Table Of Contents - Argo AD28AL Technical Data & Service Manual

1. SPECIFICATIONS
1-1 Unit specifications
1-2 Major Component specifications
1-3 Other Component specifications
1-4 Indoor Fan performance
2. DIMENSIONAL DATA
3. ELECTRICAL DATA
3-1 Electric Wiring Diagrams
4. FUNCTION
4-1 Cool Mode Operation
4-2 Heat Mode Operation
4-3 Auto Mode Operation
4-4 Dry Mode Operation
4-5 Fan Mode Operation
4-6 Protections in Cool/Dry Mode
4-7 Protections in Heat Mode
4-8 Sleep Function
4-9 Daily Timer
4-10 I FEEL Function
4-11 Drain Pump Operation
5. TROUBLESHOOTING
5-1 Check before and after troubleshooting
5-2 Air conditioner does not operate
5-3 Some part of air conditioner does not operate
5-4 Air conditioner operates, but abnormalities are observed
5-5 If a sensor is defective
6. CHECKING ELECTRICAL COMPONENTS
6-1 Measurement of Insulation Resistance
6-2 Checking Continuity of Fuse on PCB Ass'y
6-3 Checking Motor Capacitor

Table of Contents

3
Page
4
4
6
8
9
10
11
11
12
12
13
14
15
16
16
18
21
21
21
22
23
23
23
27
29
31
32
32
33
33
