- Page 1 DVD+Hi-Fi VCR Combo Home Theater System Owner’s Manual Model : LH-C6235 CD-R/RW Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely.
-
Page 2: Safety Precautions
Safety Precautions CAUTION: The apparatus should not be exposed to water CAUTION (dripping or splashing) and no objects filled with liquids, such as vases, should be placed on the apparatus. RISK OF ELECTRIC SHOCK DO NOT OPEN FCC WARNING: This equipment may generate or use radio frequency energy. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL. AND THOSE MARKED ON THE PRODUCT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE. This product has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. -
Page 4: Table Of Contents
Table of Contents Introduction Time Search ......30 3D Surround ......30 Safety Precautions . -
Page 5: Before Use
Before Use Playable Discs Disc-related Terms Title (DVD only) The main film content or accompanying feature content or music album. (8 cm/12 cm disc) Each title is assigned a title reference number enabling Audio CD you to locate it easily. (8 cm/12 cm disc) Chapter (DVD only) In addition, this unit can play CD-Rs or CD-RWs that... -
Page 6: Precautions
Before Use (Continued) Precautions Cleaning discs Fingerprints and dust on the disc can cause poor pic- Handling the unit ture quality and sound distortion. Before playing, clean the disc with a clean cloth. Wipe the disc from the cen- When shipping the unit ter out. -
Page 7: Front Panel Controls
Front Panel Controls OPEN/CLOSE (Z Z ) EJECT(Z Z ) Opens or closes the disc tray. Ejects the tape in the VCR deck. Remote Sensor PAUSE/STEP(X X /C Point the DVD+Hi-Fi VCR remote Pause playback of a tape or a disc in the DVD or control here. -
Page 8: Display Window
Display Window A disc is loaded in the DVD deck. (Lights when a disc is loaded in the DVD deck and flashes when the disc tray is opened. Indicates current DVD+Hi-Fi VCR is in VCR timer recording mode audio stream or a VCR timer recording is programmed. -
Page 9: Remote Control
Remote Control FM/AM Tuner select button POWER Select the DVD+Hi-Fi VCR’s tuner as Switches DVD+Hi-Fi VCR ON and OFF. the listening choice. (FM and AM bands) VIDEO 1/2 OPEN/CLOSE, EJECT (Z Z ) Selects a source connected to the rear - Opens and closes the disc tray. -
Page 10: Rear Panel Controls
Rear Panel Controls VIDEO 1 MONITOR OUT (VIDEO IN/AUDIO IN (Left/Right)) Connect to a TV or MONITOR Connect the audio/video output of an external source (Audio system, TV/Monitor, another VCR). S-VIDEO OUT (DVD OUT) Connect to a S-Video Input on TV. FOR DVD VIEWING ONLY. -
Page 11: Connections
Connections Without Cable Box If your cable wire is connected to your TV without a converter Depending on your TV and other equipment you wish to or descrambler box, unscrew the wire from your TV and attach connect, there are various ways you could connect the it to the ANTENNA/CABLE IN jack on the DVD+Hi-Fi VCR. -
Page 12: Basic Tv Connections
Connections (Continued) Basic TV Connections Rear of TV Make one of the following connections, depending on ANTENNA S-VIDEO VIDEO AUDIO INPUT INPUT INPUT INPUT the capabilities of your existing equipment. RF coaxial connection Connect the ANTENNA/CABLE OUT jack on the DVD+Hi-Fi VCR to the antenna in jack on the TV using the 75-ohm Coaxial Cable supplied (R). -
Page 13: Radio Antenna Connections
Connections (Continued) Radio Antenna Connections Connect the supplied FM/AM aerial for listening to the radio. Connect the AM loop aerial to the AM aerial connector. Connect he FM wire aerial to the FM aerial connector. otes To prevent noise pickup, keep the AM loop aerial away from the DVD+Hi-Fi VCR and other components. Be sure to fully extend the FM wire aerial. -
Page 14: Speaker Connections
Connections (Continued) Speaker System Connection Connect the speakers using the supplied speaker cords. To obtain the best possible surround sound, adjust the speaker parameters (distance, level, etc.). Center speaker Front speaker Front speaker (Right) (Left) FRONT REAR CENTER REAR FRONT WOOFER (R 4 ) (L 4... -
Page 15: Glossary For Audio Stream & Surround Mode
Grossary for Audio Stream & Surroiund mode Sound Mode The Dolby Digital surround format lets you enjoy up to 5.1 You can enjoy surround sound simply by selecting one channels of digital surround sound from a Dolby Digital pro- of the pre-programmed sound fields according to the gram source. -
Page 16: Vcr Operation Setup
VCR Operation Setup On-Screen Display (OSD) EASY INFORMATION If the Extended Data Service (XDS) signals are provided Some of these functions appear during VCR operated. along with normal TV signal in your area or during play- back of a tape recorded with Extended Data Service ❶... -
Page 17: Vcr Setup Menu Options
VCR Operation Setup (Continued) VCR Setup Menu Options Channel Selection This DVD+VCR is equipped with a frequency Press MENU and the MAIN menu will appear. synthesized tuner capable of receiving up to 181 channels. These include VHF channels 2-13, UHF Use v v /V V to select the SETUP menu, then press channels 14-69 and CATV channels 1-125. -
Page 18: Setting The Clock
VCR Operation Setup (Continued) Setting the Clock There are cases where the TV station does not send or sends The DVD+Hi-Fi VCR gives you two ways to set the time wrong date and/or time information and the DVD+VCR sets the and date: the Auto Clock Feature or manually. -
Page 19: Dvd Operation Setup
DVD Operation Setup General Explanation Press 1 1 /2 2 to change the setting of an item. The number buttons can be also be used for setting This manual gives basic instructions for operating the numbers (e.g., title number). For some functions, DVD+Hi-Fi VCR. -
Page 20: Initial Settings
DVD Operation Setup (Continued) Initial Settings Language Disc Language You can set your own Personal Preferences on the DVD+Hi-Fi VCR. Select a language for the disc’s Menu, Audio, and Subtitle. Initial Settings General Operation Original : The original language set for the disc is selected. Other : To select another language, press number buttons to Press SETUP. -
Page 21: Speaker Setup
DVD Operation Setup (Continued) Speaker setup Auto Play You can set up the DVD+Hi-Fi VCR so a DVD disc auto- 5.1 Speaker settings matically starts playing whenever the DVD is inserted. Select speaker settings, including volume balance and If Auto Play mode is set to On, this DVD+Hi-Fi VCR will delay time, or test the speaker settings. -
Page 22: Parental Control
DVD Operation Setup (Continued) Parental Control Country Code Enter the code of a country/area whose standards were Rating used to rate the DVD video disc, referring to the list Movies on DVDs may contain scenes not suitable for (See “Country Code List”, page 41.). children. -
Page 23: Vcr Operation
VCR Operation Normal Playback Special Effect Playbacks Preparation: Special effects playback notes Turn on the TV. Horizontal lines (noise bars) will appear on the TV screen. Tune the TV to the DVD+Hi-Fi VCR output channel (CH 3 or This is normal. 4) or set the TV’s source selector to VIDEO. -
Page 24: Normal Recording
VCR Operation (Continued) Normal Recording Timer Recording Preparation: This DVD+Hi-Fi VCR can be programmed to record up to Turn on the power of both the DVD+Hi-Fi VCR and TV. 8 programs within a period of 1 year. For unattended Tune the TV to the DVD+Hi-Fi VCR output channel (CH 3 or recording, the timer needs to know the channels to be 4) or set the TV’s source selector to VIDEO. - Page 25 VCR Operation (Continued) Checking (Erasing) Timer Record Use V V to choose the SPEED option. 1 1 0 0 Use b b /B B to choose the desired recording Programming speed (AUTO, SP or SLP). Programming can be checked whenever the DVD+HiFi AUTO mode determines how much tape is left and VCR is turned on.
-
Page 26: Instant Timer Recording
VCR Operation (Continued) Instant Timer Recording Dubbing and Editing If you wish to edit or dub your camcorder (or another Instant Timer Recording allows you to make a recording VCR) recordings to this DVD+Hi-Fi VCR, the rear (or easily of a preset length without using the programma- Front) panel mounted Audio and Video (A/V) input ble timer. -
Page 27: Vhs Hi-Fi Stereo System/Mts Broadcast
VCR Operation (Continued) VHS Hi-Fi Stereo System/ MTS (Multi-Channel TV Sound) MTS Broadcast This DVD+Hi-Fi VCR will decode MTS stereo and bilin- gual (SAP) off-the-air broadcast sound signals. It also This DVD+Hi-Fi VCR is equipped with the VHS Hi-Fi decodes stereo TV sound from local cable companies, audio sound system for recording and playback. -
Page 28: Tape Counter Memory Feature
VCR Operation (Continued) Tape Counter Memory Feature Additional Information Real-Time Counter In manual recording, Timer recording, Instant Timer Recording, playback, or fast forward modes, the DVD+Hi-Fi Shows length of tape run in hours, minutes, and VCR automatically starts rewinding the tape at the end of seconds. -
Page 29: Dvd Operation
DVD Operation Playing DVDs General Features Playback Setup Unless stated otherwise, all operations described use Turn on the TV and select the video input source con- the remote control. Some features may also be nected to the DVD+Hi-Fi VCR. available on the Setup menu. Audio system: Turn on the audio system and select the input source connected to the DVD+Hi-Fi VCR. -
Page 30: Still Picture And Frame-By-Frame Playback
DVD Operation (Continued) General Features (Continued) Time Search 0:20:09 -:- -: -- The Time Search function allows you to start playing at Still Picture and Frame-by-Frame Playback any chosen time on the disc. 1 Press DISPLAY during playback. The on-screen dis- 1 Press PAUSE/STEP (X) during playback. -
Page 31: Marker Search
DVD Operation (Continued) General Features (Continued) Special DVD Features Marker Search Checking the contents of DVD Video MARKER SEARCH discs: Menus You can start playback from a memorized point. Up to DVDs may contain menus that allow you to access spe- nine points can be memorized. -
Page 32: Audio Cd And Mp3 Disc Operation
Audio CD and MP3 Disc Operation Playing an Audio CD and MP3 Disc Notes on MP3 Recordings About MP3 An MP3 file is audio data compressed by using the The DVD+Hi-Fi VCR can play MP3 formatted record- MPEG1 audio layer-3 file-coding scheme. We call ings on CD-ROM, CD-R or CD-RW discs. -
Page 33: Pause
Audio CD and MP3 Disc Operation (Continued) Pause 3D Surround 1 Press PAUSE/STEP during playback. This unit can produce a 3D Surround effect, which 2 To return to playback, press PLAY, PAUSE/STEP or simulates multi-channel audio playback from two MEMORY/ENTER again. conventional stereo speakers, instead of the five or more speakers normally required to listen to multi- channel audio from a home theater system. -
Page 34: Programmed Playback
Programmed Playback Programmed Playback with Audio CD Repeat Programmed Tracks and MP3 Disc To repeat the track currently playing, press REPEAT. The Program function enables you to store your The Repeat icon and “TRACK” appears on the TV screen. favourite tracks from any disc in the player memory. To repeat all tracks on the program list, press REPEAT a second time. -
Page 35: Speaker Setup
Speaker Setup Adjust the following settings for the built-in 5.1 channel Speaker selection surround decoder. Select a speaker that you want to adjust. ((Front speak- ers (Left), Front speakers (Right), Centre Speaker, Rear Disc Audio speakers (Left), Rear speakers (Right), Subwoofer)) Disc Subtitle Disc Menu Rating... -
Page 36: Radio Operation
Radio Operation Presetting the radio stations Listening to the Radio You can preset 30 stations for FM and AM. Before tun- Preset radio stations in the DVD+Hi-Fi VCR memory ing, make sure that you have turned down the volume. first (see “Presetting radio stations” on the left). Press FM/AM on the remote control or on the Press FM/AM on the remote control or press front panel until the frequency band appears on... -
Page 37: Tuning Into A Station Manually
Operation with Radio (Continued) Tuning into a Station Manually Tuning into a Station Automatically Press FM/AM on the remote control or on the Hold down 4 TUNING 3 on the front panel or hold front panel until the frequency band appears on down 1 and 2 on the remote control for 1 or 2 the display and TV screen. -
Page 38: Troubleshooting
Troubleshooting Check the following guide for the possible cause of a problem before contacting service. Symptom Cause Correction The power cord is disconnected. Plug the power cord into the wall outlet No power. securely. No disc is inserted. Insert a disc or tape. (Check that the The power is on, but No tape is inserted. - Page 39 Troubleshooting (Continued) Cause Correction Symptom Some channels are Those channels were deleted with the Use CH. ADD/DEL. to restore channels. skipped over when CH. ADD/DEL option. See “Channel Selection” on page 17. using CH/TRK (v/V) Picture and sound of Antenna or cables are loose. Tighten connections or replace cable.
-
Page 40: Language Code List
Language Code List Dvd+hi-fi memory/enter the appropriate code number for the initial settings “Disc Audio”, “Disc Subtitle” and/or “Disc Menu” (See page 20). Language Code Language Code Language Code Language Code Abkhazian 6566 Fiji 7074 Lingala 7678 Singhalese 8373 Afar 6565 Finnish 7073... -
Page 41: Country Code List
Country Code List Dvd+hi-fi memory/enter the appropriate code number for the initial setting “Country Code” (See page 22). Code Country Code Country Code Country Code Country Andorra Eritrea Saint Lucia Seychelles United Arab Emirates Spain Liechtenstein Sudan Afghanistan Ethiopia Sri Lanka Sweden Antigua and Barbuda Finland... -
Page 42: Specifications
Specifications General Power requirements AC 120V, 60 Hz Power consumption 130W Dimensions (approx.) 430 X 90 X 350 mm (16.9 x 3.5 x 13.8 inches) (w x h x d) Weight (approx.) 8 kg (17.6 lbs) Operating temperature 5˚C to 40˚C (41˚F to 104˚F) Operating humidity 5 % to 90 % Signal system... - Page 43 Specifications (Continued) Speakers Satellite Type 1 Way 1 Speaker 4 Ω Impedance Frequency Response 130 - 20,000 Hz Sound Pressure Level 83 dB/W (1m) Rated Input Power Max Input Power Net Dimensions (W x H x D) 88 x 100 x 95 mm Net Weight 0.54 kg Passive Subwoofer...
- Page 44 Warranty P/N: 3828R-D050A Printed in Indonesia...
