MARIMBAS
CONCERT
YM-5104A/5100A/4900A/4600A
取扱説明書
Owner's Manual
Руководство пользователя
使用手册
사용설명서
『安全上のご注意』 および 『ガススプリング取り扱いに関する注意事項』 を必ずお読みください。
Make sure to read "Precautions for Handling Gas Spring" and "Precautions".
Обязательно прочтите разделы "ПРЕДОСТОРОЖНОСТИ ПРИ ОБРАЩЕНИИ С ПНЕВМАТИЧЕСКОЙ ПРУЖИ-
НОЙ" и "МЕРЫ ПРЕДОСТОРОЖНОСТИ".
务请阅读"气弹簧操作注意事项"和"注意事项" 。
"가스 스프링 취급상의 주의사항" 및 "주의사항" 을 반드시 읽어 주십시오 .
YM-5100A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Yamaha YM-5104A
Summary of Contents for Yamaha YM-5104A
- Page 1 MARIMBAS CONCERT YM-5104A/5100A/4900A/4600A 取扱説明書 Owner’s Manual Руководство пользователя 使用手册 사용설명서 『安全上のご注意』 および 『ガススプリング取り扱いに関する注意事項』 を必ずお読みください。 Make sure to read “Precautions for Handling Gas Spring” and “Precautions”. Обязательно прочтите разделы “ПРЕДОСТОРОЖНОСТИ ПРИ ОБРАЩЕНИИ С ПНЕВМАТИЧЕСКОЙ ПРУЖИ- НОЙ” и “МЕРЫ ПРЕДОСТОРОЖНОСТИ”. 务请阅读“气弹簧操作注意事项”和“注意事项” 。...
-
Page 2: Preventing Injuries
PRECAUTIONS Using the Concert Marimba Safely The concert marimba is a large and heavy instrument that gets used in various places by persons of all ages, so please obey the following instructions regarding their regular care and placement. Especially in the case of children, a responsible adult should provide proper instruction on how to use and treat the marimba before use. - Page 3 ● Do not apply a high tensile load to the gas spring as it will cause damage to the gas spring. ● In the event of a failure, stop using the instrument and contact the shop of its purchase. If your dealer is unable to assist you, please contact Yamaha directly. Danger 2.
-
Page 4: Précautions À Observer
Précautions à observer Pour une utilisation sûre du Marimba de concert Le Marimba de concert est un instrument grand et lourd qui peut être utilisé dans différents lieux par des personnes de tous âges ; il est donc important que vous respectiez les instructions de placement et de manipulation ci-dessous. Dans les cas où... - Page 5 PRECAUTIONS Please read the following instructions carefully before using your marimbas. ◆ Installation Location Use or storage in the following locations may cause damage, even when packaged. • In direct sunlight, such as near a window, or in a closed vehicle in daytime. •...
- Page 6 Thank you for purchasing the YAMAHA concert marimbas. We, at YAMAHA, aiming principally at beautiful sounds and playing ease, have made strenuous efforts in creating the outstanding instru- ments and selecting high quality materials, and successfully developed these marimbas. We are convinced that you will enjoy playing your in- strument that produces spreading and yet deep sounds as well as rich volume to your content.
- Page 7 Rail (3) Marking on the end face (C). Rail clamp e Resonators (Natural tone side) Resonance Regulator: G (YM-5104A, YM-5100A, YM-4900A only) o Rail (4) Marking on the end face (D). YAMAHA logo r Resonators (Accidental tone side) !0 Leg (Large end)
- Page 8 ASSEMBLY For safety, the instrument should be assembled by at least two persons in a loca- tion with sufficient space. We recommend to you to assemble the instrument on a soft rug or carpet. Connect the large and the small end legs using the reinforcement stays. * Before proceeding to the next step, make sure that the slide guide fixing bolts of the large and small end legs are securely fastened.
- Page 9 ASSEMBLY 1-2. Connect the reinforcement stays at the center. Align the end of the fixing bolt and the holes in the reinforcement stays and tighten the fixing bolt securely. Screw hole Reinforcement stay (Large end) Reinforcement stay (Small end) 1-3. Install the reinforcement stay to the large end leg. Insert the “E”...
- Page 10 ASSEMBLY Insert the rails (2) and (3) into the end frames of the legs. 2-1. First, insert the rail (2). A mark “B” is printed on the big end face of the rail (2) and the groove section of the end frame of the big end leg.
- Page 11 ASSEMBLY Attach the resonators. 3-1. Unbend the resonators, apply a hook and tighten the wing nut securely. When assembling the resonator pipes, make sure that the washer is positioned on the outer side of the hook as shown in the illustration below. * Positioning the washer on the inner side of the hook can result in noise while playing.
- Page 12 4-2. Engage the rail clamps on rail (2) and rail (3) with Rail clamp rail (1) and rail (4) respectively. YM-5104A/5100A Only Rail (2) 4-3. Secure the resonators by fitting their hooks to the rail clamps engaged in Step 4-2.
- Page 13 Large end Small end Suspension cord Post Suspension cord YM-5104A/5100A/4900A Only 5-2. Each of F# , G# and A# resonators has a resonance regulator. While tapping each tone bar, move the resonance regulator to find the position where the best resonance is obtained and fix it there.
- Page 14 ASSEMBLY YM-4600A Only 5-2. As YM-4600A does not have a resonance regulator, insert resonators into resonator holders as shown below. * The resonators are factory adjusted so that the optimum resonance level is obtained at 23°C. If desirable resonance is not available due to the Resonator temperature lower or higher than 23°C, adjust setting of the resonators.
- Page 15 SPECIFICATIONS/SCALE RANGE ■ YM-5104A ■ YM-4900A Range: Range: C16 – G83 (5-1/2 octave) F21 – C76 (4-1/2 octave) ● ● Bars: Bars: Rosewood Rosewood ● ● Bar sizes: Bar sizes: ● ● 72 – 41 mm (2.8" – 1.6") wide 65 –...
- Page 16 WU03910 版次 ： 1410 R1 Printed in Japan...
