OPERATION AND MAINTENANCE MANUAL
SKD-BE512L
SKD-BE519L
SKD-BE512LF
SKD-BE517LF
SKD-BE512P
SKD-BE519P
SKD-BE512PF
SKD-BE517PF
Ver. 3.0
DC-TYPE Automatic Non-Carbon-Brush with Counter Series
KILEWS INDUSTRIAL CO., LTD.
www.kilewswest.com
KILEWS WEST USA INC. - 6945 LTC PKWY - PORT ST LUCIE, FL 34986
PHONE (772) 293-0071 FAX (772) 465-4368 EMAIL SALES@KILEWSWEST.COM
Y2F032A-E-003
Advertisement
Table of Contents
Related Manuals for Kilews SKD-BE517LF
Summary of Contents for Kilews SKD-BE517LF
- Page 1 SKD-BE512P SKD-BE519P SKD-BE512PF SKD-BE517PF Ver. 3.0 DC-TYPE Automatic Non-Carbon-Brush with Counter Series KILEWS INDUSTRIAL CO., LTD. www.kilewswest.com KILEWS WEST USA INC. - 6945 LTC PKWY - PORT ST LUCIE, FL 34986 PHONE (772) 293-0071 FAX (772) 465-4368 EMAIL SALES@KILEWSWEST.COM Y2F032A-E-003...
- Page 2 NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. WARNING Important safety information enclosed.
-
Page 3: Important Safety Rules
Important Safety Rules Read all instructions Failure to follow all instructions listed below may result in electric shock WARNING! fire and/or serious injure. The term “power tool” in all of the warning listed below refers to your mains operated (corded) power tool or battery operated (cordless) power tool. - Page 4 4) Power tool Use and Care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use power tool if switch does not turn it on or off.
-
Page 5: Do Not Operate This Tool Without Protective Earth Connected
WARNING！ DO NOT OPERATE THIS TOOL WITHOUT PROTECTIVE EARTH CONNECTED Grounding Instructions 1、This tool should be grounded while in use to protect the operator from electric shock. NOTICE! To ensure the grounding result, the grounding conductor of the power cord must be well connected with the grounding terminal of power facility. - Page 6 Operations Cautions 1) Whenever changing a bit, make certain the Forward / Reverse Switch is in the “OFF “position and tool is unplugged. 2) Do not allow chemicals such as acetone, benzene, thinner, trichloroethylene ketone, or other similar chemicals to come in contact with the screwdriver housing as damage will result. 3) Do not drop or abuse the screwdriver.
-
Page 7: Description Of Operation
Description of Operation Attaching / detaching bit and bit type Push up the holder clamp by finger tip, and it will be unlocked. Thus, the bit can be freely attached and detached (single finger notion type) select such a bit whose shank is equal to the size shown below. ... -
Page 8: Do Not Attempt To Repair This Electric Screw Driver
2. All repairs and maintenance of this tool and its word must be performed by an authorized service center. 3. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. -
Page 9: Specifications
Model of Torque Fixing Ring KC-6C、KC-6S Power controller SKP-32B-60W Model of Suspension Rack KH-4、(KC & KH-2) Bit Type HEX 5mm, HEX 6.35mm Ø4mm, Ø5mm MODEL SKD-BE512LF SKD-BE512PF SKD-BE517LF SKD-BE517PF Input voltage(DC) DC 32V Power Consumption (kgf.cm) 1.5-12 2-12 3-17 3-17 Torque (Lbf.in) 1.33-10.44 1.77-10.44 2.57-14.78... -
Page 10: Panel Specifications
1 Pcs. Each SKD-BE517F with BIT 1# & 2# 1 Pcs. Each 2. Suspension rack and Torque fixing ring acceptable for use with the tool are available from KILEWS catalogue. 3. Torque Fixing Ring (KC-6C) 1 Pcs. Panel Specifications Name Function To Show operating is OK, N.G or in the mode... - Page 11 Counting Set-Up instruction ※Push three seconds to enter the selection ) SL===SC===At===Ht===Lt===LL===Ns===Rn===Rt <Confirm> Factory Set up Time and Function Name Description Buzz Time/ Light default Value settings 01-05/UU Screw List 1-99 Counting number / count-down only 0.1-9.9 Automatic zero time / Signal output time 0.1-9.9 Ht time Stop time ( Show wrong as screwdriver can’t sop at Five buzz and LED red flash...
- Page 12 Ht/Lt Description: Ht/Lt mainly set up the period of time. If stop is within the set period, it means OK. In contrast, it will be (NG), as stop before Lt or after Ht. and should reconfirm whether wrong screws is taken. More accuracy requested means more correct Ht/Lt set-up should be.
-
Page 13: Torque Adjustment Operation
Torque Adjustment Operation To adjust the torque on these screwdrivers. Proceed as follows : 1. Determine the torque output of the tool by checking a tightened Fastener with a torque wrench. 2. Increase or decrease the torque by rotating the Spring Adjusting Ring. Rotating the Ring clockwise to a higher number on the torque Scale increase torque output while rotating the Ring counterclockwise to a lower number decreases the torque output. - Page 14 User could test the torque output of the screwdriver by torque meter periodically and then adjust it to meet user’s requirement for the compensation of the torque decay. 5. Please refer to Kilews website http://www.kilews.com for the detail component list. ...
- Page 16 BE512L BE519L(CE) NO PARTS NO PARTS NAME-E PARTS NAME-C Q'ty NO PARTS NO PARTS NAME-E PARTS NAME-C Q'ty 1 AA50001-26 CORD ASSEMBLY 2M 電源線2M 34 GC30341-3 上離合器頭 2 AA50001-52N CORD ASSEMBLY 檔尾電源線 35 GP30351 STEEL BALLS 跳脫鋼珠 3 CJ20011 SUSPENSION RING 起子吊環...
