Page 1: Vacuum Cleaner
Vacuum Cleaner ✻ Before operating this unit, please read the instructions carefully. ✻ For indoor use only. imagine Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register user manual the possibilities... -
Page 2: Safety Information
Safety information IMpORTANT SAFETY INSTRUcTIONS Thank you for purchasing a Samsung vacuum cleaner. When using an electrical appliance, basic precautions should always be followed, including the following : PLEASE READ ALL WARNINGS AND INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER. WARNING To reduce the risk of fire, electric shock, or injury. -
Page 3: Save These Instructions
Safety information • Avoid picking up hard, sharp objects with the cleaner. They may damage the cleaner. • Always turn off this appliance before connecting or disconnecting the hose, removing the bottom plate for maintenance. • Use only on dry, indoor surfaces, never change the plug in any way. •... - Page 4 Safety information SAFETY INFORMATION • Before operating the appliance, please read this manual thoroughly and retain it for your reference. WARNING • Because these following operating instructions cover various models, the characteristics of your vacuum cleaner may differ slightly from those described in this manual. WARNING CAUTION/WARNING SYMBOLS USED Indicates that a danger of death or serious injury exists.
-
Page 5: Table Of Contents
Contents ASSEMBLING THE CLEANER OPERATING THE CLEANER MAINTENANCE TROUBLESHOOTING 06. Product View 07. Attach Handle to Vacuum 07. Attach Dust Bin to Vacuum 07. Attach Vacuum Hose and Tools 08. Power Switch 08. Handle Positions 08. Height Adjustment 08. Transporting Cleaner 09. -
Page 6: Assembling The Cleaner
Assembling the cleaner pRODUcT VIEw Handle *option Bracket Brush (Select Models Only) *option Mini Turbo Brush (Select Models Only) Carrying Handle Grille Cyclone Dust Bin Post-Motor Filter (Post-Motor Filter is located behind the door.) Powerfoot Do not plug in your vacuum cleaner until you are familiar with all instructions and operating procedures. -
Page 7: Attach Handle To Vacuum
Assembling the cleaner ATTAcH HANDLE TO VAcUUM 1. Stand the vacuum upright and slide the base of the handle firmly into the grooves at the top of the vacuum body. 2. Check to be sure the handle is fitted to the vacuum body. -
Page 8: Operating The Cleaner
Operating the cleaner pOwER SwITcH The Power Switch is located on the side of the vacuum. Push the rocker switch "ON" to vacuum, and "OFF" when cleaning is complete. HANDLE pOSITIONS Press the handle release pedal, located on the lower left side of the vacuum, with your foot to place your vacuum into one of three cleaning positions. -
Page 9: Special On-Board Tools
Operating the cleaner SpEcIAL ON-bOARD TOOLS Your vacuum is not only a powerful carpet and rug cleaner, it’s also a versatile above floor vacuum cleaner when you select one of the special tools. 1. Raise Handle to Upright Position. 2. Grasp the end of the Hose Wand and lift Hose Wand to separate from the Hose Wand Base. -
Page 10: Maintenance
Maintenance To maintain maximum cleaning performance, the following maintenance steps must be performed: 1. Empty the Dust Bin when the dirt reaches the “MAX” line on the side. 2. Cleaning the Grille Cyclone when the Dust Bin become clogged. 3. Check the Pre-Motor Filter at least once a month and clean or replace as needed. -
Page 11: Cleaning The Pre-Motor Filter
Maintenance cLEANING THE pRE-MOTOR FILTER Sponge Filter Micro Filter 1. Unplug the Vacuum Cleaner from electrical outlet. 2. The Pre-Motor Filter(Sponge Filter, Micro Filter) protects the motor from dirt particles. It is located underneath the Dust Bin. If the Pre-Motor Filter becomes dirty, remove and clean it. Note: The Pre-Motor Filter may be hand washed in cold water with mild detergent. -
Page 12: Check Rotating Brush And Drive Belt
Maintenance cHEcK ROTATING bRUSH AND DRIVE bELT You should check your vacuum cleaner’s Rotating Floor Brush and Drive Belt regularly for wear or damage. You should also clean the brush and brush ends of strings, hair, and carpet fibers. These can wrap around the brush and hamper its ability to effectively clean your carpet. -
Page 13: Mini Turbo Brush
Maintenance MINI TURbO bRUSH brushbar Replacement 1. Remove the tool from the hose, and turn upside down. Slide the switch to unlock position and remove bottom plate. 2. Unscrew the one screw and remove belt guard. 3. Remove brushbar including end plates and discard. 4. -
Page 14: Troubleshooting
Troubleshooting Check this list of possible problems and solutions before bringing your vacuum to a service center. PROBLEM Vacuum cleaner won’t run • Power cord not plugged in • Blown fuse/tripped breaker in home Vacuum cleaner and tools won’t pick up dirt •... - Page 15 Memo memo _15...
- Page 16 If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. COUNTRy SOUTH AFRICA CALL 0845 SAMSUNG (7267864) 0860 7267864 (SAMSUNG) OR VISIT US ONLINE AT www.samsung.com/uk www.samsung.com/za Code No. DJ68-00450A REV(0.7)
