Good Earth Lighting UC1230-RPW-18LF5-G Quick Start Manual

Power/linking outlet
Prise de courant pour raccordement
Tomacorriente/salida de enlace
USB ports
Ports USB
Puertos USB
DO NOT ATTEMPT TO INSTALL LED LIGHT BAR WHILE PLUGGED IN.
This LED Light bar has a 3-prong grounded plug as a feature to reduce the risk of electric shock. This plug will fit in a grounded outlet only one way. If the plug does not
fit fully in the outlet, contact a qualified electrician. Never use power strip unless the plug can be fully inserted. Do not alter the plug.
DO NOT USE THIS FIXTURE WITH A DIMMING CIRCUIT.
Read entire installation procedure before you begin and save instructions close to the fixture for future reference.
IMPORTANT SAFETY INFORMATION
1. Use only insulated staples or plastic ties to secure the cords.
2. Route and secure the cords so that they will not be pinched or damaged.
3. LED light output is strong enough to injure human eyes. Do NOT look directly at exposed LEDs.
4. LEDs gradually emit less light over their lifetime.
5. Do NOT use an extension cord. Use power strips with integral overcurrent protection to supply other electrical devices or accessories in cabinet.
6. Suitable for INDOOR use only.
7. Do NOT mount to surfaces less than ¼ in.
8. Do NOT mount over sinks or stoves.
9. Do NOT install these lights inside of enclosed cabinets.
10. Turn power off before servicing.
11. Maximum number of fixtures per run must NOT exceed maximum power supply wattage rating of 240W. Only link with UC1229-RPW-18LF5-G, UC1230-RPW-18LF5-G,
& UC1230-RPW-24LF7-G.
12. NOT intended for recessed installation in ceiling or soffits.
Care and Maintenance
Periodically clean the fixture and diffuser using a mild, non-abrasive cleaner and soft cloth. When cleaning the fixture, make sure the power is turned off. DO NOT spray
cleaner directly onto any part of the fixture or LEDs.
AA x4
BB x2
Mark the general area where the mounting brackets (BB) will be located. Using a small drill or nail, make two small pilot holes at the marked locations. Align the mounting
brackets (BB) and drive screws (AA) into place. NOTE: Ensure mounting location is within 5ft. of an electrical outlet and that there is enough space on backside to plug in the
power cord and/or linking cord.
With USB ports facing outwards, lift the fixture toward the mounting brackets (BB) while aligning the top of the fixture channel with both clips. Apply upward pressure until
channel snaps into place and seats into both brackets.
Plug into outlet. Use included cord clips (CC) for cord management; Avoid putting nails through the cord.
Barre d'éclairage à DEL pour raccordement sans contact en dessous d'un meuble (Page 2)
Linking cord
Cordon de raccordement
Cable de enlace
Power cord
Cordon d'alimentation
Cable de alimentación
WARNINGS AND CAUTIONS
SAVE AND ATTACH RECEIPT HERE
Touchless Dimming Linking Bar Light w/ USB ports (Page 1)
Barra LED enlazable para debajo de gabinetes sin contacto (Página 4 )
Model / Model / Modelo #: UC1230-RPW-18LF5-G , UC1230-RPW-24LF7-G
Wave sensor
Capteur d'ondes
Sensor de ondas
Diffuser
Diffuseur
Difusor
18in. / 45,7 cm
60in. / 152,4 cm
Hardware kit* /
Trousse de quincaillerie* /
Kit de aditamentos*
AA x4 BB x2
* Actual hardware may differ from
illustration.
* La quincaillerie incluse peut être
différente de l'illustration.
* Los aditamentos reales pueden
diferir de los que se muestran en la
ilustración.
Required/ Nécessaire/ Obligatorio
CC x5
CC x5
