PR Housewares Concept Housewares WR-40701 Quick Start Manual

Metal Wine Bottle / Glass Wall Rack
Model WR-40701 & WR-40702
WR-40701 holds 8 Bottles and 16 - 24 Glasses
WR-40702 holds 4 Bottles and 8 - 16 Glasses
Assembly:
To assemble, you will need the following:
- Level, pencil and tape measure
- Phillips head screw driver
- Hammer
- Electric drill and 5/16 drill bit
Lay out all the parts accordingly:
- Main unit (See Photo – A & B)
- Mounting brackets (See Photo – C)
Photo A - WR-40701 Fully Assembled
- Package of wall screws and plastic anchors and plastic key
Photo B - WR-40702 Fully Assembled
(See Photo – D)
Please consult with your local hardware store if you have
any questions or concerns about the construction of your
walls or ceilings. They can assist you in selecting the proper
hardware and procedures. The generic hardware provided
will work for most drywall applications. NOTE: these units
are handmade, slight variations can exist, always measure
twice before drilling.
Mounting Directions:
1. Measure carefully where you want to mount the wine rack on
the wall. Assemble the side braces to the main unit and use a
pencil to mark where the screws attach to the wall.
2. Remove the unit and drill holes using a 5/16" drill bit. If
possible mount to wall studs. Supplied anchors have a pull
rating of 20 lbs. or more each and a shear rating of 50 lbs. each.
3. Insert the anchors into the drilled holes. They may need to be
Photo C - Mounting Brackets
tapped in gently with a hammer. Use the supplied key to expand
the anchor behind drywall. (See Photos E to I on next page for
proper and improper anchor install).
4. Screw top screws into the left and right brackets into the
prepared holes. Do not tighten all the way yet.
5. Mount the main unit onto the braces, making sure that the
Photo D - Package of Screws.
wine glasses will slide into the rack from the front ( See photo –
Quantity may vary based on
A & B ). Screw bottom screws of the left and right brackets into
product ordered.
the prepared holes, tighten all screws at this point.
