Summary of Contents for Cocoon VOYAGER SKY SCANNER HD QUADCOPTER HE160972
- Page 1 Model Number: HE160972 INSTRUCTION MANUAL...
- Page 2 Version 1.0 Date of Issue 18/08/16...
-
Page 3: Warranty Details
WARRANTY DETAILS SKY SCANNER HD QUADCOPTER Warranty Details The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion. The benefits conferred by this warranty are in addition to all rights and remedies in respect of the product that the consumer has under the Competition and Consumer Act 2010 and similar state and territory laws. -
Page 4: Safety Instructions
Follow the instructions and take notice of all warning to reduce risk of fire or electric shock. • Read the instructions in this manual thoroughly before operating your Cocoon Voyager Sky Scanner HD Quadcopter • The Sky Scanner HD Quadcopter must be operated safely at all times. It is the operator’s responsibility to always fly in safe conditions... -
Page 5: Rules & Regulations
RULES & REGULATIONS The following regulations must be followed when operating a camera drone or quadcopter in Australia. • You must only operate this aircraft in your line-of-sight in daylight • You must not fly closer than 30 metres to vehicles, boats, buildings or people •... -
Page 6: Warranty Note
WARRANTY NOTE Getting the most out of your Sky Scanner Read the manual carefully It will help you get set up with ease Visit www.winplus.com.au We’ve got additional support videos and guides Call After Sales Support - 1300 663 907 Available Monday - Friday, 8:30am - 6:00pm AEST Email customercare@winplus.com.au We’re always happy to help... -
Page 7: Table Of Contents
Warranty Note Battery Note Parts List Technical specifications Features Product Overview 1.1 Cocoon Voyager Sky Scanner HD Quadcopter 1.2 Remote Control Installation 2.1 Installing the Control Batteries 2.2 Charging the Sky Scanner HD Quadcopter Battery 2.3 Installing the Propellers 2.4 Installing the Landing Skids 2.5 Installing the Propeller Guards... -
Page 8: Parts List
PARTS LIST • • 1 x Cocoon Voyager 1 x Action Camera Sky Scanner HD Mount Quadcopter • 6 x AA Activ Energy • Batteries 1 x Remote Control • • 1 x Rechargeable 4 x Propeller Guards • Battery 4 x Landing Skids •... -
Page 9: Product Overview
PRODUCT OVERVIEW 1.1 Cocoon Voyager Sky Scanner HD Quadcopter Propeller Guards Landing Gear Camera Propellers 1.2 Remote Control Antenna Trim Slider A Mode Switch/ Trim Slider B Trick Button Record Button Headless Mode Trim Slider C Speed Button On/Off Button... -
Page 10: Installation
INSTALLATION 2.1 Installing the Control Batteries Remove the battery cover Install the 6 included AA batteries into the back of the remote control, taking note of the polarity Battery cover positions indicated Replace the cover 6 X 1.5V AA batteries 2.2 Charging the Sky Scanner HD Quadcopter Battery Connect the rechargeable battery to the Balance Charger... -
Page 11: Installing The Landing Skids
2.4 Installing the Landing Skids Insert the Landing Skids in to the bottom of the Quadcopter as shown Secure the Landing Skids with the included screws 2.5 Installing the Propeller Guards Remove the Propeller Guard covers on all 4 sides of the Sky Scanner Push the Propeller Guard into the slot until you hear a ‘click’... -
Page 12: Operation
OPERATION 3.1 Pairing the Sky Scanner to the Remote Control Turn the Sky Scanner power switch to ON and place on a flat surface. The LEDs will flash indicating it is in pairing mode Press the power button on the remote control until you hear a beep. The LED light on the remote control will be flashing red, indicating it is in pairing mode Push the left throttle all the way up and then all the way down to pair. -
Page 13: Flying The Sky Scanner
FLYING THE SKY SCANNER WARNING: Incorrect operation of the Sky Scanner HD Quadcopter may result in severe injury, loss of property or fines. Winplus Australasia does not take any responsibility if local rules and regulations are not followed. Loss of the Sky Scanner HD Quadcopter is not covered by warranty. TIP: The best way to know which direction the Sky Scanner is facing, is by the coloured LEDs on its base. -
Page 14: Flying Modes
FLYING MODES 5.1 Default Mode 1 - Control Overview Hover up and down: Push the left throttle control stick up or down; the Sky Scanner will ascend or descend Forwards and backwards: Push the right throttle control stick up or down; the Sky Scanner will fly forwards or backwards Turn left or right: Pull the left throttle control stick left or right;... -
Page 15: Default Mode 1 - Trim Fine Tuning Control Overview
5.2 Default Mode 1 - Trim Fine Tuning Control Overview Forward/backward fine-tuning Leftside/rightside Left/right spin fine tuning fine tuning Backward Trim Backward Trimmer Forward Trim Forward Trimmer Leftside Trim Leftside Trimmer Rightside Trim Rightside Trimmer Left spin Trim Left spin Trimmer Right spin Trim Right spin Trimmer... -
Page 16: Default Mode 1 - Performing Tricks
5.3 Default Mode 1 - Performing Tricks Once you are familiar with basic flight operations, you can: Fly the Sky Scanner to a height of more than 3 metres Perform tricks such as flips with your Sky Scanner, in any speed settings IMPORTANT NOTE: Make sure you allow enough space both above and below your Sky Scanner before attempting to perform flips WARNING: Never attempt tricks with bent or damaged propellers or guards... -
Page 17: Mode 2 - Control Overview
5.4 Mode 2 - Control Overview To change modes, press and hold the Mode Switch/Trick Button for 3 seconds. The remote will beep once, indicating mode has been changed. NOTE: To return to default mode, repeat the step above Hover up and down: Push the left throttle control stick up or down;... -
Page 18: Mode 2 - Trim Fine Tuning Control Overview
5.5 Mode 2 - Trim Fine Tuning Control Overview Forward/Backward fine tuning Left/Right Spin Left Sideward/Right fine tuning Sideward fine tuning Backward Trim Backward Trimmer Forward Trim Forward Trimmer Leftside Trim Leftside Trimmer Rightside Trim Rightside Trimmer Left spin Trim Left spin Trimmer Right spin Trim... -
Page 19: Mode 2 - Performing Tricks
5.6 Mode 2 - Performing Tricks IMPORTANT NOTE: Make sure you allow enough space both above and below your Sky Scanner before attempting to perform flips WARNING: Never attempt tricks with bent or damaged propellers or guards Press the Mode Switch/Trick Button once and push the left throttle to the left to perform a 360-degree left flip. -
Page 20: Other Functions
OTHER FUNCTIONS 6.1 Auto Trim Function (Mode1/Mode 2) Push both left and right throttles down towards the left at a 45-degree angle as indicated in the diagram for 10 seconds. When the light on the PC board of the Sky Scanner is flashing rapidly, release the throttles and the light on the PC board will remain lit, indicating auto trim is complete. -
Page 21: Taking Photos & Videos
6.5 Taking Photos & Videos Taking a Photo NOTE: Ensure you have inserted a Micro SD card into the Camera and the Camera cord is connected to the Sky Scanner’s ‘PLUG’ jack To take a photo, press the Photo Button (marked ‘b’). The Remote Control will beep once, indicating a photo has been taken Recording a Video... -
Page 22: Action Cameras
ACTION CAMERAS 7.1 Mounting your Action Camera onto the Sky Scanner You can mount your GoPro®* Camera or Action Camera (not included) onto the Camera Adaptor included, using the various cases or mounts that came with your Action Camera. Connect your Action Camera to the included adaptor Slide the adaptor with camera onto the quadcopter Use your camera to record as per the manufacturer’s instructions IMPORTANT NOTE: Damage to your Action Camera through incorrect use of the Sky Scanner is not covered... -
Page 23: Repair And Refurbished Goods Or Parts Notice
REPAIR AND REFURBISHED GOODS OR PARTS NOTICE SKY SCANNER HD QUADCOPTER Repair and Refurbished Goods or Parts Notice Unfortunately, from time to time, faulty products are manufactured which need to be returned to the Supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. - Page 24 After Sales Support 1300 663 907 customercare@winplus.com.au HE160972 Model Number...
