M-system W5 Series Instruction Manual page 3

DIMENSIONS unit: mm (inch)
SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM
Z
Low Drift
+
4
Amplifier
*
INPUT
–
5
1
2
3
*Input shunt resistor attached for current input.
Remark 1: The section enclosed by broken line is only with 2nd output option.
Remark 2: DO NOT connect to the terminals 1 – 2 – 3.
Specifications are subject to change without notice.
SEN TRONIC
AG
Produkte, Support und Service
1 2 3 4
6 7 8 9 10
45 (1.77)
S
Isolation
Output
Driver
Z S
Output
Driver
Rugghölzli 2
CH - 5453 Busslingen
7.4 (.29)
5–M3.5 SCREW
5
6 (.24)
11
6–M3 SCREW
• When mounting, no extra space is needed between units.
+
6
OUTPUT 1
–
7
+
8
OUTPUT 2
–
9
10
U(+)
POWER
11
V(–)
Tel. +41 (0)56 222 38 18
Fax +41 (0)56 222 10 12
MODEL: W5VS
DIN RAIL
35mm wide
41 (1.61) [3.3 (.13)]
