- Page 1 VP230mb ViewPanel ® User Guide Guide de l’utilisateur Bedienungsanleitung Guía del usuario Guida dell'utente Guia do usuário Användarhandbok Käyttöopas Instrukcja obs ugi Full 23.1" Diagonal Viewable Screen...
-
Page 2: Table Of Contents
Setting the Timing Mode ...6 OSD Lock Settings ...6 Adjusting the Screen Image ...7 Other Information Specifications ...12 Troubleshooting...13 Customer Support ...14 Cleaning the ViewPanel ...15 Limited Warranty ...16 Appendix Safety Guidelines ...17 Compliance Information ...18 CE Conformity ...18 08/14/02 B ViewSonic VP230mb... -
Page 3: Product Registration
NERGY Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this mate- rial, or the performance or use of this product. -
Page 4: Getting Started
• Audio cable • U.S. Power cord • Schuko power cord • Quick Start Guide • ViewSonic Wizard CD-ROM (including user guide PDF file and INF/ICM display optimization files) The supplied INF file assures compatibility with Windows IMPORTANT: operating systems, and the ICM file (Integrated Color Management) assures accurate on-screen colors. -
Page 5: Quick Installation
NOTE: Windows 95, 98 or 2000 users may receive a message asking them to install the VP230mb INF file. 4 Install display optimization files (INF and ICM files) (1) Insert the ViewSonic Wizard CD-ROM into your computer’s CD-ROM drive. VGA analog video cable (optional) -
Page 6: Mounting Options
Installation of Base (Optional) To obtain a base installation kit, contact ViewSonic or your local dealer. Refer to the instructions that come with the base mounting kit. ViewSonic complies with VESA (Video Electronics Standards Association) 100 mm mounting standards. -
Page 7: Using The Viewpanel
OSD is locked. ® controls (pages 8 - 10) to ® VESA 1600 x 1200 @ 60 desktop > Properties > ® ▲ for 10 seconds. A message ▲ again for 10 seconds. A ViewSonic VP230mb... -
Page 8: Adjusting The Screen Image
Adjusting the Screen Image Use the buttons on the front control panel to display and adjust the OnView controls from ViewSonic . The controls are explained in the steps at the top of ® the next page and are further explained in the menu controls, pages 8 - 11. - Page 9 The following tips may help you optimize your display: • Adjust your computer's graphic card so that it outputs a video signal 1600 x 1200 @ 60Hz to the VP230mb. (Look for instructions on "changing the refresh rate" in your graphic card's user guide.) •...
- Page 10 Not available for digital mode. NOTE: expands and contracts the entire screen image. Zoom ▲ and down automatically sizes, centers, and fine tunes Contrast adjusts the difference between brings up the Image Adjust controls ViewSonic VP230mb ▼ , then ®...
- Page 11 Memory Recall settings if the display is operating in a factory Preset Timing Mode listed in this user guide. Exception: This control does not affect changes made with the User Color control. ▲ ▼ ViewSonic VP230mb...
- Page 12 OSD Position and control screens. sets the length of time the on-screen display OSD Time Out screen is displayed. For example, with a “15 second” setting, if a control is not pushed within 15 seconds, the display screen disappears. ViewSonic VP230mb...
-
Page 13: Other Information
Warning: Do not set the graphics card in your computer to exceed these refresh rates; doing so may result in permanent damage to the ViewPanel. Macintosh computers older than G3 require a ViewSonic contact ViewSonic. 23.1" full viewable diagonal area, TFT (Thin Film... -
Page 14: Troubleshooting
Loose or broken pins in the cable connector could cause an improper connection. • Connect the ViewPanel to another computer. • If you have an older graphics card, contact ViewSonic adapter. Control buttons do not work •... -
Page 15: Customer Support
F: +61 2 9929 8393 viewsonic.com T: 65 273 4018 service.sg@ F: 65 273 1566 viewsonic.com T: 886 2 2246 3456 service.ap@ F: 886 2 8242 3668 viewsonic.com T: 886 2 2246 3456 service.ap@ F: 886 2 8242 3668 viewsonic.com ViewSonic VP230mb... -
Page 16: Cleaning The Viewpanel
ViewPanel screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the ViewPanel.ViewSonic will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. -
Page 17: Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components. -
Page 18: Appendix
If you have any questions concerning which proper power cord to use, please consult with the dealer from whom you have purchased the product. Switzerland ... SEV Britain ... BASE/BS Japan ... Electric Appliance Control Act Figure A2 Maximum Current Rating of Unit 10 Amps 12 Amps 12 Amps 10 Amps 12 Amps ViewSonic VP230mb... -
Page 19: Compliance Information
Install and use the equipment according to the instruction manual. CE Conformity The device complies with the requirements of the EEC directive 89/336/EEC as amended by 92/31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic compatibility," and 73/ 23/EEC as amended by 93/68/EEC Art.13 with regard to “Safety." ViewSonic VP230mb... - Page 20 ViewSonic Corporation...
