Model Number
137B22A
Performance
Measurement Range(for ±5V output)
Measurement Range(for ±10V output)
Sensitivity(± 15 %)
Maximum Pressure
Resolution
Resonant Frequency
Rise Time(Incident)
Non-Linearity
Environmental
Temperature Range(Operating)
Temperature Coefficient of Sensitivity
Electrical
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Physical
Sensing Geometry
Sensing Element
Housing Material
Diaphragm
Sealing
Electrical Connector
Weight
[4]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
ICP® PRESSURE SENSOR
ENGLISH SI
500 psi 3447 kPa
[1]
1 kpsi 6895 kpsi
10 mV/psi 1.45 mV/kPa
5 kpsi 34,474 kPa
[2]
1 mpsi .007 kPa
≥ 400 kHz ≥ 400 kHz
≤ 6.5 µ sec ≤ 6.5 µ sec
[3]
≤ 1.0 % FS ≤ 1.0 % FS
-100 to +275 °F -73 to +135 °C
≤ 0.05 %/°F ≤ 0.090 %/°C
≥ 0.2 sec ≥ 0.2 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
8 to 14 VDC 8 to 14 VDC
Compression Compression
Quartz Quartz
Aluminum Aluminum
Invar Invar
Epoxy Epoxy
BNC Jack BNC Jack
[2]
12.4 oz 352 gm
OPTIONAL VERSIONS
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
NOTES:
[1] For +10 volt output, minimum 26 VDC supply voltage required. Negative 10 volt output may
be limited by output bias.
[2] Typical.
[3] Zero-based, least-squares, straight line method.
[4] See PCB Declaration of Conformance PS023 for details.
SUPPLIED ACCESSORIES:
Model PCS-6 Calibration of Series 134, 137, and 138 (1)
Entered: AP Engineer: JDK Sales: RWM
Date: 8/14/2013 Date: 8/14/2013 Date: 8/14/2013
3425 Walden Avenue, Depew, NY 14043
Revision: A
ECN #: 41884
Approved: BAM Spec Number:
55317
Date: 8/14/2013
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
