device Settings... -
Page 7: Select Gateway
The AT-VTP uses a .tar.gz firmware that can be downloaded from the firmware section of https:// atlona.com/product/vtp-550/. Once downloaded follow these instructions to update the firmware. NOTE: When downloading the firmware file on a MAC, ensure that the file is not being auto-extracted. - Page 8 Installation Guide AT-VTP-550 Click on the field to browse the local computer for the firmware file, or drag and drop the firmware into the VTP Image Update field. NOTE: Update files will be tar.gz file extensions. These are compressed files and should not be extracted before upload.
- Page 9 • replace and return, free of charge, any defective products with direct replacement or with similar products deemed by Atlona to perform substantially the same function as the original products. • refund the pro-rated value based on the remaining term of the warranty period, not to exceed MSRP, in cases where products are beyond repair and/or no direct or substantially similar replacement products exist.
-
Page 10: Limitation On Liability
Atlona requires that products returned are properly packed, preferably in the original carton, for shipping. Cartons not bearing a return authorization or case number will be refused. Atlona, at its sole discretion, reserves the right to reject any products received without advanced authorization. -
Page 11: Exclusive Remedy
To the maximum extent permitted by law, Atlona specifically disclaims all implied warranties, including, without limitation, warranties of merchantability and fitness for a particular purpose. - Page 12 • © 2020 Atlona Inc. All rights reserved. “Atlona” and the Atlona logo are registered trademarks of Atlona Inc. All other brand names and trademarks or registered trademarks are the property of their respective owners. Pricing, specifications and availability subject to change without notice. Actual products, product images,...
