MINI COMPONENT SYSTEM
MODEL
CD-DP2400H
OPERATION MANUAL
If you require any advice or assistance regarding
your Sharp product, please visit our web-site
www.sharp.co.uk/support.
Customers without Internet access may telephone
08705 274277 during office hours (or (01) 676 0648
if telephoning from Ireland).
Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please read this
manual carefully. It will guide you in operating your SHARP product.
CD-DP2400H Mini Component System consisting of CD-DP2400H
(main unit), CP-DP2400H (front speakers), GBOXS0072AWM1 (cen-
tre speaker) and GBOXS0073AWM1 (surround speakers).
0101

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GBOXS0072AWM1 and is the answer not in the manual?

Questions and answers

Related Manuals for Sharp GBOXS0072AWM1

Summary of Contents for Sharp GBOXS0072AWM1

  • Page 1 Thank you for purchasing this SHARP product. To obtain the best performance from this product, please read this MINI COMPONENT SYSTEM manual carefully. It will guide you in operating your SHARP product. CD-DP2400H Mini Component System consisting of CD-DP2400H (main unit), CP-DP2400H (front speakers), GBOXS0072AWM1 (cen- MODEL tre speaker) and GBOXS0073AWM1 (surround speakers).
  • Page 2 NOTES Certain replacement parts and accessories may be obtained from our main parts ! Recording and playback of any material may require consent, which SHARP is distributor. unable to give. Please refer particularly to the provisions of the Copyright Act WILLOW VALE ELECTRONICS LTD.

  • Page 3: Table Of Contents

    TERMS OF GUARANTEE ........Back cover Web-site: www.sharp.co.uk/support...

  • Page 4: Precautions

    Correct a fire or other type of accident causing damage. SHARP will not be held responsible for any damage resulting from use of this unit with a voltage other than that which is specified.

  • Page 5: Controls And Indicators

    Tuner Preset Up Button ......16, 20, 21 24 25 26 27 28 29 30 Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
  • Page 6 7. Surround Speaker Terminals ......10, 11 5 6 7 Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
  • Page 7 " When the surround speakers are not installed on the wall, the speaker badge will be upside down. In this case, you can adjust the badge to face the proper direction by turning it by hand. Badge Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
  • Page 8 30.Extra Bass Button ........13 Buttons with " " mark in the illustration can be operated on the remote control only. Other buttons can be operated both on the main unit and the remote control. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 9: Remote Control

    " Exposing the sensor on the unit to strong light may interfere with operation. Change the lighting or the direction of the unit. " Keep the remote control away from moisture, heat, shock, and vibrations. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 10: System Connections

    AM loop aerial Surround speaker (Right) Surround speaker (Left) Centre speaker VCR, DVD, etc. (not supplied, see page 26.) not supplied Front speaker (Left) Front speaker (Right) Wall socket (AC 230 V, 50 Hz) Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
  • Page 11 " Do not allow any objects to fall into or to be placed in the bass reflex ducts. " Do not stand or sit on the speakers. You may be injured. Incorrect Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
  • Page 12 60 - 90 cm (23" - 35") Note: Unplug the AC power lead from the wall socket if the unit will not be in use for a pro- longed period of time. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 13: General Control

    Treble is cut a little. ! To change the display brightness (2 levels) Treble is reduced a lot. You can switch the display brightness by pressing the DIMMER button. Vocals (midrange tones) are emphasised. Dimmed Brightened Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 14: Setting The Clock

    (AM 0:00 - PM 11:59) Note that this can only be set when the unit is first installed or it has been reset. [Refer to "Clearing all the memory (reset)" on page 30 for details.] Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 15: Listening To A Cd (Cds)

    If the CD contains more than 15 tracks, " " will appear. To select the CD you want to listen to first, press one of the DISC- 1 - DISC-3 buttons. Continued to the next page Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
  • Page 16 CD operation will be paused. When the beginning of the first track is reached during fast reverse, the unit will enter the playback mode. ! The button on the remote control allows you to locate the desired portion. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 17: Repeat Or Random Play

    Caution: After performing repeat or random play, be sure to press the (CD ) button. Other- wise, the disc(s) will play continuously. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 18: Programmed Play

    ! Even if you press the ON/STAND-BY button to enter the stand-by mode or change the function from CD to another, the programmed selections will not be cleared. ! During programme operation, random play is not possible. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 19: Listening To The Radio

    ! If the FM reception is weak, press the TUNER (BAND) button to extinguish the "ST" indicator. The reception changes to monaural, and the sound becomes clearer. After use: Press the ON/STAND-BY button to enter the power stand-by mode. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 20: Listening To The Memorised Station

    When a new station is stored in memory, the station previously memorised will be erased. Note: The backup function protects the memorised stations for a few hours should there be a power failure or the AC power lead disconnection. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 21: Listening To A Cassette Tape (Tape 1 Or Tape 2)

    ! If a power failure occurs during tape operation, the tape head will remain engaged with the tape and the cassette door will not open. In this case, wait until the power is restored. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 22: Recording To A Cassette Tape

    " Recording from a CD (CDs) ! SHARP is not liable for damage or loss of your recording arising from malfunction of this unit. You can record 3 CDs continuously. ! The volume and sound controls can be adjusted with no effect on the recorded signal (Variable Sound Monitor).
  • Page 23 Press the button on the main unit or the TAPE 2 button on the remote con- the tab. trol to start erasing. Note: Make sure that the TAPE 1 is not in use. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 24: Timer And Sleep Operation

    REC" is displayed. For timer playback For timer recording Press the TUNING/TIME ( or ) button to specify the hour to start, then press the MEMORY/SET button. The illustrations show the timer playback setting. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
  • Page 25 It will enter the power stand-by mode when the end of the recording tape is reached in timer recording or 1 hour after the playback starts in timer playback. However, another unit will not be turned on or off. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 26: Enhancing Your System

    " Be sure your headphones have a 3.5 mm (1/8") diameter plug and are between 16 ohms and 50 ohms impedance. The recommended impedance is 32 ohms. " Plugging in the headphones disconnects the speakers automatically. Adjust the volume using the VOLUME control. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 27: Enjoy The Surround Sound

    Dolby Pro Logic. This mode is memo- Front speaker (Left) Front speaker (Right) rised until a new mode is selected. Surround speaker (Left) Surround speaker (Right) Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)
  • Page 28 " The volume settings for the centre and surround speakers are stored in memory for future use. However, after a power failure or unplugging the unit, they will return to initial settings. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 29: Troubleshooting Chart

    If something is wrong with this product, check the following before calling your author- Symptom Possible cause ised SHARP dealer or service centre. " Cannot record. " Is the erase-prevention tab removed? ! General " Cannot record tracks with proper "...

  • Page 30: Maintenance

    OPEN/CLOSE button to close the disc tray. Make sure that "NO DISC" is displayed. Press the ON/STAND-BY button to enter the stand-by mode, and then unplug the AC power lead from the wall socket. Web-site: www.sharp.co.uk/support Help Line: 08705 274277 (office hours)

  • Page 31: Specifications

    Specifications CD-DP2400H As part of our policy of continuous improvement, SHARP reserves the right to make ! Cassette deck design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units.

  • Page 32: Terms Of Guarantee

    3. To benefit from this guarantee, any fault which occurs must be notified to Sharp, or its appointed Service Facility within one year from the date this product was purchased. Proof of purchase must be provided.
