3. Hanging the Fan

WARNING:
the set screws could result in the fan loosening and possibly falling.
NOTE: Make sure all screws are tightened and that wires
are not twisted.
8. Carefully lift the fan motor assembly up to the mounting bracket
and seat the hanger ball in the mounting bracket socket. Make
sure the tab on the mounting bracket socket is properly seated
in the groove in the hanger ball. Rotate the socket assembly until
the ball drops and locks into the hanger bracket screw.
9. Secure the safety cable into the structure beams using the wood
screw, washers, and spring washers provided (Fig. 3A).
NOTE: A Safety cable is required for all installations in Canada.
Safety cable is required for ceiling fan and light combinations over
35 lbs. in both flush and downrod models in the United States.

4. Attaching the Fan Blade

1. Place blade on motor as shown (Fig.4) and secure with the blade
attachment screws and washers.
2. Repeat this procedure with the remaining blades.

5. Attaching Decorative Plug

1. Press decorative plug into center hole of bottom housing (Fig. 5).
NOTE: Decorative plug is for indoor applications only.
14 Roboto Instructions
Failure to properly install the cotter pin and/or tighten
