TECHNICAL DATA
& SERVICE MANUAL
SPLIT SYSTEM AIR CONDITIONER
Model No.
CAFP255R5I
CAFP365R5I
CAFP485R5I
Product Code No.
38.7130.063
38.7130.064
38.7130.065
0.8180.460.1
09/2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAFP365R5I and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Technibel Climatisation CAFP365R5I

  • Page 1 TECHNICAL DATA & SERVICE MANUAL SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. CAFP255R5I 38.7130.063 CAFP365R5I 38.7130.064 CAFP485R5I 38.7130.065 0.8180.460.1 09/2006...
  • Page 2 IMPORTANT! • Ground the unit following local electrical codes. Please read before installation • The Yellow/Green wire cannot be used for any connection different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
  • Page 3: Table Of Contents

    Table of Contents Page 1. SPECIFICATIONS 1-1 Unit specifications 1-2 Major Component specifications 1-3 Other Component specifications 2. DIMENSIONAL DATA 3. ELECTRICAL DATA 3-1 Electric Wiring Diagram 3-2 Control PCB switches and functions 4. PROCESS AND FUNCTIONS 4-1 Control function 5.
  • Page 4: Specifications

    1. SPECIFICATIONS 1-1 Unit Specifications CAFP255R5I 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Heating Performance See catalogue with the requested matching Capacity 1140/1020/840 Air circulation (High/Med./Low) m³/h Features Microprocessor/ I.C. thermostat Controls/Temperature controls K70D036Z / K70D042Z Remote Controller (Option) wired K70D038Z / K70D040Z...
  • Page 5 CAFP365/485R5I 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Heating Performance Capacity See catalogue with the requested matching Air circulation (High/Med./Low) m³/h 1920/1680/1320 Features Controls/Temperature controls Microprocessor/ I.C. thermostat Remote Controller (Option) wired K70D036Z / K70D042Z wireless K70D038Z / K70D040Z 3 and Auto Fan speed...
  • Page 6: Major Component Specifications

    1-2 Major Component Specifications CAFP255R5I Controller PCB CR-CRP50A-B Part No. Microprocessor Controls Fan & Fan Motor Centrifugal fan Type 1…. Ø 443 Q'ty ……. Dia. and lenght SFG6X-41D6P…1 Fan motor model…Q'ty 6 … 470 No. Of poles…rpm (230 V, High) 0,611 Running Amps 31,4...
  • Page 7 CAFP365/485R5I Controller PCB CR-CRP50A-B Part No. Microprocessor Controls Fan & Fan Motor Centrifugal fan Type 1…. Ø 443 Q'ty ……. Dia. and lenght SFG6X-81A6P…1 Fan motor model…Q'ty 6 … 530 No. Of poles…rpm (230 V, High/Med/Low/LowLow) 0,765 Running Amps Power input Ω...
  • Page 8: Other Component Specifications

    1-3 Other Component Specifications ATR-IIJ225A Trasformer VAC 230V, 50Hz Rating Primary AC 20V - 0.2A Secondary 1 Secondary 2 AC 14V - 0.3A Secondary 3 AC 10,2V - 1.4A 136°C Thermal cut-off temp. Thermistor ( Coil sensor E1, E2) PBC-41E-S26 0 °C 15,0 ±...
  • Page 9: Dimensional Data

    2. DIMENSIONAL DATA CAFP255R5I 820 (Ceiling opening) 757 (Suspention bolt pitch) Air intake grille Air outlet Refrigerant liquid line [D. 9.52 (In case of 25 type , use the tube connector.)] Refrigerant gas line D. 12.7: 9, 12 type Drain connection Power supply entry For discharge duct For fresh air intake...
  • Page 10 CAFP365/485R5I 820 (Ceiling opening) 757 (Suspention bolt pitch) Air intake grille Air outlet Refrigerant liquid line (D.9.52) Refrigerant gas line (D.19.05) Drain connection Power supply entry For discharge duct For fresh air intake Suspension bolt mounting...
  • Page 11: Electrical Data

    3. ELECTRICAL DATA 3-1 Electric Wiring Diagram 7P terminal board 1(L) 2(N) power inter-unit remote supply control controller wiring...
  • Page 12: Control Pcb Switches And Functions

    3-2 Control PCB switches and functions CR-TRP50A-B OC (CN040) EMG (CN044) VARISTOR (VA041) DISP (CN072) EXCT (CN073) FILTER (JP001) (CN070) CHK (CN071) FAN DRIVE (CN032) (CN020) T10 (CN061) POWER LED (D002) EEPROM (IC010) T10: 6 plug (yellow): used for remote control. (Refer to the remote control section) (CN061) 1- start/stop input 2- COM...
  • Page 13: Process And Functions

    4. PROCESS AND FUNCTIONS 4-1 control functions...
  • Page 16: Replacing Pcb

    5. REPLACING PCB 5-1 Replacing PCB About EEPROM (Erasable Programmable Read-Only Memory) EEPROM is a component in which the various information necessary for functionning can be electronically written or erased. This component holds informations that is essential for the running of the unit, and must be handled with care. D002 led lamp (red)
  • Page 17: How To Replace Pcb

    5-2 How to replace PCB...
  • Page 18: How To Replace Eeprom With Eeprom Included In Pcb Service Pack

    5-3 How to replace EEPROM with EEPROM included in PCB service pack...
  • Page 20: Table Of Setting

    5-4 Table of settings...
  • Page 21: Service Procedure

    6. SERVICE PROCEDURE 6-1 Meaning of alarm message...
  • Page 22: Led Indicator Messages On Outdoor Control Pcb

    6-2 Led indicator messages on outdoor control PCB...
  • Page 23: Symptoms And Parts To Inspect

    6-3 Symtoms and parts to inspect...
  • Page 24: Details Of Alarm Messages

    6-4 Details of alarm messages resistance...
  • Page 28: Outdoor Unit Maintenance Remote Control

    7. OUTDOOR UNIT MAINTENANCE REMOTE CONTROL...
