- Page 1 ADOC1551280 v.1.0 ADOC 13,8V/8A/OC Enclosed buffer switch mode power supply unit with automatic operation control. Edition: 1 from 07.10.2013 Supercedes edition: ---------------...
- Page 2 ADOC1551280 Features: 13,8VDC/8A uninterrupted supply FPS technical output indicating PSU failure – OC and relay type wide range of supply voltage 88÷264VAC FLB technical output indicating battery low high efficiency 80% voltage battery charge and maintenance control ...
- Page 3 ADOC1551280 1.2 Block diagram. (fig.1). Fig.1. Block diagram of the PSU. 1.3 Description of PSU components and connectors. Table 1. Elements of the PSU (see fig. 2). Element no. Description LED indicating presence of AC power LED indicating presence of DC power LED indicating correct battery voltage FAC- AC absence technical output –...
- Page 4 ADOC1551280 Fig. 2. The view of the PSU. 1.4 Specifications: - electrical specifications (tab.2) - mechanical specifications (tab.3) - operation safety (tab.4) - operating specifications (tab.5) Electrical specifications (tab. 2). Mains supply 88 ÷ 264V AC Current consumption 1,5A@230VAC typ.
- Page 5 ADOC1551280 Temperature characteristics. Chart 1. Acceptable output current from the PSU depending on ambient temperature. Mechanical specifications (tab. 3). Enclosure dimensions 199 x 110 x 50+23 [mm] (LxWxH)(+/- 2) Net/gross weight 0,94kg / 0,99kg Connectors power supply Φ0,64÷1,63 technical outputs: Φ0,41÷1,63 Operation safety (tab.4).
- Page 6 ADOC1551280 2.2. Installation procedure. 1. Before installation of the power supply unit, make sure that 230VAC power if cut off. 2. Mount the unit in the intended location. 3. Connect the 230VAC power cables. Connect the PE cable (yellow-green) to an appropriate PSU terminal (marked with - earth symbol).
- Page 7 ADOC1551280 - green LED (Fig.2, element 2) indicates DC power at the PSU output. Under normal status the diode is permanently illuminated. In case of a short circuit or an overload, the diode is off. - green LED (Fig.2, element 3) indicates battery voltage level. Under normal status (U >...
- Page 8 WEEE separately. GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a five -year warranty for the equipment, counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects, unless such...
