PR Housewares Concept Housewares PR-40232 Assembly Instructions

Assembly:

To install, you will need the following:
- Pencil and tape measure
- Phillips head screw driver if needed and pliers.
- Electric drill with assorted bits

Parts:

- Main unit (See Photo – A)
- Package of ceiling hooks (See Photo – B)
- PR-41207 pan hooks used in corners for
mounting (See Photo – C)
- 4 of the supplied pan hooks are used in corners
for hanging the rack to links
- 4 lengths of hanging chain, pan hooks PR-41207 and
swivel pan hooks PR-41213
Please consult with your local hardware store if you have
any questions or concerns about the construction of your
walls or ceilings. They can assist you in selecting the proper
hardware and procedures. The generic hardware provided
will work for most applications. Always measure twice
before drilling. NOTE: If you have any doubt about your
installation or your ceilings ability to offer the proper
support for your pot rack, please contact a professional.

Mounting Directions:

Determine where ceiling joist (beams, studs) are located.
Place ceiling hooks so that the hanging links will hang
straight down from the ceiling. It is important the ceiling
hooks are secure within the joists so they will bear the
weight of the rack and any cookware. Proper installation
diagram (See Photo – D) on next page.
Additional hooks available. See
www.prhousewares.com for a list of parts and e-tailers.
Hanging Wood Pot Racks
Models PR-40232 and PR-49232
Concept Housewares, A Division of PR Housewares, LLC
www.prhousewares.com Email: info@prhousewares.com
Page 1

Photo A - Fully Assembled

Photo B - Ceiling Hooks

Photo C - Corners
