Symbols; Hardware Product Numbers; Product Component Parts - Rapid video mounts RVM-PROJM1 Instruction Manual

SYMBOLS

Drill Level
Agujerear Nivel
Percer Niveau

HARDWARE PRODUCT NUMBERS

A B
Leg post Leg post
M3x6 M4x8
x4 x4
H
Phillips Screw
M5x12
x4

PRODUCT COMPONENT PARTS

150lbs
Socket Wrench
Llave española
MW150F64
Clé ouverte
C
Leg post
M5x10
x4
11 13
lag bolts steel washer
x4 x4
3
7
2
6
1
Caution Tighten
Precaución Ajustar
Attention Serrer
E
D
Leg post Leg post
M6x10 M5x20
x4 x4
Product Components
Pr
Contents Qty Description
4
5
Pencil Mark
Screwdriver
Marque con lápiz
Destornillador
Marque de crayon
Tournevis
F
Rectangular Nut
M5
x4
1 1
Projector Plate
2 1 Articulation Unit
3 1 Ceiling Plate
4 4 Leg Post Covers
5 4 Projector Legs
Locking Screw
6 1
Ceiling Plate Cover
1
7
Heavy!
Tres Lourd!
!Pesado!
G
Allen Wrench
3mm
x1
P3
