- Page 1 OWNER’S MANUAL FRENCH DOOR REFRIGERATOR Please read this owner's manual thoroughly before operating and keep it handy for reference at all times. LNXS30866* LNXC23766* www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS Storing Food PRODUCT FEATURES - Food Preservation Location - Food Storage Tips - Storing Frozen Food IMPORTANT SAFETY Adjusting the Refrigerator Shelves INSTRUCTIONS - Detaching the Shelf - Assembling the Shelf - Using the Folding Shelf - When Closing the Door COMPONENTS Big Fresh Zone... -
Page 3: Product Features
PRODUCT FEATURES PRODUCT FEATURES * Depending on the model, some of the following functions may not be available. DOOR ALARM The Door Alarm function is designed to prevent refrigerator malfunctioning that could occur if a refrigerator door or freezer door remains open. If a refrigerator door or freezer door is left open for more than 60 seconds, a warning alarm sounds at 30 second intervals until it is closed. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or hurt you or others, or cause damage to the product. - Page 5 IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety precautions should be followed, including the following: This product is not to be used for special purposes such as the storage of medicine or test materials or for use on ships, etc.
- Page 6 If the refrigerator is disconnected from the power supply, you should wait for at least five minutes before plugging it back in. If you notice a chemical or burning plastic smell or see smoke, unplug the refrigerator immediately and contact your LG Electronics Service Center. SAVE THESE INSTRUCTIONS...
-
Page 7: Components
COMPONENTS COMPONENTS Use this page to become more familiar with the parts and features of your refrigerator. *The appearance and specifications of the actual product may differ depending on the model. Refrigerator Exterior LED Display Displays the refrigerator and freezer’s target temperatures, the water filter condition and the dispenser status. -
Page 8: Refrigerator Interior
COMPONENTS Refrigerator Interior Adjustable Refrigerator Shelf The shelves in your refrigerator are adjustable to meet your individual storage needs. Dairy Corner Used to preserve dairy products. Bluetooth Speaker* Cheese & Butter Bin LED Interior Lamp Cheese & butter and Condiment bins, that The interior lamps light up are specially designed the inside of the refrigerator. -
Page 9: Installation
INSTALLATION INSTALLATION Installation Overview Please read the following installation instructions first after purchasing this product or transporting it to another location. 1 Unpacking your 2 Choosing the proper 3 Disassembling/Assembling refrigerator location 4 Connecting the 5 Leveling and Door water supply and Alignment water line NOTE... -
Page 10: Specifications
INSTALLATION Specifications The appearance and specifications listed in this manual may vary due to constant product improvements. Bottom-freezer refrigerator model LNXS30866* Description French door refrigerator Electrical requirements 115 VAC @ 60 Hz Min./Max. Water pressure 20 - 120 psi (138 - 827 kPa) Dimensions 35 7/8' (W) X 36 3/8' (D) X 70 1/2' (H), 49 3/4' (D w/ door open) 912 mm (W) X 923 mm (D) X 1790 mm (H), 1263 mm (D w/ door open) -
Page 11: Unpacking Your Refrigerator
INSTALLATION Unpacking Your Refrigerator Choosing the Proper Location Select a place where a water supply can WARNING be easily connected for the automatic icemaker. Use two or more people to move and install the refrigerator. Failure to do so NOTE can result in back or other injury. -
Page 12: Ambient Temperature
INSTALLATION Removing/Assembling the Doors Ambient Temperature Install this appliance in an area where the Removing the Left Refrigerator Door temperature is between 55°F (13°C) and 110°F (43°C). If the temperature around the appliance is too low or high, cooling ability may be The water supply is connected to the adversely affected. - Page 13 INSTALLATION Removing the Right Refrigerator Remove the cover and pull out the tube Door Disconnect all wire harnesses Remove the top hinge cover screw Lift the hook (not visible), located at the bottom of the front side of the cover with a flat-head screwdriver.
- Page 14 INSTALLATION Assembling the Freezer Doors Lift the door from the middle hinge pin and remove the door. Lower the door onto the lower hinge pin. Lower hinge CAUTION Position the middle hinge pin in place to hold the door and insert the two hinge Place the door, inside facing up, on a bolts.
- Page 15 INSTALLATION Assembling the Right Refrigerator Door Connect the wire harness Install the right-side door first. Make sure that the plastic sleeve is inserted in the bottom of the door. Lower the door onto the middle hinge pin as shown in the figure. Make sure that the door-switch located inside the cover is tightly connected.
- Page 16 INSTALLATION Assembling the Left Refrigerator Push the water supply tube into the hole Door on the top case and pull it through the backplate. Install the left refrigerator door after the right door is installed. Make sure that the plastic sleeve is inserted in the bottom of the door.
-
Page 17: Connecting The Water Line
INSTALLATION Connecting the Water Line NOTE Before You Begin Collet Tube This water line installation is not covered by the refrigerator warranty. Follow these instructions Insert Line carefully to minimize the risk of expensive water damage. Water hammer (water banging in the pipes) in 1) Gently insert the tube until only one house plumbing can cause damage to refrigerator line shows on the tube. -
Page 18: Water Pressure
INSTALLATION What You Will Need Water Pressure ¼ in. outer diameter, to Copper Tubing, The water pressure must be 20~120 psi or connect the refrigerator to the water 138~827 kPa or 1.4~8.4 kgf/cm² on models supply. Be sure both ends of the tubing without a water filter and 40~120 psi or 276~827 are cut square. -
Page 19: Water Line Installation Instructions
INSTALLATION Water Line Installation Instructions FASTEN THE SHUTOFF VALVE Fasten the shutoff valve to the cold water WARNING pipe with the pipe clamp. When using any electrical device Pipe Clamp (such as a power drill) during installation, be sure the device is battery powered, double insulated or grounded in a manner that will prevent the hazard of electric shock. -
Page 20: Turning On The Power
INSTALLATION CONNECT THE TUBING TO THE VALVE TURN THE WATER ON AT THE SHUTOFF Place the compression nut and ferrule VALVE (sleeve) for the copper tubing onto the Tighten any connections that leak. end of the tubing and connect it to the shutoff valve. -
Page 21: Leveling
INSTALLATION Leveling Door Alignment After installing, plug the refrigerator’s power Leveling the doors may not be possible when cord into a 3-prong grounded outlet and push the floor is not level, or is of weak or poor the refrigerator into the final position. construction. -
Page 22: Freezer Door Alignment
INSTALLATION Freezer Door Alignment Method 2, only allows a maximum of 3mm of adjustment) Method 1 is recommended. (1) Use the wider side of the number For freezer doors, use wrench wrench to unscrew the locking nut. Unscrew nut (2) Use the narrower side of the wrench to turn the adjustment hinge pin ( clockwise or ( ) counterclockwise,... -
Page 23: How To Use
HOW TO USE HOW TO USE Before use Clean the refrigerator. Clean your refrigerator thoroughly and wipe off all dust that accumulated during shipping. CAUTION Do not scratch the refrigerator with a sharp object or use a detergent that contains alcohol, a flammable liquid or an abrasive when removing any tape or adhesive from the refrigerator,. -
Page 24: Control Panel
HOW TO USE Control Panel Depending on the model, some of the following functions may not be available. Control Panel Features Refrigerator Temperature Ice Plus Indicates the set temperature of the refrigerator This function increases both ice making and compartment in Celsius (°C) or Fahrenheit (°F). freezing capabilities. - Page 25 HOW TO USE Control Panel Features (continued) Lock Replace Filter The Lock function disables every other button When the Replace Filter icon turns on, the air on the display. filter needs to be replaced. After replacing the air filter, press and hold the Fresh Air Filter When power is initially connected to the button for three seconds to turn the icon light refrigerator, the Lock function is off.
- Page 26 Power Saving Mode Connect When the refrigerator is in the Power Saving The Connect button, when used with the LG Mode, the display will remain off until a door Smart Refrigerator smart phone app, allows is opened or a button is pressed. Once on, the the refrigerator to connect to your home’s Wi-...
-
Page 27: Smart Features
1. a wireless router and home Wi-Fi network 2. the LG Smart Grid refrigerator 3. an Android-based smart phone 4. the LG Smart Refrigerator app from the Google Play Store. NOTE To use the Smart Grid feature, you must also register for the Smart Grid (Demand Response) service with your local electric utility company. - Page 28 HOW TO USE Smart Features (continued) Using the Smart Grid Function This feature responds to notification events LG Smart Refrigerator App - What’s from your utility company to run high energy- Included consuming tasks during off-peak periods when demand is lower. These notification events are Food Manager known as Demand Response signals.
- Page 29 Open API Remote Control LG Open API You can control the Refrigerator You can manage Smart Grid features for the LG Temperature, Fresh Air Filter and Ice Plus Smart Refrigerator. from the smart phone app. Please check the detailed specifications on the notice page on us.smartthinq.com.
- Page 30 HOW TO USE FCC Notice FCC RF Radiation Exposure Statement (for transmitter module contained in This equipment complies with FCC radiation this product) exposure limits set forth for an uncontrolled environment. This transmitter must not be co- This equipment has been tested and found to located or operating in conjunction with any other comply with the limits for a Class B digital device, antenna or transmitter.
-
Page 31: In-Door Ice Bin
HOW TO USE In-Door Ice Bin Depending on the model, some of the To remove the in-door ice bin, grip the following functions may not be available. front handle, slightly lift the lower part, and slowly pull out the bin as shown. CAUTION Keep hands and tools out of the ice compartment door and dispenser chute. -
Page 32: Automatic Icemaker
HOW TO USE Automatic Icemaker WARNING Personal Injury Hazard Depending on the model, some of the DO NOT place fingers or hands on the following functions may not be available. automatic ice making mechanism while the refrigerator is plugged in. Ice is made in the automatic icemaker and sent to the dispenser. - Page 33 HOW TO USE Automatic Icemaker When You Should Turn the Icemaker Off (continued) When the water supply will be shut off for several hours. CAUTION When the ice bin is removed for more The first ice and water dispensed may than one or two minutes.
-
Page 34: Ice And Water Dispenser
HOW TO USE Ice and Water Dispenser NOTE If discolored ice is dispensed, check Depending on the model, some of the the water filter and water supply. If the following functions may not be available. problem continues, contact a qualified service center. -
Page 35: Storing Food
HOW TO USE Storing Food Food Preservation Location Each compartment inside the refrigerator is designed to store different types of food. Store your food in the optimal space to enjoy the freshest taste. Adjustable refrigerator shelf Adjustable shelves to meet your individual storage needs. Dairy Corner Store dairy foods such as Refrigerator Bin... -
Page 36: Food Storage Tips
HOW TO USE Storing Frozen Food Food Storage Tips The following tips may not be applicable NOTE depending on the model. Check a freezer guide or a reliable cookbook for further information about preparing food Wrap or store food in the refrigerator in airtight for freezing or food storage times. -
Page 37: Adjusting The Refrigerator Shelves
HOW TO USE Storing Frozen Food (continued) Adjusting the Refrigerator Shelves Packaging The shelves in your refrigerator are adjustable Successful freezing depends on correct to meet your individual storage needs. Your packaging. When you close and seal the model may have either glass or wire shelves. package, it must not allow air or moisture in or out. -
Page 38: Using The Folding Shelf
HOW TO USE Using the Folding Shelf When Closing the Door You can store taller items, such as containers or bottles, by simply pushing the front half of the shelf underneath the back half of the shelf. Pull the front of the shelf firmly toward you to return to a full shelf. -
Page 39: Big Fresh Zone
HOW TO USE Big Fresh Zone Assembling the Big Fresh Zone Drawer Removing the Big Fresh Zone Drawer Slightly tilt up the front of the drawer and insert the rollers on the sides into the Open both refrigerator doors fully. Pull the guides. -
Page 40: Removing/Assembling The Fresh Zone
HOW TO USE Removing/Assembling the Assembling the Fresh Zone Compartment Fresh Zone Compartment (Model Name : LNXC23766*) Hold the Fresh Zone compartment at an angle and place it into the refrigerator Removing the Fresh Zone compartment. Compartment Open the refrigerator doors all the way. Empty and remove the Door-in-Door case and bins. - Page 41 HOW TO USE Removing/Assembling the Assembling the Fresh Zone Compartment Fresh Zone Compartment (Model Name : LNXS30866*) Hold the cover at a 45-degree angle and insert it into the refrigerator. Removing the Fresh Zone Compartment Open both refrigerator doors completely and empty and remove the Door-in-Door case and bins.
-
Page 42: Easyreach
HOW TO USE EasyReach™ Dairy Corner The EasyReach™ compartments are slightly Use the Dairy Corner to store items such as cooler than the shelf or door bin areas. They butter and cheese. are a convenient place to store dairy snacks or other small items you want to keep especially cold. -
Page 43: Removing The Door-In-Door Compartment
HOW TO USE Removing the Door-in-Door Remove the screws on both sides of the Compartment Door-in-Door compartment. CAUTION Remove contents from the Door-in-Door compartment before disassembly. To remove the Door-in-Door case, lift up and pull out. Move the EasyLift bin up to remove it. Lift the lower door bin from the bottom to remove it. -
Page 44: Easylift Bin
HOW TO USE EasyLift Bin Freezer Drawer Move the EasyLift bin up and down easily and The sliding freezer drawers allow easy access conveniently as necessary. Remove the contents and convenience of use. of the bin before raising or lowering it. Use the upper compartments to store packaged frozen foods and frequently-used To raise the bin, hold the center of the bin and... -
Page 45: Assembling The Freezer Drawer
HOW TO USE Refrigerator/Freezer Door Bins Assembling the Freezer Drawer Store small packaged frozen food in the freezer Open both freezer doors completely. Raise door bins, or small packaged refrigerated food the front of the drawer slightly and insert or beverages in the refrigerator door bins, such the rollers on the drawer's sides into the as milk, water, juice, beer, etc. -
Page 46: Maintenance
MAINTENANCE MAINTENANCE Cleaning Both the refrigerator and freezer sections defrost automatically; however, clean both sections about once a month to prevent odors. Wipe up spills immediately. Always unplug the refrigerator before cleaning. General Cleaning Tips Inside Walls (Allow the freezer to warm up so the Unplug refrigerator or disconnect power. -
Page 47: Replacing The Fresh Air Filter
MAINTENANCE Replacing the Fresh Air Filter Replace the fresh air filter: Install a new air filter. Approximately every six months. Place the new filter inside of the cover with the side that says “Front” facing When the REPLACE FILTER light turns on. outward. -
Page 48: Replacing The Water Filter
MAINTENANCE Replacing the Water Filter NOTE Replace with a new water filter. This refrigerator does not require a filter Insert the new filter into the filter head and bypass plug when the filter is not in place. rotate it clockwise until the arrow on the new filter lines up with the arrow on the filter head. - Page 49 MAINTENANCE Performance Data Sheet Use Replacement Cartridge: ADQ73613401 The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system as specified in NSF/ANSI Standard 42 and Standard 53.
- Page 50 The disposable filter cartridge must be replaced every six months, at the rated capacity or if a noticeable reduction in flow rate occurs. NSF is a trademark of NSF International. LG is a trademark of LG Corp. MCM Co..Ltd.
- Page 51 MAINTENANCE California Department of Public Health Certification 14-3015...
-
Page 52: Smart Diagnosis
Press and hold the Freezer Smart Diagnosis™ feature when instructed button for three seconds to do so by the LG call center agent. The while continuing to hold your transmission sounds that you will hear are phone to the speaker. -
Page 53: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Review the Troubleshooting section before calling for service; doing so will save you both time and money. Problem Possible Causes Solutions Refrigerator and The refrigerator control is set to Turn the control ON. Refer to the Setting the Freezer section OFF (some models). - Page 54 TROUBLESHOOTING Problem Possible Causes Solutions Refrigerator or Refrigerator was recently It may take up to 24 hours for each compartment Freezer section is installed. to reach the desired temperature. too warm. Air vents are blocked. Rearrange items to allow air to flow throughout the compartment.
- Page 55 TROUBLESHOOTING Problem Possible Causes Solutions Interior moisture Doors are opened often or for When the doors are opened often or for long buildup. long periods of time. periods of time, warm, humid air enters the compartment. This raises the temperature and moisture level within the compartment.
- Page 56 TROUBLESHOOTING Problem Possible Causes Solutions Frost or ice Condensation from food with a This is normal for food items with a high water crystals on frozen high water content has frozen content. food (inside of inside of the food package. sealed package).
- Page 57 TROUBLESHOOTING Problem Possible Causes Solutions Icemaker is not Doors are opened often or for If the doors of the unit are opened often, ambient making enough long periods of time. air will warm the refrigerator which will prevent ice (continued). the unit from maintaining the set temperature.
- Page 58 TROUBLESHOOTING Problem Possible Causes Solutions Not dispensing Doors are not closed Ice will not dispense if any of the refrigerator ice. completely. doors are left open. Infrequent use of the dispenser. Infrequent use of the ice dispenser will cause the cubes to stick together over time, which will prevent them from properly dispensing.
- Page 59 TROUBLESHOOTING Problem Possible Causes Solutions Not dispensing New installation or water line Dispense 2.5 gallons of water (flush for water. recently connected. approximately 5 minutes) to remove trapped air and contaminants from the system. Do not dispense the entire 2.5 gallon amount continuously.
- Page 60 TROUBLESHOOTING Problem Possible Causes Solutions Ice has bad taste Water supply contains minerals A water filter may need to be installed to or odor. such as sulfur. eliminate taste and odor problems. NOTE: In some cases, a filter may not help. It may not be possible to remove all minerals / odor / taste in all water supplies.
- Page 61 TROUBLESHOOTING Problem Possible Causes Solutions Icemaker is Icemaker shutoff (arm/sensor) Empty the ice bin. If your icemaker is equipped making too much is obstructed. with an ice shutoff arm, make sure that the arm ice. moves freely. If your icemaker is equipped with the electronic ice shutoff sensor, make sure that there is a clear path between the two sensors.
- Page 62 TROUBLESHOOTING Problem Possible Causes Solutions Pulsating or Your refrigerator is designed Normal Operation High-Pitched to run more efficiently to keep Sound your food items at the desired temperature. The high efficiency compressor may cause your new refrigerator to run longer than your old one, but it is still more energy efficient than previous models.
-
Page 63: Warranty
Should your LG Refrigerator (“Product”) fail due to a defect in materials or workmanship under normal home use, during the warranty period set forth below, LG will at its option repair or replace the product. This limited warranty is valid only to the original retail purchaser of the product and applies only when purchased and used within the United States including U.S. - Page 64 Call 1-800-243-0000 (24 hours a day, 365 days a year) and select the appropriate option from the menu, or visit our website at http://www.lg.com Or by mail: LG Customer Information Center: P. O. Box 240007, 201 James Record Road Huntsville, Alabama 35813 ATTN: CIC...
- Page 65 WARRANTY: Should your LG Refrigerator (“Product”) fail due to a defect in material or workmanship under normal home use during the warranty period set forth below, LG Canada will at its option repair or replace the Product upon receipt of proof of original retail purchase. This warranty is valid only to the original retail purchaser of the product and applies only to a Product distributed in Canada by LG Canada or an authorized Canadian distributor thereof.
- Page 66 6. Damage resulting from the misuse, abuse, improper installation, repair, or maintenance of the Product. Improper repair includes use of parts not approved or specified by LG Canada. 7. Damage or product failure caused by unauthorized modification or alteration, or use for other than its intended purpose, or resulting from any water leakage due to improper installation.
