STEP 5- ATTACH THE ARTICULATION UNIT AT THE CEILING PLATE
STEP 5A- ATTACH THE ARTCULATION UNIT AT THE CEILING PLATE
DROP CEILING INSTALLATION
MINIMUM 2 TURN ENGAGEMENT
STEP 5A- ATTACH THE ARTCULATION UNIT AT THE CEILING PLATE
STEP 6- ATTACH THE PROJECTOR LEGS AT THE PROJECTOR PLATE
H
F
STEP 7- ATTACH THE PROJECTOR TO THE MOUNT
Choose the proper leg posts and
attach to the projector
A
B
C
D
IMPORTANT!
TIGHTEN UNTIL SNUG
E
Tighten the set screw
to fix the mount
X4
V1
P6
