Care and Cleaning

Indoor/Outdoor Coils

The Indoor/Outdoor coils on the Zoneline should be
cleaned and checked regularly.
NOTE: When cleaning the coils do not use acid based
coil cleaners. Care must be taken to avoid bending the
aluminum fins on the coils.
Indoor-Air Coil
Minor amounts of lint and dirt may pass through the
accumulations can be carefully vacuumed away with a
brush attachment on a vacuum cleaner or professionally
steam cleaned away.
Outdoor-Air Coil
outdoor-air intake should also be kept free of obstructions.
opening will reduce the efficiency of your unit and could
cause premature compressor failure.
the unit to be removed from the closet. See servicing
section of this manual for instructions on how to remove the
unit.

Base Pan

the unit from the outside and settle in the base pan (the
bottom of the unit).
6
Have the coils cleaned regularly.
may be present in the base pan.
Check it periodically and clean, if necessary.
Outdoor coils
