- Page 1 Network Video Recorder Installation Manual DR-8516 DR-8532 DR-8532D Powered by...
- Page 2 Before reading this manual This manual contains basic instructions on installing and using DirectIP Network Video Recorder, an IDIS product. Users who are using this product for the first time, as well as users with experience using comparable products, must read this manual carefully before use and heed to the warnings and precautions contained herein while using the product.
- Page 3 Before reading this manual C. If the equipment has been exposed to rain or water. Important Safeguards instructions, adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in 1. Read Instructions damage and will often require extensive work by a qualified technician to All the safety and operating instructions should be read before the appliance restore the equipment to its normal operation.
- Page 4 Before reading this manual In-Text Symbol Type Description Caution Important information concerning a specific function. Note Useful information concerning a specific function. User’s Caution Statement Caution: Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void your authority to operate the equipment.
- Page 5 IDIS Co., Ltd. reserves all rights concerning this manual. Use or duplication of this manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this manual are subject to change without prior notice.
-
Page 6: Table Of Contents
Table of Contents Part 1 – Introduction ......... 7 Product Features . -
Page 7: Part 1 - Introduction
Part 1 – Introduction Product Features This is a DirectIP-enabled video recorder that supports surveillance, recording, and playback of video from network cameras (or video encoders). This NVR (Network Video Recorder) unit offers the following features: ● Real-time 16/32 channel DirectIP network surveillance ●... - Page 8 Part 1 – Introduction HDMI Monitor HDMI Monitor Audio Out Microphone DirectIP Gigabit Network PoE Switch Camera USB HDD Flash Memory Network Camera Alarm Out Network Video Recorder Analog Alarm (1-4) Video Encoder Camera Sensor (1-16) Mouse Network Connection IR Remote Control...
-
Page 9: Accessories
Part 1 – Introduction Accessories Upon unpackaging the product, check the contents inside to ensure that all the following accessories are included. Network Video Recorder Power Cable Quick Guide Optical USB Mouse IR Remote Control (Optional) -
Page 10: Overview
Part 1 – Introduction Overview Front Panel Panic Recording SATA LED Status LEDs USB Ports Button Power LED Front Door Lock Rack Mount Ears • Some buttons have more than one function. • Remote control sensor is located on the left side of the front panel. Ensure that the sensor remains unobstructed at all times. - Page 11 Part 1 – Introduction 4 USB Ports 5 Power LED ● Storage Device Connection Lights up while the main unit is in operation. Connect an external USB hard drive or a USB flash memory device to one of the USB ports for use with the Clip Copy feature.
- Page 12 Part 1 – Introduction Connections on the Front Panel IR Remote Control Flash Memory Mouse USB HDD...
-
Page 13: Dimensions
Part 1 – Introduction Dimensions Unit : mm 482.6 ▼ ▼ ▼ 437.6 482.6 482.6... -
Page 14: Rear Panel
Part 1 – Introduction Rear Panel DR-8516 / DR-8532 DR-8532D Video In Ports Power In Port Network Port - SFP (1~2) / RJ45 (3~5) eSATA Ports USB 3.0 Ports Audio Connection Ports HDMI Out Port Alarm Connection Ports RS-232 Port... - Page 15 Part 1 – Introduction (DR-8532D) The LED and Buzzer Control Rules of Redundant Power Condition Power Module #1 Power Module #2 Buzzer AC Cord Included / Not Included Power Module #1 Power Module #2 Green LED Red LED Green LED Red LED Mounted Non-mounted...
-
Page 16: Rear Panel Connections
Part 1 – Introduction Rear Panel Connections ● RJ45 Video In Port Power Cable Connection Connect the power cable to this port. This NVR does not feature a separate power on/off button and will turn on the moment power is supplied. Connect network cameras or video encoders to the NVR using RJ-45 cable (Cat5, Cat5e, or Cat6). - Page 17 Part 1 – Introduction eSATA Connection • This NVR does not feature a built-in audio amplifier unit and therefore requires the user to purchase a Connect external hard drives to these ports. speaker system with a built-in amplifier separately. It's possible to connect an amplified audio source to the NVR, but microphones that do not have a built- in amplifier will not function properly if connected to the NVR directly.
- Page 18 Part 1 – Introduction ● Alarm In 1 through 16 ● NC/NO 1 through 4 (Relay Alarm Outputs) This NVR is capable of responding to event signals from This NVR is capable of activating/deactivating buzzers, exterxnal alarm in devices. Connect mechanical or lights, and other external devices.
- Page 19 Part 1 – Introduction Connections on the Rear Panel Power Network Camera DirectIP Gigabit PoE Switch Network eSATA Storage Camera Microphone Device Network Sensor IDIS Center Remote Monitoring Speaker HDMI Monitor Keyboard Alarm...
-
Page 20: Part 2 - Appendix
Part 2 - Appendix Supported SFP Transceiver Module List The system's SFP ports support the following types of SFP modules: Wavelength Standard Diameter (um) Length Mode Connector SFP Module (nm) 50/125 550m Multi ATOP 1000BASE-SX APSB85123CDL05 62.5/125 500m Multi ATOP 1000BASE-LX 9/125 1310... -
Page 21: System Log Types
Part 2 - Appendix System Log Types Boot Up Panic On System Shutdown Panic Off Restart Clear All Data Upgrade Success Clear Disk Upgrade Error Format Disk Power Failure Disk Full Time Changed Auto Deletion Time Zone Change Search Begin Time Sync. -
Page 22: Error Code Types
Part 2 - Appendix Error Code Types Upgrade Error Codes Type Type Unknown Error Remote Network Error Incorrect File Version No Remote Upgrade Permission Incorrect OS Version Remote Upgrade File Save Failure Incorrect Software Version Remote Upgrade Cancelled by User Incorrect Kernel Version USB Storage Device Mount Failure Storage Device Mount Failure... - Page 23 Part 2 - Appendix Clip Copy Error Codes Type Type Unknown Error Disk Error Device Error Clip Player Execution File Not Found Device Connection Failure Clip Player Execution File Access Failure CD Media Not Found Clip Player Execution File Save Failure Incorrect Media Image Generation Failure File Name Taken...
- Page 24 Part 2 - Appendix Network Error Codes Type Type Cause of Failure Unknown Connection Cancelled by User Normal Logout No Response from Network Device Host All Channels in Use - Connection Denied High Network Noise Level Incorrect Product Version Info Transmission Queue Full Incorrect User Name or Password Incorrect OEM Info...
-
Page 25: Troubleshooting
Part 2 - Appendix Troubleshooting Problem Solution ● Check the power cable connection status. The main unit won't turn on. ● Check the power outlet. ● Check the camera's video cable connection status. ● Check the monitor's video cable connection status. Unable to display Live video. -
Page 26: Specifications
Client Connection Gigabit Ethernet(Client) x1 Video in Connection Gigabit Ethernet(Video In) x3, SFP(Video In ) x 2 Transmission Speed 50Mbps / 100Mbps(BRP Mode) Email (attach clip (.cbf ) .MP4), Callback to Remote S/W, Push notification (IDIS Event Notification Mobile), FTP, HTTP... - Page 27 GENERAL Operating System Embedded Linux Unit Dimensions 482.6mm x 88mm x 523.3mm (19"x3.5"x20.6") (W x H x D) 11.25kg (24.80lb) (with 2 HDDs) DR-8516/DR-8532 Unit Weight 12.63kg (27.84lb) (with 2 HDDs) DR-8532D Working Temperature 0°C to 40°C Operating Humidity 0% ~ 90%...
- Page 28 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
