Wireless USB Adapter F5D6050
User's manual

Advertisement

Table of Contents
loading

Related Manuals for Belkin F5D6050

Summary of Contents for Belkin F5D6050

  • Page 1 Wireless USB Adapter F5D6050 User’s manual...

  • Page 2: Table Of Contents

    Uninstalling the Software and Drivers ..... . . 9 Using the Belkin Wireless LAN Monitor Utility ....10 The Status Tab .

  • Page 3: Introduction

    network settings for work, school, home, or any other setup • Wireless interface compliance with the IEEE 802.11b standard • USB interface, for Plug-and-Play installation and convenience • 64- or 128-bit Wireless (WEP) Encryption • Wireless access to networked resources •...

  • Page 4: Knowing Your Wireless Usb Network Adapter

    System Requirements • PC with one available USB port • Windows® 98, 2000, Me, or XP Package Contents • Belkin Wireless USB Network Adapter • Quick Installation Guide • Installation Software CD • User Manual KNOWING YOUR WIRELESS USB NETWORK...
  • Page 5 4. The installer will start. Click on or select “Easy” to continue to the next step. If you are using Windows XP, it is recommended that you use the Belkin Wireless USB Network Adapter Utility to manage the Adapter’s wireless settings.
  • Page 6 Click “Finish”. PLACING THE WIRELESS USB NETWORK ADAPTER 9. When the installation is complete, the Belkin WLAN Monitor icon will be on your desktop. To open the Monitor Utility, double-click on this icon. 10. A small icon in your system tray (bottom right corner of most screens) will appear.

  • Page 7: Connecting To Your Wireless Network

    “Uninstall” option in the menu, or you can go to the Windows Control Panel and select the “Add/Remove Programs” option. The Belkin wizard will walk you through the removal process. When you launch the Wireless LAN Monitor Utility (the Utility), you will presented with the screen below.

  • Page 8: Using The Belkin Wireless Lan Monitor Utility

    Utility screen without shutting the Utility down by clicking Exit (l). Double-clicking on the icon in the system tray will open the window. The Status Tab USING THE BELKIN WIRELESS LAN MONITOR UTILITY USING THE BELKIN WIRELESS LAN MONITOR...
  • Page 9 initial configuration setting when you install the Adapter. To learn how to use Profiles, see the section of this manual called “Using Profile Manager Mode”. (b) Operating Mode Shows the current wireless mode the Adapter is operating in. There are operating modes: “Infrastructure”...
  • Page 10 To change the SSID, click in the SSID field, type the SSID you want, then click “Apply”. USING THE BELKIN WIRELESS LAN MONITOR UTILITY (e) Tx Rate Displays the current rate of data transmission. There are five Tx rates possible: Fixed 11Mbps—Always transmit and receive at 11Mbps data rate...

  • Page 11: The Statistics Tab

    The closer you are to a wireless router or access point, the stronger the signal should be. USING THE BELKIN WIRELESS LAN MONITOR UTILITY (i) Link Quality Displays the quality of the wireless signal from 0 to 100%. The closer to 100%, the better the link quality is.

  • Page 12: The Site Survey Tab

    A large number of unsuccessful frames may indicate that there is a problem or interference in your area. USING THE BELKIN WIRELESS LAN MONITOR UTILITY The Site Survey Tab Clicking on the “Site Survey” tab will display a list of all available access points in your area.

  • Page 13: The Encryption Tab

    TIP: Double-clicking on the BSSID of an access point will make the Adapter join that particular network. To check the area for more access points, click “Re-Scan”. USING THE BELKIN WIRELESS LAN MONITOR UTILITY The Encryption Tab The “Encryption” tab is used to set up the wireless encryption settings.
  • Page 14 (rate, passphrase, and key). USING THE BELKIN WIRELESS LAN MONITOR UTILITY Setting 64-Bit or 128-Bit Manually Using an Alphanumeric Keyword (Advanced) 1. Select “64-bit” or “128-bit” encryption from the drop-down menu.

  • Page 15: The Advanced Tab

    (rate, passphrase, and key). USING THE BELKIN WIRELESS LAN MONITOR UTILITY Setting 64-Bit or 128-Bit Manually Using a Hexadecimal Key (Advanced) 1. Select “64-bit” or “128-bit” from the drop-down menu.

  • Page 16: Using Profile Manager Mode

    Enabling this mode will decrease performance of the Adapter, but may greatly enhance your battery life. Use this feature only if necessary. USING THE BELKIN WIRELESS LAN MONITOR UTILITY Using Profile Manager Mode Using Profiles allows you to save configurations for different wireless networks.
  • Page 17 USING THE BELKIN WIRELESS LAN MONITOR UTILITY Creating a Profile Before you can use the Profile Manager, you need to create a profile. Follow these steps to create a profile. 1. If not already, turn ON the Profile Manager mode by pressing the “Activate...

  • Page 18: Operating In Ad-Hoc Mode

    When you have completed setup of the Ad-Hoc network, computers will network together normally as if wired together through a hub or switch. TROUBLESHOOTING You can find technical support information at networking.belkin.com www.belkin.com through the tech support area. If you want to contact...

  • Page 19: Information

    Belkin Corporation warrants this product against defects in materials and workmanship for its lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided it is returned during the warranty period, with transportation charges prepaid, the authorized Belkin dealer from whom you purchased the product.
  • Page 20 • Consult the dealer or an experienced radio/TV technician for help. Modifications The FCC requires the user to be notified that any changes or modifications to this device that are not expressly approved by Belkin Components may void the users authority to operate the equipment. Canada- Industry Canada (IC) The wireless radio of this device complies with RSS 139 &...
  • Page 21 • EN 300 328 Technical requirement for radio equipment • ETS 300 826 General EMC requirements for radio equipment. To determine the type of transmitter, check the identification label on your Belkin product. Products with the CE marking comply with the EMC Directive (89/336/EEC) and the Low Voltage Directive (72/23/EEC) issued by the Commission of the European Community.
  • Page 22 F5D6050F00000 SP01 編號： 版次：A 版 產品規格書 F5D6050 適用機種： Wireless USB Adapter F5D6050 Specifications 1. General specification 2. Standard test condition 3. Electrical specification 4. Frequency channel plan 核准： 審查： 製表： 修訂日期： 制定日期： 2002 年 11 月 08 日 莊繐瑄 年...
  • Page 23 Specification Test Method/Condition Item Condition Min. Typ. Max. General specification 1-1. Standard IEEE 802.11b 1-2. Frequency Band(MHz) 2400 2483.5 1-3. No. of Selectable 11 Channels (US, Canada) Channels 13 Channels (Europe) 14 Channels (Japan) 1-4. Channel Spacing (MHz) 1-5. Modulation Technique DSSS (CCK, DQPSK, DBPSK) 1-6.
  • Page 24 4. Frequency channel plan Regulation Domains Channel_ID Frequency ETSI Spain France (Mhz) (X ’10’ ) (X ‘20’ ) (X ’30‘ ) (X ’31‘ ) (X ‘32’ ) (X ‘40’ ) 2412 2417 2422 2427 2432 2437 2442 2447 2452 2457 2462 2467 2472...
