ADIAS19DC
ADIBS13DC
ADICS13DC
Split air conditioner system
Condizionatore d'aria split system
Zweirohrsystem-Klimaanlage
Acondicionador de aire Split System
Sistema de ar condicionado de Unidades Separadas
Climatiseurs split
37.4255.134.03
09/2019
INSTALLATION
INSTRUCTIONS
MANUALE
D'INSTALLAZIONE
NOTICE
D'INSTALLATION
INSTALLATIONS-
ANLEITUNGEN
INSTRUCCIONES
DE INSTALACIÓN
INSTRUÇÕES DE
INSTALAÇÃO
EN
IT
FR
DE
ES
PT
Advertisement
Table of Contents
Related Manuals for Argo ADIAS19DC
Summary of Contents for Argo ADIAS19DC
- Page 1 MANUALE D’INSTALLAZIONE NOTICE D’INSTALLATION INSTALLATIONS- ANLEITUNGEN INSTRUCCIONES DE INSTALACIÓN INSTRUÇÕES DE INSTALAÇÃO ADIAS19DC ADIBS13DC ADICS13DC Split air conditioner system Condizionatore d’aria split system Climatiseurs split Zweirohrsystem-Klimaanlage Acondicionador de aire Split System Sistema de ar condicionado de Unidades Separadas 37.4255.134.03 09/2019...
-
Page 2: Table Of Contents
CONTENTS 1 - Installation site selection................4 2 - System wiring diagram ................4 3 - Wires’ length, size and delayed fuse .............4 4 - Additional material required for installation (not supplied) ......5 5 - Operating limits ..................5 6 - Accessories supplied with the unit ............5 7 - Tools required for installation (not supplied) ...........5 8 - Dimensions, weight and refrigerant connections ........6 9 - Installation procedure ................7... - Page 3 When wiring WARNING ELECTRICAL SHOCK CAN CAUSE SEVERE PERSONAL INJURY OR DEATH. ONLY A QUALIFIED, EXPERIENCED ELECTRICIANS SHOULD ATTEMPT TO WIRE THIS SYSTEM. • Do not supply power to the unit until all wiring and tubing are completed or reconnected and checked, to ensure the grounding.
-
Page 4: Installation Site Selection
1 - INSTALLATION SITE SELECTION AVOID • Direct sunlight. • Select an appropriate position from which every corner • Nearby heat sources that may affect unit performance. of the room can be uniformily cooled. • Areas where leakage of flammable gas may be expected. •... -
Page 5: Additional Material Required For Installation (Not Supplied)
4 - ADDITIONAL MATERIAL REQUIRED FOR INSTALLATION (NOT SUPPLIED) Deoxidized annealed copper tube for refrigerant tubing connecting the units of the system; it has to be insulated with ● foamed polyethylene (min. thickness 8mm). For tubing dimensions, tubing length and elevation difference limits, see installation manual of outdoor unit. -
Page 6: Dimensions, Weight And Refrigerant Connections
8 - DIMENSIONS, WEIGHT AND REFRIGERANT CONNECTIONS MODEL A (mm) B (mm) C (mm) D (mm) E (mm) MODEL WEIGHT (kg) ADIA 457 x 1 ADIA ADIB-C 1106 290 X 2 ADIB AWIC REAR VIEW FRONT VIEW FRESH AIR INTAKE PORT TOP VIEW CONVOGLIATORE ARIA REFRIGERANT TUBING SIDE... -
Page 7: Installation Procedure
9 - INSTALLATION PROCEDURE Minimum operation and maintenance area. Find the space for the installation of the return Use rawl plug suitable to the ceiling consistence air grille and mark the opening to do. Cut the and four M10 threaded bars of suitable lenght (not falseceiling. - Page 8 Predispose a removable panel of the falseceiling Secure the unit in position with locknuts and for servicing. washers, level the unit, keeping the right distance from the falseceiling for the installation of return air grille. The unit is supplied of PVC hose from the Convoy the condensate to the outside with a condensate pump.
-
Page 9: Duct For Fresh Air
Rear and front flange for the air intake. On the front and rear side of the unit a rectangular port (with flange) helps during duct mounting. 780 (ADIAS19) Outlet conduct 986 (ADIB-CS13) Intake coduct False ceiling 782 (ADIAS19) 988 (ADIB-CS13) Air intake Discarge air duct (optional accessory). -
Page 10: Remote Control Unit Installation
11 - REMOTE CONTROL UNIT INSTALLATION To ensure that the air conditioner operates correctly, DO NOT install the remote control unit in the following places: • In direct sunlight. • Behind a curtain or other places where it is covered. •... -
Page 11: Home Automation Wiring
End of installation. 13 - HOME AUTOMATION WIRING It is possible to connect the unit to a Home Automation system, according to the following instructions: ON/OFF (Terminals O O) - DEFAULT FACTORY STATE: CLOSED Contact open: the unit does not operate (always OFF) - inputs from the remote control unit are not processed. -
Page 12: Pump Down
15 - PUMP DOWN (See Installation Instruction of Outdoor Unit) Pump down means collecting all refrigerant gas in the system back into the outdoor unit without losing gas. Pump down is used when the unit is to be moved of before servicing the refrigerant circuit. 16 - TEST OF THE SYSTEM AND CONTROL OF THE AIR VOLUME TO THE OUTLET GRILLES The unit is prearranged to supply an external static pressure of about 5 mm. -
Page 13: Outdoor/Indoor Unit Refrigerant Circuit Address
17 - OUTDOOR/INDOOR UNIT REFRIGERANT CIRCUIT ADDRESS Indoor units that are part of a multisplit system must be properly configured to be able to communicate with the outdoor unit over different channels (Indoor A, Indoor B, etc...) of the communication bus. Each indoor unit address must correspond to the physical connection of the indoor unit to the outdoor unit refrigerant circuit, i.e.: Refrigerant Circuit A <-->... - Page 14 (2) ADDRESS SETTING THROUGH REMOTE CONTROLLER (UP TO 8 INDOOR UNITS) Set the remote controller as shown in the table. Indoor unit A: 11°C BUTTON SETTING Indoor unit B: 12°C Indoor unit C: 13°C working mode (COOL - HEAT) AUTO Indoor unit D: 14°C set point Indoor unit E: 15°C...
- Page 15 (3) AUTOMATIC ADDRESSING PROCEDURE System requirements: Outdoor unit must have a recent firmware version that supports the automatic addressing procedure. Indoor units must have a recent firmware version that supports the automatic addressing procedure Dip-switch for communication address setting on the indoor unit (SW2) must be left to the factory default state, i.e. to the OFF position.
-
Page 16: Match Between Remote Controller And Indoor Unit
18 - MATCH BETWEEN REMOTE CONTROLLER AND INDOOR UNIT Disconnect the power of indoor unit. ● Remove the batteries from the remote control unit. ● Set the microswitches (see table). ● Insert the batteries in the remote control unit. ● Switch on the indoor unit. -
Page 17: Remote Controller: How To Change From Infrared To Wires
19 - REMOTE CONTROLLER: HOW TO CHANGE FROM INFRARED TO WIRED PREPARE THE REMOTE CONTROLLER • Detach the plastic cover of the remote controller terminal block. • Open the batteries compartment, remove the batteries and set microswitches 5 and 6 in OFF position. •... -
Page 18: Electrical Wiring Diagram
20 - ELECTRICAL WIRING DIAGRAM - SCHEMA ELETTRICO - SCHÉMA ÉLECTRIQUE - ELEKTRISCHER SCHALTPLAN - ESQUEMA ELÉCTRICO - DIAGRAMA ELÉTRICO BLACK NERO NOIR SCHWARZ NEGRO PRETO BLUE BLEU BLAU AZUL AZUL BROWN MARRONE MARRON BRAUN MARRÓN CASTANHO G / Y GREEN / YELLOW VERDE / GIALLO VERT / JAUNE... - Page 19 Via Alfeno Varo, 35 - 25020 Alfianello - BS - Italy Tel. +39 0331 755111 - Fax +39 0331 755501 www.argoclima.com...
