Winplus Australasia does not take any responsibility for the loss of the Cocoon FPV HD Camera Drone and it
is NOT covered by warranty. We recommend that users test their drone in a safe indoor environment before
attempting to fly the drone outdoors.
We highly recommend that you read the instruction manual in full before attempting to operate and fly the drone.
PHONE HOLDER
ON/OFF BUTTON
LEFT
THUMBSTICK
Fly Up/Down
Turn Left/Right
Depress for fine tuning
VIDEO
ENGAGE PROPELLERS
FLIGHT
Up & Down
Push the left thumb stick up
or down to move the drone
upwards or downwards
Push the left thumb stick up
to the highest point and then
allow the thumb stick to reset
to the centre
Forward & Backward
Push the right thumb stick up
or down to move the drone
forwards or backwards.
CONTROL
REFEREnCE
SWITCH OFF PROPELLERS
Turn Left & Right
Pull the left thumb stick left
or right to turn the drone left
or right.
REMOTE
RIGHT
THUMBSTICK
Fly Forward/
Backward
Fly Left/Right
Headless Mode
Speed Control
360º FLIP
STUNT
B - AUTO
TAKE OFF/
LAND
Push the left thumb stick
down to the lowest level and
hold for approximately 5
seconds until the drone has
landed and powered down
Fly Sideways
Pull the right thumb stick left
or right to move the drone to
the left or right.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HE180101 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cocoon HE180101

  • Page 1 CONTROL REFEREnCE Winplus Australasia does not take any responsibility for the loss of the Cocoon FPV HD Camera Drone and it is NOT covered by warranty. We recommend that users test their drone in a safe indoor environment before attempting to fly the drone outdoors.
  • Page 2 GETTING STARTED GUIDE Version 1.0 INSTALL THE REMOTE UNPACK CONTROL BATTERIES Unpack your Cocoonv FPV HD Camera Drone and check that you have Remove the battery cover and Install the 4 x AA supplied batteries into received all components as listed on page 11 of your manual. the back of the remote control.
