- Page 1 User’s Manual PROFESSIONAL POWER AMPLIFIER CA SERIES CA1N CA1L CA2N CA2L CA3N CA3L CA4N CA4L SM-11021604-ZL...
-
Page 2: Dear Customers
DEAR CUSTOMERS: Please carefully read and strictly follow the user's manual when you use CA series professional amplifier. If you have any question, please contact the local dealer. CATALOGUE Attentions Functions&features Parameters Installation Front panel Rear panel Power supply Input/Output connectors... - Page 3 The equilateral triangle with exclamatory mark means the important operation on the user's manual. FEATURES CA series is the amplifier with big power and excellent performance. It can meet different audio avenues. 1> Big power,dynamic energy; 2> Innovative heat sink structure and high quality heat sink fan assure reliable working for a long time;...
- Page 4 PARAMETERS-CA4N 1000W Stereo mode 1600W 1000W Rated Power Parallel mono mode 1600W 2000W Bridged mono mode 3200W <0.05%(10%Rated power Intermodulation <0.1%(60Hz/7kHz,10%Rated power distortion Frequency response 20Hz~20kHz(+0/-0.25dB) Phase difference < 15 Damping factors >800(8 /100Hz) Segregation >75dB >108dB(A-Weight) Total gain 39 0.5dB Difference of <0.25dB Channel gain...
- Page 5 PARAMETERS-CA4L 950W Stereo mode 1500W 950W Rated Power Parallel mono mode 1500W 1900W Bridged mono mode 3000W <0.05%(10%Rated power Intermodulation <0.1%(60Hz/7kHz,10%Rated power distortion Frequency response 20Hz~20kHz(+0/-0.25dB) Phase difference < 15 Damping factors >800(8 /100Hz) Segregation >75dB >108dB(A-Weight) Total gain 35.7 0.5dB Difference of <0.25dB Channel gain...
- Page 6 PARAMETERS-CA3N 660W Stereo mode 1000W 660W Rated Power Parallel mono mode 1000W 1330W Bridged mono mode 2000W <0.05%(10%Rated power Intermodulation <0.1%(60Hz/7kHz,10%Rated power distortion Frequency response 20Hz~20kHz(+0/-0.25dB) Phase difference < 15 Damping factors >800(8 /100Hz) Segregation >75dB >108dB(A-Weight) Total gain 37.3 0.5dB Difference of <0.25dB Channel gain...
- Page 7 PARAMETERS-CA3L 660W Stereo mode 1000W 660W Rated Power Parallel mono mode 1000W 1300W Bridged mono mode 2000W <0.05%(10%Rated power Intermodulation <0.1%(60Hz/7kHz,10%Rated power distortion Frequency response 20Hz~20kHz(+0/-0.25dB) Phase difference < 15 Damping factors >800(8 /100Hz) Segregation >75dB >108dB(A-Weight) Total gain 34.2 0.5dB Difference of <0.25dB Channel gain...
- Page 8 PARAMETERS-CA2N 330W Stereo mode 500W 330W Rated Power Parallel mono mode 500W 660W Bridged mono mode 1000W <0.05%(10%Rated power Inter modulation <0.1%(60Hz/7kHz,10%Rated power distortion Frequency response 20Hz~20kHz(+0/-0.25dB) Phase difference < 15 Damping factors >800(8 /100Hz) Segregation >75dB >108dB(A-Weight) Total gain 34 0.5dB Difference of <0.25dB...
- Page 9 PARAMETERS-CA2L 330W Stereo mode 500W 330W Rated Power Parallel mono mode 500W 660W Bridged mono mode 1000W <0.05%(10%Rated power Intermodulation <0.1%(60Hz/7KHz,10%Rated power distortion Frequency response 20Hz~20KHz(+0/-0.25dB) Phase difference < 15 Damping factors >800(8 /100Hz) Segregation >75dB >108dB(A-Weight) Total gain 31.2 0.5dB Difference of <0.25dB Channel gain...
- Page 10 PARAMETERS-CA1N 200W Stereo mode 300W 200W Rated Power Parallel mono mode 300W 400W Bridged mono mode 600W <0.05%(10%Rated power Intermodulation <0.1%(60Hz/7kHz,10%Rated power distortion Frequency response 20Hz~20kHz(+0/-0.25dB) Phase difference < 15 Damping factors >800(8 /100Hz) Segregation >75dB >108dB(A-Weight) Total gain 32 0.5dB Difference of <0.25dB Channel gain...
- Page 11 PARAMETERS-CA1L 200W Stereo mode 300W 200W Rated Power Parallel mono mode 300W 400W Bridged mono mode 600W <0.05%(10%Rated power Intermodulation <0.1%(60Hz/7kHz,10%Rated power distortion Frequency response 20Hz~20kHz(+0/-0.25dB) Phase difference < 15 Damping factors >800(8 /100Hz) Segregation >75dB >108dB(A-Weight) Total gain 29 0.5dB Difference of <0.25dB Channel gain...
-
Page 12: Installations
INSTALLATIONS CA4N/CA4L 446mm 441mm 435.7mm 430.5mm CA2N/CA2L/CA3N/CA3L 376mm 371mm 365.7mm 360.5mm CA1N/CA1L 310mm 302.5mm 298mm 292.5mm... -
Page 13: Front Panel
FRONT PANEL FOR EXAMPLE:CA4N PRO DESIGN CA SERIES BRIDGE P E A K SIGNAL POWER CA4N PROFESSIONAL AMPLIFIERS air input port signal indicator of channel B signal indicator of channel A power switch overload indicator of channel A gain adjustment pots of channel A... -
Page 14: Power Supply
Output connectors The binding post and NL4 jack in same channel of CA series amplifier are paralleled; Do not connect loads to the two connectors at the same time; The red end of binding post is connected with anode of speaker, the black end connected with cathode of speaker;... - Page 15 FUNCTION SETUP AND CABLE CONNECTING 1> Limiter setup As the below drawing, when switch is OFF, the limit is off, the limit circuit is out of work, if input signal is too strong, output can cause clip distortion and also raise overload on loudspeaker As the below drawing, when the switch is ON, the limit is on, if the input signal is too strong, the limit circuit can...
- Page 16 FUNCTION SETUP AND CABLE CONNECTING When LF cutting is at 5Hz, the audio signal 50HZ can be amplified really. Like the right drawing: 25HZ 40 50 60 80 100 300 400 500 3> Mode option and signal cable connection, Like the right drawing: XLR unbalanced...
-
Page 17: Indicators On Front Panel
OPERATIONS Please follow the steps during using the equipment 1> Start a Setup thef unctiona ndc onnectiona ccordingt ot hea bovef unctions etupa nd connecting; b Check if the output cable is short circuit and the load is too low; c Check if the local voltage complies with the user's manual;... -
Page 18: Troubles And Trouble Shootings
TROUBLES AND TROUBLE SHOOTINGS Trouble Troublele shootings Check if the power plug and jack are connected well. No voice, Power indicator If the power jack corresponds lights off with AC 220V/50~60Hz Check if the fuse on rear panel is broken. Check if the music signal cable is connected well. - Page 19 User’s Manual PROFESSIONAL POWER AMPLIFIER CA SERIES www.beta3pro.com...
