- Page 1 GUIDE D'INSTALLATION & D'UTILISATION OPERATING AND INSTALLATION INSTRUCTIONS Réfrigérateur-Congélateur Fridge-Freezer...
- Page 2 Dear Customer, You have just acquired a BRANDT fridge-freezer and we would like to thank you. We have invested all our dedication and know-how in this appliance so that it would best meet your needs. With innovation and performance, we designed it to be always easy to use.
-
Page 3: Table Of Contents
Contents Safety and the environment • Safety instructions.................... • Respecting the environment and saving energy..........• BIOCARE - anti-bacterial walls ................Description of your appliance How to carry out your initial installation • Reversing the direction the doors open ............. •... -
Page 4: Safety Instructions
Safety instructions This appliance is intended for domestic use only. It has been designed for preserving and freezing food. The following instructions are for your own safety and should be observed without fail. We can neither be held responsible, nor uphold the guarantee in case of failu- re to observe these recommendations, which may lead to material damage or phy- sical injury. -
Page 5: Respecting The Environment And Saving Energy
Respecting the environment and saving energy To reduce your appliance’s electrical consup- uses a gas called R600a. The exact type of re- tion: frigerant used in your appliance is also clearly indicated on the identification plate inside your • Install it in a suitable place see "Installa- appliance's refrigerator section, low down on tion of your appliance"... -
Page 6: Description Of Your Appliance
Description of your appliance Control panel Butter rack with glass shutter Lighting Ventilation system* Anti-bacterial walls Door rack Removable shelves Bottle rack Maxi-Fresh* Vegetable drawer or containers * Mini rack Removable Maxi box with “condiments and herbs” space Ice trays Freezer drawers Plinth * depending on the model... -
Page 7: Reversing The Direction The Doors Open
Reversing the direction the doors open The doors normally open to the left (hinges on the right); if you wish to open the door to the right, you can modify the direction in which it opens by following the instructions below. To ensure cor- rect installation, please scrupulously follow the directions and the sequence of operations below. - Page 8 Reversing the direction the doors open 11. The upper left-hand hinge L is placed inside the drawing R6 plinth (R6). Remove it and inset it into the housing on the left on the control panel M . Fasten it with the two screws (R7).
-
Page 9: Installing Your Appliance
Installing your appliance Your appliance must be installed in compliance with the instructions given in this "Operating and installation instructions manual" in order to keep your food under optimum conditions and with optimal energy consumption. • The appliance should be installed in a •... -
Page 10: Electrical Connection
Electrical connection For your own safety, you must comply with the instructions given below. The electrical installation must comply Recommendations for the electri- with Standard NF C *15-100, in particu- cal installation of your appliance : lar concerning the Earth. •... -
Page 11: Starting And Setting The Appliance
Starting and adjusting the appliance Yellow quick freeze led Red alarm led Light switch Quick freeze Freezer green Refrigerator green ON led ON led General start button/ Refrigerator thermostat Freezer thermostat Starting the appliance and setting the freezer's thermostat This function stops automatically after 52 hours unless you interrupt it manually before Turn the general "Start"... - Page 12 Starting and adjusting the appliance Setting the refrigerator's thermostat Temperature indicator and "Cold Zone" To adjust the refrigerator's temperature, turn symbols the "Refrigerator Thermostat" knob on the You will find the symbol opposite control panel. Position 1 indicates the least in your refrigerator.
-
Page 13: Mixed Or Regulated Cold (Depending On The Model)
Mixed or regulated cold (depending on the model) This guide to installing and using your fridge-freezer is applicable to several models. Your appliance is equipped with one or other of these functions. You can check very quic- kly by comparing your refrigerator to the illustrations on this page. -
Page 14: Preparing Food For The Refrigerator
Preparing food for the refrigerator Before placing food in your appliance: Let hot dishes and drinks cool down outside the appliance. Carefully wrap fresh foods: they will then keep their flavour, colour, humidity content and Remove the cardboard packs from around yo- freshness. -
Page 15: Your Refrigerator's Modular Layout
Arranging food in your refrigerator "Cold Zone" symbols Leave a space between the food items to allow the air to circulate freely and avoid different The coldest area, indicated by products contaminating each other. the logo opposite, is designed for delicate, sensitive and highly perishable food: meat, poultry, Do not put packages and food in contact with fish, cooked meats, prepared dishes, ready-... -
Page 16: Frozen And Deep-Frozen Food
Frozen and deep-frozen food Your domestic appliance enables you to freeze Deep-freezing is an industrial process that is food: it lowers its core temperature rapidly and quicker and more intense that domestic free- you can therefore keep it longer. zing. The products you purchase from the shops are deep-frozen. -
Page 17: Food Freezing Guide
Food freezing guide Fresh meat Product Valid for Lamb,small pieces 8 months Roast pork 5 months Pork ribs 4 months Boiled beef,roast beef 10 months Beef steak,entrecotes,in sauce,roast veal 8 months Veal steaks,cutlets 10 months Minces meat 4 months Giblets,offal 3 months Sausages 2 months... - Page 18 Food freezing guide Cooked food The length of time you can store cooked dishes reduces if you use bacon or smoked ham to season dishes. Product Valid for Preparatory cooking Sauce with meat juices half-cooked 3 months Tomato sauce just-cooked Minestrone with vegetables 2 months no pasta...
- Page 19 Food freezing guide Fruits Fruit must be covered with sugar or syrup, as appropriate. The amount of sugar to use is around 250g for 1 kilo of fruit. Syrups are used in varying percentages; these are prepared by boiling sugared wa- ter.
-
Page 20: Arranging Food In Your Freezer
Arranging food in your freezer Do not put fresh food next to food that has The maximum weight of food that already been frozen to avoid causing the fro- you can freeze over 24 hours is zen food to warm up. shown on the information plate (in- side your appliance's refrigerator section near the bottom of the left-... -
Page 21: Defrosting Food
Defrosting food You can defrost food in five different ways: Never refreeze food once it has de- frosted, even partially, without • By putting them in your appliance's refri- cooking it first. gerator section for several hours We would advise you not to place •... -
Page 22: Ongoing Maintenance Of Your Appliance
Ongoing maintenance of your appliance Disconnect your appliance prior to performing any maintenance operation. Grasp the plug directly, instead of pulling on the power cable. Cleaning your appliance We recommend that you clean and Periodically check that the drain hole for the disinfect your appliance regularly defrosting water is not blocked and clean it for improved hygiene and to keep... -
Page 23: Changing The Light Bulb
Ongoing maintenance of your appliance Changing the light bulb The sliding compartment for fruit and vegeta- bles is fitted with a filter that controls the hu- Disconnect your appliance midity by adapting it for optimum preservation • Unscrew the screw holding the interior li- of these foodstuffs. -
Page 24: Noises, Inconveniences And Minor Breakdowns
Noises, inconveniences or minor breakdowns Normal operating noises So that the selected temperature remains constant, your appliance regularly switches off its motor. The resultant noises are quite normal operating noises. They reduce automatically as soon as your refrigerator reaches the desired temperature. These noises are as follows: NOISE CAUSE Coming from the motor.This buzzing may briefly be louder when... - Page 25 Noises, inconveniences or minor breakdowns PROBLEM ADVICE Frost forms inside your - be careful not to open your appliance’s door too often, and not appliance to leave it open - this is quite normal. It stops condensation forming on the outside The external walls are warm of your appliance -When your home’s heating is not on (for example in spring and...
- Page 26 When making an appointment, state the full reference of your equipment (model, type and serial number). This information appears on the manufacturer's nameplate attached to your equipment. Brandt Appliances - SAS au capital de 10.000.000 euros, RCS Nanterre sous le n 440 302 347 174.5906.3...
