- Page 1 PUBLIC ADDRESS SYSTEM T-B60D/B120D/B240D/B350D/B500D MIXER AMPLIFIER POWER MIC1 INPUT MIC 1 MIC 2 MIC 3 4 AUX 1 AUX 2 BASS TREBLE MASTER PROT 100V CLIP T-B60D 4-16 Ω Please follow the instructions in this manual to obtain the optimum results from this unit.
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. SAFETY PRECAUTIONS ..................3 2. GENERAL DESCRIPTION ..................5 3. FEATURES .......................5 4. NOMENCLATURE AND FUNCTIONS 4.1 Front Panel ......................6 4.2 Rear Panel....................... 7 5. OPERATION ILLUSTRATION ................8 TROUBLESHOOTING .....................9 7. APPLICATIONS ..................... 10 8.BLOCK DIAGRAM ....................11 9.SPECIFICATIONS .................... -
Page 3: Safety Precautions
1. SAFETY PRECAUTIONS Be sure to read the instructions in this section carefully before use. Make sure to observe the instructions in this manual as the conventions of safety symbols and messages regarded as very important precautions are included. We also recommend you keep this instruction manual handy for future reference. Safety Symbol and Message Conventions Safety symbols and messages described below are used in this manual to prevent bodily injury and property damage which could result from mishandling. - Page 4 SAFETY PRECAUTIONS When the Unit is in Use When Installing the Unit Do not place heavy objects on the unit as this may Never plug in nor remove the power supply plug cause it to fall or break which may result in with wet hands, as doing so may cause electric personal injury and/or...
-
Page 5: General Description
2. GENERAL DESCRIPTION This product is a mixer amplifier with Bluetooth radio, adopting by combination of high-performance switching power supply and digital power amplifier, with 1U chassis design, high efficiency, light weight & delicate appearance. 3. FEATURES 1. With 1U chassis design internal combination of switching power supply and digital power amplifier higher efficiency, light weight and delicate appearance. -
Page 6: Nomenclature And Functions
4. NOMENCLATURE AND FUNCTIONS 4.1 FRONT PANEL POWER MIC1 INPUT MIC 1 MIC 2 MIC 3 4 AUX 1 AUX 2 BASS TREBLE MASTER PROT 100V CLIP 4-16 Ω 6 7 8 11 12 1. MIC1 unbalanced input jack 2. MIC1 volume control knob 3. -
Page 7: Rear Panel
4. NOMENCLATURE AND FUNCTIONS 4.2 REAR PANEL MIC 1 OUTPUT OUTPUT INPUT MIC 4 MIC 3 MIC 2 MUTE 100V/4-16Ω 100V 4-16Ω AUDIO AUX2 AUX1 EMC IN MUTE 8 9 1011 1213 14 AC power input socket 100V/ output interface 4-16 Ω... -
Page 8: Operation Illustration
5. OPERATION ILLUSTRATION 1.Connect the speakers: ①When the 100V and ② 4-16Ω selector switch When the 100V and 4-16Ω selector switch to 100V position, as shown below: 4-16Ω position, as shown below: OUTPUT OUTPUT 100V/4-16Ω 100V/4-16Ω 100V 4-16Ω 100V 4-16Ω SPK+ SPK+ SPK-... -
Page 9: Troubleshooting
5. DISPLAY SCREEN OPERATION INSTRUCTIONS Microphone using: 1.Turning the volume knob to the left,Connect the microphone and microphone input interface. 2.Turning the volume knob in the right position. 3.Facing the microphone and Speak loudly, turn the volume knob to the right, until the output signal no longer distortion.If input is high but output is low voice, and then increase the volume by using the volume knob.If the speaker volume is very high, then reduce the volume by using the volume knob. -
Page 10: Applications
7. APPLICATIONS REAR PANEL CONNECTIONS... -
Page 11: Block Diagram
8. BLOCK DIAGRAM... -
Page 12: Specifications
9. SPECIFICATIONS Model T-B60D T-B120D T-B240D T-B350D T-B500D Rated Power 120W 240W 350W 500W Output Level 4-16Ω/100V MIC1,2,3,4 input:5mV±1mV/600 Ω, balanced European terminal; AUX1,2 input:350mV±20mV/10K Ω, unbalanced Input Sensitivity RCA connection terminal; EMC input:775mV±40mV/10K Ω, balanced European terminal Output Sensitivity&... -
Page 13: Dimensional Diagram
10. DIMENSIONAL DIAGRAM UNIT:mm POWER MIC1 INPUT MIC 1 MIC 2 MIC 3 4 AUX 1 AUX 2 BASS TREBLE MASTER PROT 100V CLIP 4-16 Ω MIC 1 OUTPUT OUTPUT INPUT MIC 4 MIC 3 MIC 2 MUTE 100V/4-16Ω 100V 4-16Ω... - Page 14 PUBLIC ADDRESS SYSTEM VersionV0.1...
