Fire-Lite Alarms APS-6RF Instruction Manual

Fire-Lite Alarms APS-6RF Instruction Manual

Auxiliary power supply
Hide thumbs Also See for APS-6RF:
Table of Contents

Advertisement

Quick Links

Download this manual
PN 50893:B
ECN 00-317
Auxiliary Power Supply
APS-6RF
Instruction Manual
Document 50893
B
07/20/2000
Rev:

Advertisement

Table of Contents
loading

Related Manuals for Fire-Lite Alarms APS-6RF

Summary of Contents for Fire-Lite Alarms APS-6RF

  • Page 1 PN 50893:B ECN 00-317 Auxiliary Power Supply APS-6RF Instruction Manual Document 50893 07/20/2000 Rev:...
  • Page 2 While a fire alarm system may lower insurance Fire Alarm System Limitations rates, it is not a substitute for fire insurance! An automatic fire alarm system–typically made up of Heat detectors do not sense particles of combustion and smoke detectors, heat detectors, manual pull stations, alarm only when heat on their sensors increases at a audible warning devices, and a fire alarm control with predetermined rate or reaches a predetermined level.
  • Page 3 Adherence to the following will aid in problem-free Installation Precautions installation with long-term reliability: WARNING - Several different sources of power can be Like all solid state electronic devices, this system may connected to the fire alarm control panel. Disconnect all operate erratically or can be damaged when subjected sources of power before servicing.
  • Page 4 This Page Intentionally Left Blank APS-6RF Instruction PN 50893:B 7/20/00...

  • Page 5: Table Of Contents

    Introduction ....................11 Wiring the APS-6RF ..................12 Field Wiring an APS-6RF................12 Connecting Multiple APS-6RF Power Supplies........13 Connecting the APS-6RF to an IC-4F/ICE-4F Module......14 Configuring the APS-6RF................15 Servicing the APS-6RF ................. 16 Appendix A: Sensiscan 200 Mounting in a CAB-200 Backbox ..............
  • Page 6 This Page Intentionally Left Blank APS-6RF Instruction PN 50893:B 7/20/00...

  • Page 7: Overview

    Compatibility Document Table 1 Supplemental Documentation Description The APS-6RF Auxiliary Power Supply is a 150W cabinet-mounted power supply, designed to power devices that require filtered, regulated, non- resettable power, such as Notification Appliance Circuit Modules. The APS-6RF provides three 24 VDC (filtered) output circuits.
  • Page 8 1. Overview Description The figures below identify the features of the APS-6RF power supply: Trouble In (J4) - Trouble Out (J3) “P” style connectors for internal cabinet connections Three 24 VDC output circuits LED Status Indicators: Two (2) power-limited Green LED – Indicates AC power on One (1) non power-limited Yellow LED –...

  • Page 9: Specifications

    Specifications 1. Overview Specifications The APS-6RF is compatible with the Sensiscan 2000, and Sensiscan 200 control panels. Specifications for the APS-6RF are: Electrical Specifications AC Primary Input Power 120 VAC, 60 Hz, 2.5 A Wire Size: #14 AWG with 240 VAC, 50 Hz, 1.2 A...
  • Page 10 NOTES APS-6RF Instruction PN 50893:B 7/20/00...

  • Page 11: Installation

    2. Installation WARNING: Use extreme caution when working with the APS-6RF. High voltage and AC line-connected circuits are present. Turn off and remove all power sources. To reduce the risk of electric shock make sure to properly ground the unit.

  • Page 12: Wiring The Aps-6Rf

    • Wiring multiple APS-6RF power supplies. • Connecting an APS-6RF to an IC module Field Wiring an APS-6RF You can use J1 and J2 in place of TB2 when the APS-6RF is powering internal modules (such as an IC-4F, ICE-4F, TC-2F, TC-4F) with compatible connectors.

  • Page 13: Connecting Multiple Aps-6Rf Power Supplies

    Wiring the APS-6RF 2. Installation Connecting Multiple APS-6RF Power Supplies Typical trouble bus connections for multiple APS-6RF power supplies using trouble connectors J3 and J4. Use Cable 71033 or 75098 (same cables; different lengths) for all wiring. See appendix on your system for specific “Trouble Input” connection.

  • Page 14: Connecting The Aps-6Rf To An Ic-4F/Ice-4F Module

    Wiring the APS-6RF Connecting the APS-6RF to an IC-4F/ICE-4F Module All four (4) NACs on the IC-4F are powered from the APS-6RF output circuit 2 (J2) and the four (4) NACs on the ICE-4F are powered from circuit 1 (J1). The NACs share the total 3A available from each circuit.

  • Page 15: Configuring The Aps-6Rf

    Configuring the APS-6RF 2. Installation Configuring the APS-6RF The APS-6RF may be configured for the following: • 8-hour delay for reporting loss of AC: cut jumper JP2. • 16-hour delay for reporting loss of AC: cut jumper JP2 and JP3.

  • Page 16: Servicing The Aps-6Rf

    Servicing the APS-6RF Servicing the APS-6RF The only serviceable components on the APS-6RF are fuses F1 and F2. If a fuse fails, replace it with a fuse of the same type and rating: • F1 AC protection - 4A, 3 AG •...

  • Page 17: Appendix A: Sensiscan 200

    Place the APS-6RF onto the mounting studs in the backbox. Insert a standoff through each of the printed circuit board mounting holes, threading each standoff to the mounting studs. Tighten the standoffs until the APS-6RF is securely fastened to the backbox. Reinstall the plastic chassis cover.

  • Page 18: Connecting The Aps-6Rf To An Mps-24Bf

    Appendix A: Sensiscan 200 Connecting the APS-6RF to an MPS-24BF Connecting the APS-6RF to an MPS-24BF Make the following connections as shown in the figure below. • Connect primary power from TB1 to MPS-24BF terminal block TB1, Pin 3( ) and Pin 4( NEUT •...

  • Page 19: Appendix B: Sensiscan 2000

    Insert a standoff through each of the printed circuit board mounting holes, threading each standoff to the mounting studs on the chassis. Tighten the standoffs until the APS-6RF is securely fastened to the chassis. Reinstall the plastic chassis cover. CHS-4F Chassis...

  • Page 20: Connecting The Aps-6Rf To An Mps-24Af

    Appendix B: Sensiscan 2000 Connecting the APS-6RF to an MPS-24AF Connecting the APS-6RF to an MPS-24AF Make the following connections as shown in the figure below. • Connect primary power from TB1 to MPS-24AF terminal block TB1, Pin 5( ) and Pin 7( NEUT •...

  • Page 21: Connecting The Aps-6Rf To An Mps-24Bf

    Connecting the APS-6RF to an MPS-24BF Appendix B: Sensiscan 2000 Connecting the APS-6RF to an MPS-24BF Make the following connections as shown in the figure below. • Connect primary power from TB1 to MPS-24BF terminal block TB1, Pin 3( ) and Pin 4( NEUT •...
  • Page 22 NOTES APS-6RF Instruction PN 50893:B 7/20/00...
  • Page 23 PC board, vertical Power-limited circuit Primary Power features of the APS-6RF 18, 20, 21 primary power field wiring fuses Secondary Power 18, 20, 21 secondary power High Voltage Warning 9, 17 Sensiscan 200 9, 19 Sensiscan 2000 APS-6RF Instruction PN 50893:B 7/20/00...
  • Page 24 Index serviceable components Specifications 17, 19 standoff TC-2F/TC-4F terminal block cover Trouble Bus trouble connectors 18, 20, 21 trouble input Warning, High Voltage wiring APS-6RF Instruction PN 50893:B 7/20/00...
  • Page 25 APS-6RF Instruction PN 50893:B 7/20/00...
  • Page 26 APS-6RF Instruction PN 50893:B 7/20/00...
  • Page 27 Limited Warranty The manufacturer warrants its products to be free from defects in materials and workmanship for eighteen (18) months from the date of manufacture, under normal use and service. Products are date-stamped at time of manufacture. The sole and exclusive obligation of the manufacturer is to repair or replace, at its option, free of charge for parts and labor, any part which is defective in materials or workmanship under normal use and service.
  • Page 28 World Headquarters One Fire-Lite Place, Northford, CT 06472-1653 USA 203-484-7161 • Fax 203-484-7118 www.firelite.com...
