Beta Three
Professional Amplifier
T-1000
T-2000
T-3000
K-20020318

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T-2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Beta Three T-2000

Summary of Contents for Beta Three T-2000

  • Page 1 Beta Three Professional Amplifier T-1000 T-2000 T-3000 K-20020318...
  • Page 2 HIGH PERFORMANCE POWER AMPLIFIERS SPECIFICATIONS TECHNICAL PA METERS INSTALLATION FRONT &REAR PANEL 1. POWER ON 2. LEVEL 3. BRIDGE 4. PROTEC 5. CLIP 6. SIGNAL 7. AIR VENTS 8. OUTPUTS 9. GROUND ON/FLOATING 10. INPUTS...

  • Page 3: Magnetic Field

    HIGH PERFORMANCE POWER AMPLIFIERS SPECIFICATIONS P r o f e s s i o n a l A u d i o W o r k s A V I S CAUTION RISK OF ELECTRIC SHOCK RISQUE DE CHOC ELECTRIQUE DO NOT OPEN N OUVREZ PAS A PREVENIR LE CHOC...
  • Page 4 HIGH PERFORMANCE POWER AMPLIFIERS Introduction TECHNICAL PARAMETERS Output power: Bridged-Mono Stereo(W/Ch) 300W/8ohm 1000W/8ohm T-1000: 450W/4ohm 1200W/4ohm 400W/8ohm 1200W/8ohm T-2000: 600W/4ohm 1400W/4ohm 550W/8ohm 1800W/8ohm T-3000: 900W/4ohm 2000W/4ohm Frequency Response: 20Hz-50KHz(+/-0.1). Phase Response: +/-5 degree from 20Hz-50KHz. Signal to noise ratio: 105dB(A-weighted)at full output and 28 dB GAIN.
  • Page 5 HIGH PERFORMANCE POWER AMPLIFIERS Installation 1. MAINS POWER CONNECTION. Before connecting the amplifier to the mains power socket, make certain that the voltage corresponds with that indicated on the rear of the unit (an allowance of 10% is acceptable). Before connecting the power cable to the mains, always make certain that is not damaged and that there are no bare wires, always connect the power cable to the amplifier before switching it on and only remove the cable after switching it off.

  • Page 6: Front Panel

    HIGH PERFORMANCE POWER AMPLIFIERS BRIDGE T-3000 PROTECT PROFESSIONAL DESIGN Beta Three C L I P POWER SIGNAL FRONT PANEL SPEAKON CONNECTOR NOTICE OUTPUT INPUT CHA OUT CHB OUT BRIDGE OUT CAUTION +1=CHA+ +1=CHB+ +1=CHA+ RISK OF ELECTRIC SHOCK -1=CHA- -1=CHB-...
  • Page 7 HIGH PERFORMANCE POWER AMPLIFIERS 1. POWER ON ON/OFF switch with indication LED. 2.LEVEL Control of the input level of the external signal: operates with continual values which vary from" fully closed"(position" "-the signal is not fed to the amplifier sections) to "fully open"(position" 0dB")-the signal is sent to the amplifier sections at the same level as that with which it arrives at the input).
  • Page 8 K-20020318...

This manual is also suitable for:

T-1000T-3000
