PR Housewares Concept Housewares PR-40903 Quick Start Manual

Assembly:

To install, you will need the following:
- Pencil and tape measure
- Phillips head screw driver and or a standard or flat head
screwdriver
- Hammer
- Electric drill and 5/16 drill bit

Parts:

- Main unit (See Photo – A)
- Pan hooks, PR-41208 and PR-41205 (See Photo –B)
- Package of wall screws, plastic anchors and plastic key (See
Photo – C)
Please consult with your local hardware store if you have
any questions or concerns about the construction of your
walls or ceilings. They can assist you in selecting the proper
hardware and procedures. The generic hardware provided
will work for most drywall applications. NOTE: these units
are handmade, slight variations can exist, always measure
twice before drilling.

Mounting Directions:

Assemble rack with all supports, then with rough frame
work constructed use as a guide for installation. Measure
carefully where you want to mount the rack on the wall use
a pencil to mark where the screws attach to the wall.
Remove the unit and drill holes using a 5/16" drill bit. When
/ if possible mount to a wall stud. Supplied anchors have a
pull rating of 20 lbs. or more each and a shear rating of 50
lbs. each.
Insert the anchors into the drilled holes. They may need to be
tapped in gently with a hammer. Use the supplied key to expand the
anchor behind drywall. (See Photos B to F on next page for proper
and improper anchor install). Use
supplied screws to attach.
Wall Mounted Stainless Pot Racks
Models PR-40903 and PR-40904
Concept Housewares, A Division of PR Housewares, LLC
www.prhousewares.com Email: info@prhousewares.com
Page 1
Photo A - Fully Assembled
Photo B - Pan Hooks
Photo C - Wall screws, plastic
anchors and plastic key
