- Page 1 TECHNICAL DATA & SERVICE MANUAL SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. CAFM75R5I 38.7130.031 CAFM95R5I 38.7130.032 CAFM125R5I 38.7130.033 CAFM165R5I 38.7106.983 CAFM185R5I 38.7130.034 0.8180.438.2 08/2008...
- Page 2 7-5 Multiset alarm codes...
- Page 6 IMPORTANT! • Ground the unit following local electrical codes. Please read before installation • The Yellow/Green wire cannot be used for any connection different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
-
Page 7: Table Of Contents
Table of Contents Page 1. SPECIFICATIONS 1-1 Unit specifications 1-2 Major Component specifications 1-3 Other Component specifications 1-4 Noise Criterion Curves 2. DIMENSIONAL DATA 3. ELECTRICAL DATA 3-1 Electric Wiring Diagram 3-2 Control PCB switches and functions 4. FUNCTION 4-1 Room Temperature Control 4-2 Automatic control for heating and cooling 5. -
Page 8: Specifications
1. SPECIFICATIONS 1-1 Unit Specifications CAFM75/95/125R5I 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Heating Performance Capacity See catalogue with the requested matching Air circulation (High/Med./Low) m³/h 700/600/500 Features Controls/Temperature controls Microprocessor/ I.C. thermostat Remote Controller (Option) wired K70D036Z / K70D042Z wireless... - Page 9 CAFM165/185R5I 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Heating Performance See catalogue with the requested matching Capacity Air circulation (High/Med./Low) m³/h 750/630/530 Features Controls/Temperature controls Microprocessor/ I.C. thermostat Remote Controller (Option) wired K70D036Z / K70D042Z wireless K70D038Z / K70D040Z Fan speed 3 and Auto...
-
Page 10: Major Component Specifications
1-2 Major Component Specifications CAFM75/95/125R5I Controller PCB CR-CRP50A-B Part No. Microprocessor Controls Fan & Fan Motor Type Centrifugal fan Q'ty ……. Dia. and lenght 1…. Ø 280 L 166 Fan motor model…Q'ty K35407-MO1972 …1 4… 880/740/660/290 No. Of poles…rpm (230 V, High/Med/Low/LowLow) 0,27 Running Amps Power input... - Page 11 CAFM165/185R5I Controller PCB CR-CRP50A-B Part No. Microprocessor Controls Fan & Fan Motor Type Centrifugal fan Q'ty ……. Dia. and lenght 1…. Ø 280 L 166 Fan motor model…Q'ty K35407-MO1972 …1 4… 880/740/660/290 No. Of poles…rpm (230 V, High/Med/Low/LowLow) 0,27 Running Amps Power input Ω...
-
Page 12: Other Component Specifications
1-3 Other Component Specifications ATR-IIJ225A Trasformer VAC 230V, 50Hz Rating Primary AC 20V - 0.2A Secondary 1 AC 14V - 0.3A Secondary 2 AC 10,2V - 1.4A Secondary 3 136°C Thermal cut-off temp. PBC-41E-S26 Thermistor ( Coil sensor E1, E2) 0 °C 15,0 ±... -
Page 13: Noise Criterion Curves
1-4 Noise Criterion Curves MODEL: CAFM75/95/125R5I MODEL: CAFM165/185R5I SOUND LEVEL: HIGH SPEED SOUND LEVEL: HIGH SPEED CONDITION: IN FRONT OF THE UNIT 2m CONDITION: IN FRONT OF THE UNIT 2m frequency at center frequency at center of sound pressure band (Hz) of sound pressure band (Hz) -
Page 14: Dimensional Data
2. DIMENSIONAL DATA... -
Page 15: Electrical Data
3. ELECTRICAL DATA 3-1 Electric Wiring Diagram 7P terminal board 1(L) 2(N) power inter-unit remote supply control controller wiring... -
Page 16: Control Pcb Switches And Functions
3-2 Control PCB switches and functions CR-TRP50A-B OC (CN040) EMG (CN044) VARISTOR (VA041) DISP (CN072) EXCT (CN073) FILTER (JP001) (CN070) CHK (CN071) FAN DRIVE (CN032) (CN020) T10 (CN061) POWER LED (D002) EEPROM (IC010) T10: 6 plug (yellow): used for remote control. (Refer to the remote control section) (CN061) 1- start/stop input 2- COM... -
Page 17: Function
4. FUNCTIONS 4-1 Room temperature control... -
Page 18: Automatic Control For Heating And Cooling
4-2 Automatic control for heating and cooling... -
Page 19: Replacing Pcb
5. REPLACING PCB 5-1 Replacing PCB About EEPROM (Erasable Programmable Read-Only Memory) EEPROM is a component in which the various information necessary for functionning can be electronically written or erased. This component holds informations that is essential for the running of the unit, and must be handled with care. D002 led lamp (red) -
Page 20: How To Replace Pcb
5-2 How to replace PCB... -
Page 21: How To Replace Eeprom With Eeprom Included In Pcb Service Pack
5-3 How to replace EEPROM with EEPROM included in PCB service pack... -
Page 23: Table Of Setting
5-4 Table of settings... -
Page 24: Servicing And Maintenance Functions
6. SERVICING AND MAINTENANCE FUNCTIONS... -
Page 25: Trouble Diagnosis
7. TROUBLE DIAGNOSIS 7-1 Contents of remote controller switch alarm display... -
Page 27: Outdoor Unit Control Panel Led Display
7-2 Outdoor unit control panel LED display... -
Page 28: Trouble Indications And Inspection Points
7-3 Trouble indications and inspection points... -
Page 30: Remote Controller Servicing Functions
7-4 Remote controller servicing functions... -
Page 50: Inspection Of Parts
7-6 Inspection of parts... - Page 53 R.D. 28 Reyrieux BP 131 - 01601 Trévoux CEDEX France Tél. 04.74.00.92.92 - Fax 04.74.00.42.00 R.C.S. Bourg-en-Bresse B 759 200 728...
