Figure 7 Mounting Dimensions (For 1-Disk Models) (Alternate Basedeck) - Seagate Technology SkyHawk ST2000LV000 Product Manual

Figure 7 Mounting Dimensions (for 1-disk models) (alternate basedeck)
(22.450)
2.499 ± 1.270
7.949 ± 1.270
BASE
2X M3 X 0.5-6H
MOUNTING HOLES: BOTH SIDES
4MM MIN. SCREW DEPTH FROM
M3 PADS. NO THRU.
3.5+.075-.3X90
(13.430)
(3.500)
Seagate SkyHawk Product Manual, Rev. E
100.350
(16.520)
(14.000)
2X (3.000)
BOTH SIDES
+ 0.200
- 0.250
(90.600)
4 X M3 X 0.5-6H
2.5MM MIN FULL THREAD. NO THRU
3.5 +.075 -.3 X90
Configuring and Mounting
69.850 ± 0.250
7.000 0.200
RECOMMENDED
TEMPERATURE
MEASUREMENT
LOCATION
24
