RVM-64CM125
TV Ceiling Mount
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
MANUEL D'INSTRUCTIONS
Reduce
Reuse
Recyle
!
CAUTION:
THE MAXIMUM LOADING
WEIGHT IS 125 LBS. USE WITH PRODUCTS
HEAVIER THAN THE MAXIMUM WEIGHT
INDICATED MAY RESULT IN INSTABILITY AND
POSSIBLE PERSONAL INJURY.
Max Screen Size: 70"
V1
P1
Advertisement
Related Manuals for Rapid video mounts RVM-64CM125
Summary of Contents for Rapid video mounts RVM-64CM125
- Page 1 RVM-64CM125 Reduce TV Ceiling Mount Reuse INSTRUCTION MANUAL Recyle MANUAL DE INSTRUCCIONES MANUEL D’INSTRUCTIONS CAUTION: THE MAXIMUM LOADING WEIGHT IS 125 LBS. USE WITH PRODUCTS HEAVIER THAN THE MAXIMUM WEIGHT INDICATED MAY RESULT IN INSTABILITY AND POSSIBLE PERSONAL INJURY. Max Screen Size: 70”...
-
Page 2: Tools Needed
Tampoco prevé todas las posibles contingencias relacionadas con la instalación o el uso de este producto. La información que contiene este documento queda sujeta a cambio sin aviso previo o compromiso alguno. RAPID VIDEO MOUNTS no ofrece ninguna garantía, ni expresa ni implícita, respecto de la información aquí incluida. RAPID VIDEO MOUNTS no se responsabiliza de la precisión de la información provista en este documento, ni tampoco de que sea completa o suficiente. - Page 3 HARDWARE PRODUCT NUMBERS SQUARE M8 x 30 M4 x 30 M5 x 30 M6 x 30 M8 x 15 M6 x 15 M4 x 12 M5 x 12 SPACER WASHER M8 x 45 ALLEN KEY M5 SET SCREW ALLEN KEY LAG BOLT LAG BOLT STEEL...
- Page 4 STEP 1- FLAT BACK TV (UNIVERSAL MONITOR PLATE) Connect Universal Monitor Plate to TV Conecte el adaptador al monitor Connectez l'adaptateur au moniteur STEP 1- CURVED BACK TV (UNIVERSAL MONITOR PLATE) Connect Universal Monitor Plate to flat panel Conecte el adaptador al monitor Connectez l'adaptateur au moniteur Spacers can also be used to provide clearance for cables...
- Page 5 STEP 1- USE M8 STEEL WASHER IF THE PHILLIPS SCREWS FROM THE MONITOR KIT ARE TOO LONG Diagrams show three options for using additional washers if hardware screws are too long to properly tighten into back of television. select the proper spacers or spacer suit as below if necessary...
- Page 6 STEP 1- CENTER UNIVERSAL MONITOR PLATE Monitor Plate must be centered (horizontal plane) on back of TV Secure vertical rails to horizontal chrome rod on Monitor Plate with pre-installed screws.
- Page 7 STEP 2- ASSEMBLE THE CEILING MOUNT...
-
Page 8: Step 3- Wood Stud Installation
STEP 3- WOOD STUD INSTALLATION Wood Pilot Pilot Hole Size Pilot Drill Depth 7/32” inch 2.75 inch 5.5 mm 70 mm... - Page 9 STEP 4- ATTACH THE PIPE ASSEMBLY AT THE CEILING PLATE. M5 Set Screw Allen Key 2.5mm Adjust the pipe assembly to Rotate the pipe assembly to the best direction , then tighten the ceiling plate, assemble the the set screw with the security two parts.
- Page 10 STEP 5- LIFT AND HANG THE MONITOR PLATE AT THE PIPE ASSEMBLY. Secure Acorn Nut and Washer on a) Rotate handle clockwise as far as Monitor Plate to Pipe possible. Assemble (snug b) Pull handle to side laterally tension only) (against spring tension) and rotate counter-clockwise as far as possible.
-
Page 11: Step 6- Cable Management
STEP 6- CABLE MANAGEMENT... -
Page 12: Warranty Information
Esta garantía se aplica a los residentes de los Estados Unidos que realizaron la compra en un distribuidor autorizado de RAPID VIDEO MOUNTS. Esta garantía cubre los productos RAPID VIDEO MOUNTS de los defectos de materiales y de mano de obra por un periodo de 5 años. RAPID VIDEO MOUNTS, a su exclusivo criterio, reparará o reemplazará...
