Seagate Technology SkyHawk ST2000LV000 Product Manual page 26

Figure 8 Mounting Dimensions (for 2-disk models)
(3.500)
(13.430)
2X M3 X 0.5-6H MOUNTING
HOLES: BOTH SIDES
4MM MIN SCREW DEPTH
FROM M3 PADS. NO THRU
3.5 +.075 -.3 X90
RECOMMENDED
TEMPERATURE
MEASUREMENT
LOCATION
Seagate SkyHawk Product Manual, Rev. E
22.450
2.499 1.270
7.949 1.270
BASE
+ 0.20
100.35
- 0.25
16.520
(90.600)
(14.000)
2X (3.000) BOTH SIDES
4 X M3 X 0.5-6H
2.5MM MIN FULL THREAD. NO THRU
Configuring and Mounting
69.850 0.250
3.5 +.075 -.3 X90
7.000 0.200
25
